【PaddlePaddle Hackathon 第四期】No.105 作品提交

活动链接 👉 No.105：基于PaddleNLP PPDiffusers 训练 AIGC 趣味模型

【队名】：megemini

【模型简介】：当中国水墨山水遇上AIGC

【模型链接】：Hugging Face 地址:

  • 模型 👉 megemini/shanshui_style 可以生成水墨山水画。
  • 模型 👉 megemini/shanshui_gen_style 可以生成水墨山水画的具像图片。

【AI Studio 项目】：👉 【Hackathon 4th AIGC】当中国水墨山水遇上AIGC

【AI Studio 应用中心】：👉 ☯ 当中国水墨山水遇上AIGC ☯

【Hugging Face 应用中心】：👉 megemini/shanshui

✨ 创意简介&效果展示 ✨

中国水墨山水画算的上中国文化的瑰宝，AIGC这么火，碰巧有个亲属 👉 亦石 画得一手好山水，那么就来看看模型学的如何，画得可有意境 ｡･:*˚:✧｡

这里有两个模型，利用 Textual Inversion 学习 style，预训练模型为 runwayml/stable-diffusion-v1-5 ：

  • megemini/shanshui_style 可以生成水墨山水画。
  • megemini/shanshui_gen_style 可以生成水墨山水画的具像图片。
Imagemodelprompt
megemini/shanshui_styleA fantasy landscape in <shanshui-style>
megemini/shanshui_styleA fantasy landscape in <shanshui-style>
megemini/shanshui_styleA fantasy landscape in <shanshui-style>
megemini/shanshui_gen_styleA fantasy landscape in <shanshui-gen-style>
megemini/shanshui_gen_styleA fantasy landscape in <shanshui-gen-style>
megemini/shanshui_gen_styleA fantasy landscape in <shanshui-gen-style>

AIGC虽然还有点问题，比如第一张图片上面的文字明显是乱画的～ 但是，这也比俺强啊 … … 😶‍🌫

另外，这里解释一下 megemini/shanshui_gen_style 这个模型的来历～

当时看到官方例子中的 StableDiffusionMegaPipeline 有个 img2img，出于好奇，就用水墨画（不是官方例子中的那种简笔画）作为输入，结果就是类似 megemini/shanshui_gen_style 风格的图片～

当时，确实是有点被震惊到，感觉很像是水墨画的一种具像，有种中西艺术揉合的样子，然后就用这些由水墨画生成的图片，又训练了一把 Textual Inversion 的 style，然后就有了 megemini/shanshui_gen_style。

这里看看当时我是被什么图片震撼到的（runwayml/stable-diffusion-v1-5 生成）：

原画生成(并用于此模型的训练)prompt
A fantasy landscape
A fantasy landscape
A fantasy landscape
A fantasy landscape
A fantasy landscape, trending on artstation

都知道AIGC能够生成很不错的图片，可当自己亲手生成这种图片，感觉还是不一样的，希望您能有同感 ଘ(੭ˊᵕˋ)੭ ੈ♡‧₊˚

接下来，就看看怎么一步步训练这些模型，并生成图片。

🖍️ 水墨山水画 - shanshui_style 模型 🖍️

1. 模型训练

模型的训练需要具备几个方面：

  • 数据

    这里我将一些亲属的水墨画放到了 ./train_shanshui/ 目录下面 (传播时要注明作者哦~)，您也可以自己添加自己喜欢的画作。




  • 工具

    这里用的是 Textual Inversion，paddlenlp 封装了 train_textual_inversion.py 可以很方便的调用。

  • 方法

    这里学习的是 style，也就是利用模型学习水墨山水画的风格。

  • 预训练模型

    这里用的是 runwayml/stable-diffusion-v1-5

万事具备，只需一行命令就可以训练模型了 ～ 训练之前记得要安装必要的包 ～

%%capture
# 安装好之后要重启此 notebook
!pip install "paddlenlp>=2.5.2" safetensors "ppdiffusers>=0.11.1" --user

# 训练模型
!python -u train_textual_inversion.py \--pretrained_model_name_or_path="runwayml/stable-diffusion-v1-5" \--train_data_dir="train_shanshui" \--learnable_property="style" \--placeholder_token="<shanshui-style>" --initializer_token="style" \--resolution=512 \--train_batch_size=1 \--gradient_accumulation_steps=4 \--max_train_steps=1000 \--learning_rate=5.0e-04 \--scale_lr \--lr_scheduler="constant" \--lr_warmup_steps=0 \--seed 2023 \--output_dir="shanshui_style"
/opt/conda/envs/python35-paddle120-env/lib/python3.9/site-packages/sklearn/utils/multiclass.py:14: DeprecationWarning: Please use `spmatrix` from the `scipy.sparse` namespace, the `scipy.sparse.base` namespace is deprecated.from scipy.sparse.base import spmatrix
[32m[2023-05-06 14:57:05,895] [    INFO][0m - Downloading tokenizer_config.json from https://bj.bcebos.com/paddlenlp/models/community/runwayml/stable-diffusion-v1-5/tokenizer/tokenizer_config.json[0m
100%|███████████████████████████████████████████| 312/312 [00:00<00:00, 227kB/s]
[32m[2023-05-06 14:57:05,987] [    INFO][0m - We are using <class 'paddlenlp.transformers.clip.tokenizer.CLIPTokenizer'> to load 'runwayml/stable-diffusion-v1-5/tokenizer'.[0m
[32m[2023-05-06 14:57:05,987] [    INFO][0m - Downloading https://bj.bcebos.com/paddlenlp/models/community/runwayml/stable-diffusion-v1-5/tokenizer/vocab.json and saved to /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/tokenizer[0m
[32m[2023-05-06 14:57:06,542] [    INFO][0m - Downloading vocab.json from https://bj.bcebos.com/paddlenlp/models/community/runwayml/stable-diffusion-v1-5/tokenizer/vocab.json[0m
100%|████████████████████████████████████████| 842k/842k [00:00<00:00, 32.2MB/s]
[32m[2023-05-06 14:57:06,671] [    INFO][0m - Downloading https://bj.bcebos.com/paddlenlp/models/community/runwayml/stable-diffusion-v1-5/tokenizer/merges.txt and saved to /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/tokenizer[0m
[32m[2023-05-06 14:57:06,708] [    INFO][0m - Downloading merges.txt from https://bj.bcebos.com/paddlenlp/models/community/runwayml/stable-diffusion-v1-5/tokenizer/merges.txt[0m
100%|████████████████████████████████████████| 512k/512k [00:00<00:00, 32.8MB/s]
[32m[2023-05-06 14:57:06,911] [    INFO][0m - Downloading https://bj.bcebos.com/paddlenlp/models/community/runwayml/stable-diffusion-v1-5/tokenizer/added_tokens.json and saved to /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/tokenizer[0m
[32m[2023-05-06 14:57:07,006] [    INFO][0m - Downloading added_tokens.json from https://bj.bcebos.com/paddlenlp/models/community/runwayml/stable-diffusion-v1-5/tokenizer/added_tokens.json[0m
100%|████████████████████████████████████████| 2.00/2.00 [00:00<00:00, 1.83kB/s]
[32m[2023-05-06 14:57:07,079] [    INFO][0m - Downloading https://bj.bcebos.com/paddlenlp/models/community/runwayml/stable-diffusion-v1-5/tokenizer/special_tokens_map.json and saved to /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/tokenizer[0m
[32m[2023-05-06 14:57:07,121] [    INFO][0m - Downloading special_tokens_map.json from https://bj.bcebos.com/paddlenlp/models/community/runwayml/stable-diffusion-v1-5/tokenizer/special_tokens_map.json[0m
100%|███████████████████████████████████████████| 478/478 [00:00<00:00, 331kB/s]
[32m[2023-05-06 14:57:07,167] [    INFO][0m - Already cached /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/tokenizer/tokenizer_config.json[0m
Downloading (…)cheduler_config.json: 100%|█████| 342/342 [00:00<00:00, 50.0kB/s]
W0506 14:57:07.386356 16163 gpu_resources.cc:61] Please NOTE: device: 0, GPU Compute Capability: 7.0, Driver API Version: 11.2, Runtime API Version: 11.2
W0506 14:57:07.389185 16163 gpu_resources.cc:91] device: 0, cuDNN Version: 8.2.
[32m[2023-05-06 14:57:08,854] [    INFO][0m - Adding <shanshui-style> to the vocabulary[0m
[32m[2023-05-06 14:57:08,889] [    INFO][0m - Downloading config.json from https://bj.bcebos.com/paddlenlp/models/community/runwayml/stable-diffusion-v1-5/text_encoder/config.json[0m
100%|███████████████████████████████████████████| 592/592 [00:00<00:00, 532kB/s]
[32m[2023-05-06 14:57:08,959] [    INFO][0m - loading configuration file /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/text_encoder/config.json[0m
[33m[2023-05-06 14:57:08,959] [ WARNING][0m - You are using a model of type clip_text_model to instantiate a model of type . This is not supported for all configurations of models and can yield errors.[0m
[32m[2023-05-06 14:57:08,960] [    INFO][0m - Model config PretrainedConfig {"_name_or_path": "openai/clip-vit-large-patch14","architectures": ["CLIPTextModel"],"attention_dropout": 0.0,"bos_token_id": 0,"dropout": 0.0,"eos_token_id": 2,"hidden_act": "quick_gelu","hidden_size": 768,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 3072,"layer_norm_eps": 1e-05,"max_position_embeddings": 77,"num_attention_heads": 12,"num_hidden_layers": 12,"pad_token_id": 1,"paddlenlp_version": null,"torch_dtype": "float32","transformers_version": "4.21.0.dev0","vocab_size": 49408
}
[0m
[32m[2023-05-06 14:57:09,000] [    INFO][0m - Downloading config.json from https://bj.bcebos.com/paddlenlp/models/community/runwayml/stable-diffusion-v1-5/text_encoder/config.json[0m
100%|███████████████████████████████████████████| 592/592 [00:00<00:00, 675kB/s]
[32m[2023-05-06 14:57:09,050] [    INFO][0m - loading configuration file /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/text_encoder/config.json[0m
[32m[2023-05-06 14:57:09,051] [    INFO][0m - Model config CLIPTextConfig {"_name_or_path": "openai/clip-vit-large-patch14","architectures": ["CLIPTextModel"],"attention_dropout": 0.0,"bos_token_id": 0,"dropout": 0.0,"eos_token_id": 2,"hidden_act": "quick_gelu","hidden_size": 768,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 3072,"layer_norm_eps": 1e-05,"max_position_embeddings": 77,"model_type": "clip_text_model","num_attention_heads": 12,"num_hidden_layers": 12,"pad_token_id": 1,"paddlenlp_version": null,"projection_dim": 512,"return_dict": true,"torch_dtype": "float32","transformers_version": "4.21.0.dev0","vocab_size": 49408
}
[0m
Downloading (…)model_state.pdparams: 100%|████| 492M/492M [00:03<00:00, 126MB/s]
Downloading (…)v1-5/vae/config.json: 100%|██████| 610/610 [00:00<00:00, 246kB/s]
Downloading (…)model_state.pdparams: 100%|████| 335M/335M [00:02<00:00, 127MB/s]
Downloading (…)1-5/unet/config.json: 100%|██████| 807/807 [00:00<00:00, 318kB/s]
Downloading (…)model_state.pdparams: 100%|██| 3.44G/3.44G [00:27<00:00, 126MB/s]
[32m[2023-05-06 14:57:52,806] [    INFO][0m - -----------  Configuration Arguments -----------[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - adam_beta1: 0.9[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - adam_beta2: 0.999[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - adam_epsilon: 1e-08[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - adam_weight_decay: 0.01[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - center_crop: False[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - dataloader_num_workers: 0[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - enable_xformers_memory_efficient_attention: False[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - gradient_accumulation_steps: 4[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - gradient_checkpointing: False[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - height: 512[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - hub_model_id: None[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - hub_token: None[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - initializer_token: style[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - language: en[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - learnable_property: style[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - learning_rate: 0.002[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - logging_dir: shanshui_style/logs[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - lr_num_cycles: 1[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - lr_power: 1.0[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - lr_scheduler: constant[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - lr_warmup_steps: 0[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - max_grad_norm: -1[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - max_train_steps: 1000[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - num_train_epochs: 2[0m
[32m[2023-05-06 14:57:52,807] [    INFO][0m - num_validation_images: 4[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - only_save_embeds: False[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - output_dir: shanshui_style[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - placeholder_token: <shanshui-style>[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - pretrained_model_name_or_path: runwayml/stable-diffusion-v1-5[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - push_to_hub: False[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - repeats: 100[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - report_to: visualdl[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - resolution: 512[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - save_steps: 500[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - scale_lr: True[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - seed: 2023[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - tokenizer_name: None[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - train_batch_size: 1[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - train_data_dir: train_shanshui[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - validation_epochs: 50[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - validation_prompt: None[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - width: 512[0m
[32m[2023-05-06 14:57:52,808] [    INFO][0m - ------------------------------------------------[0m
[32m[2023-05-06 14:57:52,933] [    INFO][0m - ***** Running training *****[0m
[32m[2023-05-06 14:57:52,933] [    INFO][0m -   Num examples = 2300[0m
[32m[2023-05-06 14:57:52,933] [    INFO][0m -   Num batches each epoch = 2300[0m
[32m[2023-05-06 14:57:52,933] [    INFO][0m -   Num Epochs = 2[0m
[32m[2023-05-06 14:57:52,933] [    INFO][0m -   Instantaneous batch size per device = 1[0m
[32m[2023-05-06 14:57:52,933] [    INFO][0m -   Total train batch size (w. parallel, distributed & accumulation) = 4[0m
[32m[2023-05-06 14:57:52,933] [    INFO][0m -   Gradient Accumulation steps = 4[0m
[32m[2023-05-06 14:57:52,933] [    INFO][0m -   Total optimization steps = 1000[0m
Train Steps:  50%|▌| 500/1000 [09:37<09:40,  1.16s/it, epoch=0000, lr=0.002, ste[32m[2023-05-06 15:07:30,439] [    INFO][0m - Saving embeddings[0m
Train Steps: 100%|█| 1000/1000 [19:14<00:00,  1.15s/it, epoch=0001, lr=0.002, st[32m[2023-05-06 15:17:07,914] [    INFO][0m - Saving embeddings[0mDownloading (…)1-5/model_index.json: 100%|█████| 601/601 [00:00<00:00, 70.2kB/s][AFetching 10 files:   0%|                                 | 0/10 [00:00<?, ?it/s][ADownloading (…)rocessor_config.json: 100%|█████| 342/342 [00:00<00:00, 49.1kB/s][A[AFetching 10 files:  20%|█████                    | 2/10 [00:00<00:00, 18.71it/s][ADownloading (…)model_state.pdparams:   0%|          | 0.00/1.22G [00:00<?, ?B/s][A[ADownloading (…)model_state.pdparams:   1%| | 10.5M/1.22G [00:00<00:14, 83.3MB/s][A[ADownloading (…)model_state.pdparams:   3%|  | 31.5M/1.22G [00:00<00:09, 123MB/s][A[ADownloading (…)model_state.pdparams:   4%|  | 52.4M/1.22G [00:00<00:09, 120MB/s][A[ADownloading (…)model_state.pdparams:   6%|  | 73.4M/1.22G [00:00<00:11, 102MB/s][A[ADownloading (…)model_state.pdparams:   8%| | 94.4M/1.22G [00:00<00:11, 95.8MB/s][A[ADownloading (…)model_state.pdparams:   9%|▏ | 105M/1.22G [00:01<00:11, 94.3MB/s][A[ADownloading (…)model_state.pdparams:  10%|▎  | 126M/1.22G [00:01<00:10, 104MB/s][A[ADownloading (…)model_state.pdparams:  12%|▎  | 147M/1.22G [00:01<00:09, 110MB/s][A[ADownloading (…)model_state.pdparams:  14%|▍  | 168M/1.22G [00:01<00:09, 107MB/s][A[ADownloading (…)model_state.pdparams:  16%|▍  | 189M/1.22G [00:01<00:09, 107MB/s][A[ADownloading (…)model_state.pdparams:  17%|▎ | 210M/1.22G [00:02<00:10, 97.6MB/s][A[ADownloading (…)model_state.pdparams:  18%|▎ | 220M/1.22G [00:02<00:11, 83.5MB/s][A[ADownloading (…)model_state.pdparams:  20%|▍ | 241M/1.22G [00:02<00:10, 89.9MB/s][A[ADownloading (…)model_state.pdparams:  22%|▍ | 262M/1.22G [00:02<00:10, 88.7MB/s][A[ADownloading (…)model_state.pdparams:  23%|▍ | 283M/1.22G [00:02<00:09, 93.6MB/s][A[ADownloading (…)model_state.pdparams:  25%|▌ | 304M/1.22G [00:03<00:10, 90.8MB/s][A[ADownloading (…)model_state.pdparams:  27%|▌ | 325M/1.22G [00:03<00:09, 97.4MB/s][A[ADownloading (…)model_state.pdparams:  28%|▊  | 346M/1.22G [00:03<00:08, 101MB/s][A[ADownloading (…)model_state.pdparams:  30%|▉  | 367M/1.22G [00:03<00:08, 102MB/s][A[ADownloading (…)model_state.pdparams:  32%|▉  | 388M/1.22G [00:03<00:07, 104MB/s][A[ADownloading (…)model_state.pdparams:  34%|█  | 409M/1.22G [00:04<00:07, 108MB/s][A[ADownloading (…)model_state.pdparams:  35%|█  | 430M/1.22G [00:04<00:06, 113MB/s][A[ADownloading (…)model_state.pdparams:  37%|▋ | 451M/1.22G [00:04<00:08, 92.3MB/s][A[ADownloading (…)model_state.pdparams:  39%|▊ | 472M/1.22G [00:04<00:07, 97.4MB/s][A[ADownloading (…)model_state.pdparams:  41%|▊ | 493M/1.22G [00:05<00:08, 88.5MB/s][A[ADownloading (…)model_state.pdparams:  41%|▊ | 503M/1.22G [00:05<00:08, 87.2MB/s][A[ADownloading (…)model_state.pdparams:  42%|▊ | 514M/1.22G [00:05<00:07, 88.5MB/s][A[ADownloading (…)model_state.pdparams:  44%|▉ | 535M/1.22G [00:05<00:07, 90.4MB/s][A[ADownloading (…)model_state.pdparams:  46%|█▎ | 556M/1.22G [00:05<00:06, 100MB/s][A[ADownloading (…)model_state.pdparams:  47%|█▍ | 577M/1.22G [00:05<00:06, 102MB/s][A[ADownloading (…)model_state.pdparams:  49%|█▍ | 598M/1.22G [00:06<00:05, 110MB/s][A[ADownloading (…)model_state.pdparams:  51%|█▌ | 619M/1.22G [00:06<00:05, 100MB/s][A[ADownloading (…)model_state.pdparams:  52%|█ | 629M/1.22G [00:06<00:06, 96.4MB/s][A[ADownloading (…)model_state.pdparams:  53%|█ | 640M/1.22G [00:06<00:05, 96.4MB/s][A[ADownloading (…)model_state.pdparams:  54%|█ | 661M/1.22G [00:06<00:05, 92.6MB/s][A[ADownloading (…)model_state.pdparams:  55%|█ | 671M/1.22G [00:06<00:06, 87.8MB/s][A[ADownloading (…)model_state.pdparams:  57%|█▏| 692M/1.22G [00:07<00:05, 92.3MB/s][A[ADownloading (…)model_state.pdparams:  58%|█▏| 703M/1.22G [00:07<00:06, 81.9MB/s][A[ADownloading (…)model_state.pdparams:  60%|█▏| 724M/1.22G [00:07<00:05, 82.2MB/s][A[ADownloading (…)model_state.pdparams:  60%|█▏| 734M/1.22G [00:07<00:05, 81.7MB/s][A[ADownloading (…)model_state.pdparams:  61%|█▏| 744M/1.22G [00:07<00:05, 81.6MB/s][A[ADownloading (…)model_state.pdparams:  63%|█▎| 765M/1.22G [00:08<00:05, 88.1MB/s][A[ADownloading (…)model_state.pdparams:  65%|█▎| 786M/1.22G [00:08<00:04, 98.2MB/s][A[ADownloading (…)model_state.pdparams:  66%|█▎| 797M/1.22G [00:08<00:04, 96.9MB/s][A[ADownloading (…)model_state.pdparams:  66%|█▎| 807M/1.22G [00:08<00:04, 92.5MB/s][A[ADownloading (…)model_state.pdparams:  68%|█▎| 828M/1.22G [00:08<00:03, 99.6MB/s][A[ADownloading (…)model_state.pdparams:  70%|█▍| 849M/1.22G [00:08<00:03, 96.1MB/s][A[ADownloading (…)model_state.pdparams:  71%|█▍| 860M/1.22G [00:08<00:03, 96.9MB/s][A[ADownloading (…)model_state.pdparams:  72%|█▍| 870M/1.22G [00:09<00:03, 89.5MB/s][A[ADownloading (…)model_state.pdparams:  72%|█▍| 881M/1.22G [00:09<00:03, 91.7MB/s][A[ADownloading (…)model_state.pdparams:  74%|█▍| 902M/1.22G [00:09<00:03, 98.3MB/s][A[ADownloading (…)model_state.pdparams:  76%|██▎| 923M/1.22G [00:09<00:02, 104MB/s][A[ADownloading (…)model_state.pdparams:  77%|█▌| 933M/1.22G [00:09<00:04, 65.4MB/s][A[ADownloading (…)model_state.pdparams:  79%|█▌| 965M/1.22G [00:10<00:02, 94.7MB/s][A[ADownloading (…)model_state.pdparams:  81%|█▌| 986M/1.22G [00:10<00:02, 94.8MB/s][A[ADownloading (…)model_state.pdparams:  83%|▊| 1.01G/1.22G [00:10<00:02, 92.0MB/s][A[ADownloading (…)model_state.pdparams:  85%|▊| 1.03G/1.22G [00:10<00:01, 99.1MB/s][A[ADownloading (…)model_state.pdparams:  86%|▊| 1.05G/1.22G [00:10<00:01, 97.3MB/s][A[ADownloading (…)model_state.pdparams:  88%|▉| 1.07G/1.22G [00:11<00:01, 93.1MB/s][A[ADownloading (…)model_state.pdparams:  89%|▉| 1.08G/1.22G [00:11<00:01, 93.5MB/s][A[ADownloading (…)model_state.pdparams:  91%|█▊| 1.10G/1.22G [00:11<00:01, 100MB/s][A[ADownloading (…)model_state.pdparams:  92%|▉| 1.12G/1.22G [00:11<00:00, 95.1MB/s][A[ADownloading (…)model_state.pdparams:  93%|▉| 1.13G/1.22G [00:12<00:01, 76.1MB/s][A[ADownloading (…)model_state.pdparams:  96%|█▉| 1.16G/1.22G [00:12<00:00, 102MB/s][A[ADownloading (…)model_state.pdparams:  97%|█▉| 1.18G/1.22G [00:12<00:00, 106MB/s][A[ADownloading (…)model_state.pdparams: 100%|█| 1.22G/1.22G [00:12<00:00, 95.4MB/s][A[ADownloading (…)_checker/config.json: 100%|██████| 553/553 [00:00<00:00, 188kB/s][A[AFetching 10 files:  40%|██████████               | 4/10 [00:13<00:23,  3.85s/it][ADownloading (…)er/model_config.json: 100%|██████| 614/614 [00:00<00:00, 176kB/s][A[A
Fetching 10 files: 100%|████████████████████████| 10/10 [00:13<00:00,  1.32s/it]
[32m[2023-05-06 15:17:21,677] [    INFO][0m - loading configuration file /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/safety_checker/config.json[0m
[32m[2023-05-06 15:17:21,678] [    INFO][0m - Model config CLIPVisionConfig {"architectures": ["StableDiffusionSafetyChecker"],"attention_dropout": 0.0,"dropout": 0.0,"hidden_act": "quick_gelu","hidden_size": 1024,"image_size": 224,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 4096,"layer_norm_eps": 1e-05,"model_type": "clip_vision_model","num_attention_heads": 16,"num_channels": 3,"num_hidden_layers": 24,"paddlenlp_version": null,"patch_size": 14,"projection_dim": 768,"return_dict": true
}
[0m
[32m[2023-05-06 15:17:24,896] [    INFO][0m - loading configuration file /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/feature_extractor/preprocessor_config.json from cache at /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/feature_extractor/preprocessor_config.json[0m
[32m[2023-05-06 15:17:24,896] [    INFO][0m - size should be a dictionary on of the following set of keys: ({'width', 'height'}, {'shortest_edge'}, {'longest_edge', 'shortest_edge'}), got 224. Converted to {'shortest_edge': 224}.[0m
[32m[2023-05-06 15:17:24,896] [    INFO][0m - crop_size should be a dictionary on of the following set of keys: ({'width', 'height'}, {'shortest_edge'}, {'longest_edge', 'shortest_edge'}), got 224. Converted to {'height': 224, 'width': 224}.[0m
[32m[2023-05-06 15:17:24,897] [    INFO][0m - Image processor CLIPFeatureExtractor {"crop_size": {"height": 224,"width": 224},"do_center_crop": true,"do_convert_rgb": true,"do_normalize": true,"do_rescale": true,"do_resize": true,"feature_extractor_type": "CLIPFeatureExtractor","image_mean": [0.48145466,0.4578275,0.40821073],"image_processor_type": "CLIPFeatureExtractor","image_std": [0.26862954,0.26130258,0.27577711],"resample": 3,"rescale_factor": 0.00392156862745098,"size": {"shortest_edge": 224}
}
[0m
[32m[2023-05-06 15:17:32,510] [    INFO][0m - Configuration saved in shanshui_style/text_encoder/config.json[0m
[32m[2023-05-06 15:17:33,173] [    INFO][0m - tokenizer config file saved in shanshui_style/tokenizer/tokenizer_config.json[0m
[32m[2023-05-06 15:17:33,173] [    INFO][0m - Special tokens file saved in shanshui_style/tokenizer/special_tokens_map.json[0m
[32m[2023-05-06 15:17:33,174] [    INFO][0m - added tokens file saved in shanshui_style/tokenizer/added_tokens.json[0m
[32m[2023-05-06 15:17:39,729] [    INFO][0m - Configuration saved in shanshui_style/safety_checker/config.json[0m
[32m[2023-05-06 15:17:41,937] [    INFO][0m - Image processor saved in shanshui_style/feature_extractor/preprocessor_config.json[0m
[32m[2023-05-06 15:17:41,937] [    INFO][0m - Saving embeddings[0m
Train Steps: 100%|█| 1000/1000 [19:49<00:00,  1.19s/it, epoch=0001, lr=0.002, st
[0m

几个主要的参数：

–pretrained_model_name_or_path=“runwayml/stable-diffusion-v1-5” \ # 预训练模型

–train_data_dir=“train_shanshui” \ # 数据目录

–learnable_property=“style” \ # 学习 style

–placeholder_token=“<shanshui-style>” \ # prompt 中用来表示此 style 的 token

–initializer_token=“style” \ # 初始化 token

–resolution=512 \

–train_batch_size=1 \

–gradient_accumulation_steps=4 \

–max_train_steps=1000 \ # 训练步骤，有时间可以设置多一些

–learning_rate=5.0e-04 \

–scale_lr \

–lr_scheduler=“constant” \

–lr_warmup_steps=0 \

–seed 2023 \

–output_dir=“shanshui_style” # 模型保存的路径

2. 模型预测

模型预测利用 ppdiffusers 的 StableDiffusionPipeline，这里注意，要在 prompt 中加入上面 placeholder_token 设置的token <shanshui-style>。

另外，生成图片的分辨率越高，貌似生成的图片 *质量* 越好 ～

import matplotlib.pyplot as plt
%matplotlib inlinefrom ppdiffusers import StableDiffusionPipeline# 我们所需加载的模型地址，这里我们输入了训练时候使用的 output_dir 地址
model_path = "shanshui_style"
pipe = StableDiffusionPipeline.from_pretrained(model_path)prompt = "A fantasy landscape in <shanshui-style>"
image = pipe(prompt, num_inference_steps=100, guidance_scale=7.5, height=432, width=768,).images[0]
[2023-05-06 15:21:08,008] [    INFO] - loading configuration file shanshui_style/feature_extractor/preprocessor_config.json from cache at shanshui_style/feature_extractor/preprocessor_config.json
[2023-05-06 15:21:08,011] [    INFO] - Image processor CLIPFeatureExtractor {"crop_size": {"height": 224,"width": 224},"do_center_crop": true,"do_convert_rgb": true,"do_normalize": true,"do_rescale": true,"do_resize": true,"feature_extractor_type": "CLIPFeatureExtractor","image_mean": [0.48145466,0.4578275,0.40821073],"image_processor_type": "CLIPFeatureExtractor","image_std": [0.26862954,0.26130258,0.27577711],"resample": 3,"rescale_factor": 0.00392156862745098,"size": {"shortest_edge": 224}
}[2023-05-06 15:21:08,013] [    INFO] - loading configuration file shanshui_style/safety_checker/config.json
[2023-05-06 15:21:08,015] [    INFO] - Model config CLIPVisionConfig {"architectures": ["StableDiffusionSafetyChecker"],"attention_dropout": 0.0,"dropout": 0.0,"dtype": "float32","hidden_act": "quick_gelu","hidden_size": 1024,"image_size": 224,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 4096,"layer_norm_eps": 1e-05,"model_type": "clip_vision_model","num_attention_heads": 16,"num_channels": 3,"num_hidden_layers": 24,"paddlenlp_version": null,"patch_size": 14,"projection_dim": 768,"return_dict": true
}[2023-05-06 15:21:10,500] [    INFO] - loading configuration file shanshui_style/text_encoder/config.json
[2023-05-06 15:21:10,503] [    INFO] - Model config CLIPTextConfig {"_name_or_path": "openai/clip-vit-large-patch14","architectures": ["CLIPTextModel"],"attention_dropout": 0.0,"bos_token_id": 0,"dropout": 0.0,"dtype": "float32","eos_token_id": 2,"hidden_act": "quick_gelu","hidden_size": 768,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 3072,"layer_norm_eps": 1e-05,"max_position_embeddings": 77,"model_type": "clip_text_model","num_attention_heads": 12,"num_hidden_layers": 12,"pad_token_id": 1,"paddlenlp_version": null,"projection_dim": 512,"return_dict": true,"torch_dtype": "float32","transformers_version": "4.21.0.dev0","vocab_size": 49409
}[2023-05-06 15:21:11,683] [    INFO] - Adding <shanshui-style> to the vocabulary0%|          | 0/100 [00:00<?, ?it/s]

plt.imshow(image)

<matplotlib.image.AxesImage at 0x7fd1203a91f0>

在这里插入图片描述

🖍️ 水墨山水画具像图 - shanshui_gen_style 模型 🖍️

1. 模型训练

同样，这里看看模型训练的几个要素：

  • 数据

    这里需要利用 Stable diffusion 的 img2img，将之前用到的水墨画先生成具像图，作为此模型的训练数据。




  • 工具

    同 shanshui_style，这里用的是 Textual Inversion，paddlenlp 封装了 train_textual_inversion.py 可以很方便的调用。

  • 方法

    同 shanshui_style，这里学习的是 style，也就是利用模型学习水墨山水画具像之后的风格。

  • 预训练模型

    同 shanshui_style，这里用的是 runwayml/stable-diffusion-v1-5

这里单独介绍一下如何用 img2img 生成图片：

from stable_diffusion_mega import StableDiffusionMegaPipeline
import PIL
import paddlepipe = StableDiffusionMegaPipeline.from_pretrained("runwayml/stable-diffusion-v1-5", paddle_dtype=paddle.float16)
pipe.enable_attention_slicing()
generator = paddle.Generator().manual_seed(202305)prompt = "A fantasy landscape"
init_image = PIL.Image.open("train_shanshui/mmexport1477788619881.jpg").convert("RGB")
with paddle.amp.auto_cast(True, level="O2"):image = pipe.img2img(prompt=prompt,image=init_image,strength=0.75,guidance_scale=7.5,generator=generator).images[0]
Fetching 18 files:   0%|          | 0/18 [00:00<?, ?it/s][2023-05-06 15:42:09,430] [    INFO] - loading configuration file /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/feature_extractor/preprocessor_config.json from cache at /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/feature_extractor/preprocessor_config.json
[2023-05-06 15:42:09,433] [    INFO] - size should be a dictionary on of the following set of keys: ({'width', 'height'}, {'shortest_edge'}, {'shortest_edge', 'longest_edge'}), got 224. Converted to {'shortest_edge': 224}.
[2023-05-06 15:42:09,435] [    INFO] - crop_size should be a dictionary on of the following set of keys: ({'width', 'height'}, {'shortest_edge'}, {'shortest_edge', 'longest_edge'}), got 224. Converted to {'height': 224, 'width': 224}.
[2023-05-06 15:42:09,437] [    INFO] - Image processor CLIPFeatureExtractor {"crop_size": {"height": 224,"width": 224},"do_center_crop": true,"do_convert_rgb": true,"do_normalize": true,"do_rescale": true,"do_resize": true,"feature_extractor_type": "CLIPFeatureExtractor","image_mean": [0.48145466,0.4578275,0.40821073],"image_processor_type": "CLIPFeatureExtractor","image_std": [0.26862954,0.26130258,0.27577711],"resample": 3,"rescale_factor": 0.00392156862745098,"size": {"shortest_edge": 224}
}[2023-05-06 15:42:09,439] [    INFO] - loading configuration file /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/safety_checker/config.json
[2023-05-06 15:42:09,441] [    INFO] - Model config CLIPVisionConfig {"architectures": ["StableDiffusionSafetyChecker"],"attention_dropout": 0.0,"dropout": 0.0,"hidden_act": "quick_gelu","hidden_size": 1024,"image_size": 224,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 4096,"layer_norm_eps": 1e-05,"model_type": "clip_vision_model","num_attention_heads": 16,"num_channels": 3,"num_hidden_layers": 24,"paddlenlp_version": null,"patch_size": 14,"projection_dim": 768,"return_dict": true
}[2023-05-06 15:42:12,238] [    INFO] - loading configuration file /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/text_encoder/config.json
[2023-05-06 15:42:12,242] [    INFO] - Model config CLIPTextConfig {"_name_or_path": "openai/clip-vit-large-patch14","architectures": ["CLIPTextModel"],"attention_dropout": 0.0,"bos_token_id": 0,"dropout": 0.0,"eos_token_id": 2,"hidden_act": "quick_gelu","hidden_size": 768,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 3072,"layer_norm_eps": 1e-05,"max_position_embeddings": 77,"model_type": "clip_text_model","num_attention_heads": 12,"num_hidden_layers": 12,"pad_token_id": 1,"paddlenlp_version": null,"projection_dim": 512,"return_dict": true,"torch_dtype": "float32","transformers_version": "4.21.0.dev0","vocab_size": 49408
}0%|          | 0/37 [00:00<?, ?it/s]

plt.figure(figsize=(16, 6))
plt.subplot(211)
plt.imshow(init_image)plt.subplot(212)
plt.imshow(image)
<matplotlib.image.AxesImage at 0x7fd331dd6c70>

在这里插入图片描述

只需要将 ./train_shanshui/ 目录下面的图片通过上面的 img2img 方法生成具像图片，然后保存下来即可。

这里已经提前生成好了，保存在 ./train_shanshui_gen 目录下。

您可以直接使用，也可以换个 prompt 重新生成一下 ～

有了这些图片，就可以训练 shanshui_gen_style 模型了，方法跟 shanshui_style 一样 ～

!python -u train_textual_inversion.py \--pretrained_model_name_or_path="runwayml/stable-diffusion-v1-5" \--train_data_dir="train_shanshui_gen" \--learnable_property="style" \--placeholder_token="<shanshui-gen-style>" --initializer_token="style" \--resolution=512 \--train_batch_size=1 \--gradient_accumulation_steps=4 \--max_train_steps=1000 \--learning_rate=5.0e-04 \--scale_lr \--lr_scheduler="constant" \--lr_warmup_steps=0 \--seed 2023 \--output_dir="shanshui_gen_style"

/opt/conda/envs/python35-paddle120-env/lib/python3.9/site-packages/sklearn/utils/multiclass.py:14: DeprecationWarning: Please use `spmatrix` from the `scipy.sparse` namespace, the `scipy.sparse.base` namespace is deprecated.from scipy.sparse.base import spmatrix
[2023-05-06 15:46:35,822] [    INFO] - Found /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/tokenizer/tokenizer_config.json
[2023-05-06 15:46:35,822] [    INFO] - We are using <class 'paddlenlp.transformers.clip.tokenizer.CLIPTokenizer'> to load 'runwayml/stable-diffusion-v1-5/tokenizer'.
[2023-05-06 15:46:35,822] [    INFO] - Already cached /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/tokenizer/vocab.json
[2023-05-06 15:46:35,822] [    INFO] - Already cached /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/tokenizer/merges.txt
[2023-05-06 15:46:35,822] [    INFO] - Already cached /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/tokenizer/added_tokens.json
[2023-05-06 15:46:35,823] [    INFO] - Already cached /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/tokenizer/special_tokens_map.json
[2023-05-06 15:46:35,823] [    INFO] - Already cached /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/tokenizer/tokenizer_config.json
W0506 15:46:35.914148 21179 gpu_resources.cc:61] Please NOTE: device: 0, GPU Compute Capability: 7.0, Driver API Version: 11.2, Runtime API Version: 11.2
W0506 15:46:35.917075 21179 gpu_resources.cc:91] device: 0, cuDNN Version: 8.2.
[2023-05-06 15:46:37,482] [    INFO] - Adding <shanshui-gen-style> to the vocabulary
[2023-05-06 15:46:37,527] [    INFO] - Found /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/text_encoder/config.json
[2023-05-06 15:46:37,528] [    INFO] - loading configuration file /home/aistudio/.paddlenlp/models/runwayml/stable-diffusion-v1-5/text_encoder/config.json
[2023-05-06 15:46:37,528] [ WARNING] - You are using a model of type clip_text_model to instantiate a model of type . This is not supported for all configurations of models and can yield errors.
[2023-05-06 15:46:37,529] [    INFO] - Model config PretrainedConfig {"_name_or_path": "openai/clip-vit-large-patch14","architectures": ["CLIPTextModel"],"attention_dropout": 0.0,"bos_token_id": 0,"dropout": 0.0,"eos_token_id": 2,"hidden_act": "quick_gelu","hidden_size": 768,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 3072,"layer_norm_eps": 1e-05,"max_position_embeddings": 77,"num_attention_heads": 12,"num_hidden_layers": 12,"pad_token_id": 1,"paddlenlp_version": null,"torch_dtype": "float32","transformers_version": "4.21.0.dev0","vocab_size": 49408
}[2023-05-06 15:46:37,568] [    INFO] - Found /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/text_encoder/config.json
[2023-05-06 15:46:37,569] [    INFO] - loading configuration file /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/text_encoder/config.json
[2023-05-06 15:46:37,570] [    INFO] - Model config CLIPTextConfig {"_name_or_path": "openai/clip-vit-large-patch14","architectures": ["CLIPTextModel"],"attention_dropout": 0.0,"bos_token_id": 0,"dropout": 0.0,"eos_token_id": 2,"hidden_act": "quick_gelu","hidden_size": 768,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 3072,"layer_norm_eps": 1e-05,"max_position_embeddings": 77,"model_type": "clip_text_model","num_attention_heads": 12,"num_hidden_layers": 12,"pad_token_id": 1,"paddlenlp_version": null,"projection_dim": 512,"return_dict": true,"torch_dtype": "float32","transformers_version": "4.21.0.dev0","vocab_size": 49408
}[2023-05-06 15:46:48,452] [    INFO] - -----------  Configuration Arguments -----------
[2023-05-06 15:46:48,452] [    INFO] - adam_beta1: 0.9
[2023-05-06 15:46:48,452] [    INFO] - adam_beta2: 0.999
[2023-05-06 15:46:48,452] [    INFO] - adam_epsilon: 1e-08
[2023-05-06 15:46:48,452] [    INFO] - adam_weight_decay: 0.01
[2023-05-06 15:46:48,452] [    INFO] - center_crop: False
[2023-05-06 15:46:48,452] [    INFO] - dataloader_num_workers: 0
[2023-05-06 15:46:48,452] [    INFO] - enable_xformers_memory_efficient_attention: False
[2023-05-06 15:46:48,452] [    INFO] - gradient_accumulation_steps: 4
[2023-05-06 15:46:48,452] [    INFO] - gradient_checkpointing: False
[2023-05-06 15:46:48,452] [    INFO] - height: 512
[2023-05-06 15:46:48,452] [    INFO] - hub_model_id: None
[2023-05-06 15:46:48,452] [    INFO] - hub_token: None
[2023-05-06 15:46:48,452] [    INFO] - initializer_token: style
[2023-05-06 15:46:48,452] [    INFO] - language: en
[2023-05-06 15:46:48,453] [    INFO] - learnable_property: style
[2023-05-06 15:46:48,453] [    INFO] - learning_rate: 0.002
[2023-05-06 15:46:48,453] [    INFO] - logging_dir: shanshui_gen_style/logs
[2023-05-06 15:46:48,453] [    INFO] - lr_num_cycles: 1
[2023-05-06 15:46:48,453] [    INFO] - lr_power: 1.0
[2023-05-06 15:46:48,453] [    INFO] - lr_scheduler: constant
[2023-05-06 15:46:48,453] [    INFO] - lr_warmup_steps: 0
[2023-05-06 15:46:48,453] [    INFO] - max_grad_norm: -1
[2023-05-06 15:46:48,453] [    INFO] - max_train_steps: 1000
[2023-05-06 15:46:48,453] [    INFO] - num_train_epochs: 1
[2023-05-06 15:46:48,453] [    INFO] - num_validation_images: 4
[2023-05-06 15:46:48,453] [    INFO] - only_save_embeds: False
[2023-05-06 15:46:48,453] [    INFO] - output_dir: shanshui_gen_style
[2023-05-06 15:46:48,453] [    INFO] - placeholder_token: <shanshui-gen-style>
[2023-05-06 15:46:48,453] [    INFO] - pretrained_model_name_or_path: runwayml/stable-diffusion-v1-5
[2023-05-06 15:46:48,453] [    INFO] - push_to_hub: False
[2023-05-06 15:46:48,453] [    INFO] - repeats: 100
[2023-05-06 15:46:48,453] [    INFO] - report_to: visualdl
[2023-05-06 15:46:48,453] [    INFO] - resolution: 512
[2023-05-06 15:46:48,453] [    INFO] - save_steps: 500
[2023-05-06 15:46:48,453] [    INFO] - scale_lr: True
[2023-05-06 15:46:48,453] [    INFO] - seed: 2023
[2023-05-06 15:46:48,453] [    INFO] - tokenizer_name: None
[2023-05-06 15:46:48,453] [    INFO] - train_batch_size: 1
[2023-05-06 15:46:48,453] [    INFO] - train_data_dir: train_shanshui_gen
[2023-05-06 15:46:48,453] [    INFO] - validation_epochs: 50
[2023-05-06 15:46:48,453] [    INFO] - validation_prompt: None
[2023-05-06 15:46:48,453] [    INFO] - width: 512
[2023-05-06 15:46:48,453] [    INFO] - ------------------------------------------------
[2023-05-06 15:46:48,545] [    INFO] - ***** Running training *****
[2023-05-06 15:46:48,545] [    INFO] -   Num examples = 4500
[2023-05-06 15:46:48,545] [    INFO] -   Num batches each epoch = 4500
[2023-05-06 15:46:48,545] [    INFO] -   Num Epochs = 1
[2023-05-06 15:46:48,545] [    INFO] -   Instantaneous batch size per device = 1
[2023-05-06 15:46:48,545] [    INFO] -   Total train batch size (w. parallel, distributed & accumulation) = 4
[2023-05-06 15:46:48,545] [    INFO] -   Gradient Accumulation steps = 4
[2023-05-06 15:46:48,546] [    INFO] -   Total optimization steps = 1000
Train Steps:  50%|▌| 500/1000 [09:32<09:32,  1.14s/it, epoch=0000, lr=0.002, ste[2023-05-06 15:56:20,836] [    INFO] - Saving embeddings
Train Steps: 100%|█| 1000/1000 [19:07<00:00,  1.15s/it, epoch=0000, lr=0.002, st[2023-05-06 16:05:55,695] [    INFO] - Saving embeddingsFetching 10 files: 100%|███████████████████████| 10/10 [00:00<00:00, 318.92it/s]
[2023-05-06 16:06:03,860] [    INFO] - loading configuration file /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/feature_extractor/preprocessor_config.json from cache at /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/feature_extractor/preprocessor_config.json
[2023-05-06 16:06:03,861] [    INFO] - size should be a dictionary on of the following set of keys: ({'width', 'height'}, {'shortest_edge'}, {'longest_edge', 'shortest_edge'}), got 224. Converted to {'shortest_edge': 224}.
[2023-05-06 16:06:03,861] [    INFO] - crop_size should be a dictionary on of the following set of keys: ({'width', 'height'}, {'shortest_edge'}, {'longest_edge', 'shortest_edge'}), got 224. Converted to {'height': 224, 'width': 224}.
[2023-05-06 16:06:03,861] [    INFO] - Image processor CLIPFeatureExtractor {"crop_size": {"height": 224,"width": 224},"do_center_crop": true,"do_convert_rgb": true,"do_normalize": true,"do_rescale": true,"do_resize": true,"feature_extractor_type": "CLIPFeatureExtractor","image_mean": [0.48145466,0.4578275,0.40821073],"image_processor_type": "CLIPFeatureExtractor","image_std": [0.26862954,0.26130258,0.27577711],"resample": 3,"rescale_factor": 0.00392156862745098,"size": {"shortest_edge": 224}
}[2023-05-06 16:06:03,861] [    INFO] - loading configuration file /home/aistudio/.cache/paddlenlp/ppdiffusers/runwayml/stable-diffusion-v1-5/safety_checker/config.json
[2023-05-06 16:06:03,863] [    INFO] - Model config CLIPVisionConfig {"architectures": ["StableDiffusionSafetyChecker"],"attention_dropout": 0.0,"dropout": 0.0,"hidden_act": "quick_gelu","hidden_size": 1024,"image_size": 224,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 4096,"layer_norm_eps": 1e-05,"model_type": "clip_vision_model","num_attention_heads": 16,"num_channels": 3,"num_hidden_layers": 24,"paddlenlp_version": null,"patch_size": 14,"projection_dim": 768,"return_dict": true
}[2023-05-06 16:06:08,550] [    INFO] - Configuration saved in shanshui_gen_style/text_encoder/config.json
[2023-05-06 16:06:09,679] [    INFO] - tokenizer config file saved in shanshui_gen_style/tokenizer/tokenizer_config.json
[2023-05-06 16:06:09,679] [    INFO] - Special tokens file saved in shanshui_gen_style/tokenizer/special_tokens_map.json
[2023-05-06 16:06:09,680] [    INFO] - added tokens file saved in shanshui_gen_style/tokenizer/added_tokens.json
[2023-05-06 16:06:25,831] [    INFO] - Configuration saved in shanshui_gen_style/safety_checker/config.json
[2023-05-06 16:06:28,328] [    INFO] - Image processor saved in shanshui_gen_style/feature_extractor/preprocessor_config.json
[2023-05-06 16:06:28,329] [    INFO] - Saving embeddings
Train Steps: 100%|█| 1000/1000 [19:39<00:00,  1.18s/it, epoch=0000, lr=0.002, st

2. 模型预测

同样，模型预测利用 ppdiffusers 的 StableDiffusionPipeline，这里注意，要在 prompt 中加入上面 placeholder_token 设置的token <shanshui-gen-style>。

另外，生成图片的分辨率越高，貌似生成的图片 *质量* 越好 ～

import matplotlib.pyplot as plt
%matplotlib inlinefrom ppdiffusers import StableDiffusionPipeline# 我们所需加载的模型地址，这里我们输入了训练时候使用的 output_dir 地址
model_path = "shanshui_gen_style"
pipe = StableDiffusionPipeline.from_pretrained(model_path)prompt = "A fantasy landscape in <shanshui-gen-style>"
image = pipe(prompt, num_inference_steps=100, guidance_scale=7.5, height=432, width=768,).images[0]
[2023-05-06 17:25:48,682] [    INFO] - loading configuration file shanshui_gen_style/feature_extractor/preprocessor_config.json from cache at shanshui_gen_style/feature_extractor/preprocessor_config.json
[2023-05-06 17:25:48,684] [    INFO] - Image processor CLIPFeatureExtractor {"crop_size": {"height": 224,"width": 224},"do_center_crop": true,"do_convert_rgb": true,"do_normalize": true,"do_rescale": true,"do_resize": true,"feature_extractor_type": "CLIPFeatureExtractor","image_mean": [0.48145466,0.4578275,0.40821073],"image_processor_type": "CLIPFeatureExtractor","image_std": [0.26862954,0.26130258,0.27577711],"resample": 3,"rescale_factor": 0.00392156862745098,"size": {"shortest_edge": 224}
}[2023-05-06 17:25:48,686] [    INFO] - loading configuration file shanshui_gen_style/safety_checker/config.json
[2023-05-06 17:25:48,688] [    INFO] - Model config CLIPVisionConfig {"architectures": ["StableDiffusionSafetyChecker"],"attention_dropout": 0.0,"dropout": 0.0,"dtype": "float32","hidden_act": "quick_gelu","hidden_size": 1024,"image_size": 224,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 4096,"layer_norm_eps": 1e-05,"model_type": "clip_vision_model","num_attention_heads": 16,"num_channels": 3,"num_hidden_layers": 24,"paddlenlp_version": null,"patch_size": 14,"projection_dim": 768,"return_dict": true
}[2023-05-06 17:25:48,691] [    INFO] - Configuration saved in /home/aistudio/.cache/paddlenlp/ppdiffusers/shanshui_gen_style/safety_checker/config.json
[2023-05-06 17:25:51,073] [    INFO] - loading configuration file shanshui_gen_style/text_encoder/config.json
[2023-05-06 17:25:51,077] [    INFO] - Model config CLIPTextConfig {"_name_or_path": "openai/clip-vit-large-patch14","architectures": ["CLIPTextModel"],"attention_dropout": 0.0,"bos_token_id": 0,"dropout": 0.0,"dtype": "float32","eos_token_id": 2,"hidden_act": "quick_gelu","hidden_size": 768,"initializer_factor": 1.0,"initializer_range": 0.02,"intermediate_size": 3072,"layer_norm_eps": 1e-05,"max_position_embeddings": 77,"model_type": "clip_text_model","num_attention_heads": 12,"num_hidden_layers": 12,"pad_token_id": 1,"paddlenlp_version": null,"projection_dim": 512,"return_dict": true,"torch_dtype": "float32","transformers_version": "4.21.0.dev0","vocab_size": 49409
}[2023-05-06 17:25:51,080] [    INFO] - Configuration saved in /home/aistudio/.cache/paddlenlp/ppdiffusers/shanshui_gen_style/text_encoder/config.json
[2023-05-06 17:25:52,155] [    INFO] - Adding <shanshui-gen-style> to the vocabulary

": “quick_gelu”,
“hidden_size”: 768,
“initializer_factor”: 1.0,
“initializer_range”: 0.02,
“intermediate_size”: 3072,
“layer_norm_eps”: 1e-05,
“max_position_embeddings”: 77,
“model_type”: “clip_text_model”,
“num_attention_heads”: 12,
“num_hidden_layers”: 12,
“pad_token_id”: 1,
“paddlenlp_version”: null,
“projection_dim”: 512,
“return_dict”: true,
“torch_dtype”: “float32”,
“transformers_version”: “4.21.0.dev0”,
“vocab_size”: 49409
}

[2023-05-06 17:25:51,080] [    INFO] - Configuration saved in /home/aistudio/.cache/paddlenlp/ppdiffusers/shanshui_gen_style/text_encoder/config.json
[2023-05-06 17:25:52,155] [    INFO] - Adding <shanshui-gen-style> to the vocabulary0%|          | 0/100 [00:00<?, ?it/s]

plt.imshow(image)

<matplotlib.image.AxesImage at 0x7fd0ac2bb9a0>

在这里插入图片描述

🤗 HuggingFace 模型与应用 🤗

【飞桨黑客松】AIGC - DreamBooth LoRA 文生图模型微调

这个项目里面详细介绍了如何在 AI Studio 中使用 HuggingFace，有需要的同学可以过去看看 ～

项目里面提供了一个可以将模型上传到 HuggingFace 的方法：upload_lora_folder

使用前请确保已经登录了huggingface hub！

from utils import upload_lora_folder
upload_dir                    = "shanshui_gen_style"                      # 我们需要上传的文件夹目录
repo_name                     = "shanshui_gen_style"                     # 我们需要上传的repo名称
pretrained_model_name_or_path = "shanshui_gen_style"    # 训练该模型所使用的基础模型
prompt                        = "A fantasy landscape in <shanshui-gen-style>"    # 搭配该权重需要使用的Prompt文本upload_lora_folder(upload_dir=upload_dir,repo_name=repo_name,pretrained_model_name_or_path=pretrained_model_name_or_path,prompt=prompt,
)

虽然名字是 lora 相关的，但是没关系，模型上传上去之后手动修改一下 Model card 即可。

这里之前已经将两个模型上传上去了：

  • 模型 👉 megemini/shanshui_style 可以生成水墨山水画。
  • 模型 👉 megemini/shanshui_gen_style 可以生成水墨山水画的具像图片。

另外，在 AI Studio 和 HuggingFace 上建了一个相关的一个应用：

【AI Studio 应用中心】：👉 ☯ 当中国水墨山水遇上AIGC ☯

【Hugging Face 应用中心】：👉 megemini/shanshui

由于用不起GPU 👀 ，而CPU的服务运行起来又太慢（1000～2000+秒 🎃 ），这里简单放两张运行之后的截图：


如何自建应用，又是可以水一期的话题了 (๑˃̵ᴗ˂̵)，不过，很简单就是了 ～

总之，多看多学多试 ～

🍧 最后 🍧

欣赏别人的AIGC成果，远没有自己摸索来的有成就感！！！

不多说了，快来试试吧！😎

🍀 参考资料 🍀

【飞桨黑客松】AIGC - DreamBooth LoRA 文生图模型微调

Textual Inversion 微调代码

Community Examples

HuggingFace

gradio

此文章为搬运
原项目链接

这篇关于【Hackathon 4th AIGC】当中国水墨山水遇上AIGC的文章就介绍到这儿，希望我们推荐的文章对编程师们有所帮助！


http://www.chinasem.cn/article/261813。

相关文章

跨国公司撤出在华研发中心的启示：中国IT产业的挑战与机遇

跨国公司撤出在华研发中心的启示：中国IT产业的挑战与机遇

近日，IBM中国宣布撤出在华的两大研发中心，这一决定在IT行业引发了广泛的讨论和关注。跨国公司在华研发中心的撤出，不仅对众多IT从业者的职业发展带来了直接的冲击，也引发了人们对全球化背景下中国IT产业竞争力和未来发展方向的深思。面对这一突如其来的变化，我们应如何看待跨国公司的决策？中国IT人才又该如何应对？中国IT产业将何去何从？本文将围绕这些问题展开探讨。 跨国公司撤出的背景与
阅读更多...
从戴尔公司中国大饭店DTF大会，看科技外企如何在中国市场发展

从戴尔公司中国大饭店DTF大会，看科技外企如何在中国市场发展

【科技明说 ｜ 科技热点关注】 2024戴尔科技峰会在8月如期举行，虽然因事未能抵达现场参加，我只是观看了网上在线直播，也未能采访到DTF现场重要与会者，但是通过数十年对戴尔的跟踪与观察，我觉得2024戴尔科技峰会给业界传递了6大重要信号。不妨简单聊聊：从戴尔公司中国大饭店DTF大会，看科技外企如何在中国市场发展？ 1）退出中国的谣言不攻自破。 之前有不良媒体宣扬戴尔将退出中国的谣言，随着2
阅读更多...
关于大模型和AIGC的36条笔记和真话

关于大模型和AIGC的36条笔记和真话

行业到底有多卷？ 最新统计，中国已有130多个大模型问世，在网信办备案的算法模型也超过70多家。BAT等互联网巨头悉数下场发布AI大模型，仅2023年就有超60家创业公司拿到融资，产品更是布满了基础层、模型层和应用层。新一代生成式AI，可能要回头看看上一代AI趟过的坑，不要行业自嗨，避免上一个冬天的轮回。在这个领域的从业者，更要清晰地看到行业的内卷和客户的痛点，别被大佬的鸡汤迷了眼。 1、
阅读更多...
知名AIGC人工智能专家培训讲师唐兴通谈AI大模型数字化转型数字新媒体营销与数字化销售

知名AIGC人工智能专家培训讲师唐兴通谈AI大模型数字化转型数字新媒体营销与数字化销售

在过去的二十年里，中国企业在数字营销领域经历了一场惊心动魄的变革。从最初的懵懂无知到如今的游刃有余，这一路走来，既有模仿学习的艰辛，也有创新突破的喜悦。然而，站在人工智能时代的门槛上，我们不禁要问：下一个十年，中国企业将如何在数字营销的浪潮中乘风破浪？ 一、从跟风到精通：中国数字营销的进化史 回顾过去，中国企业在数字营销领域的发展可谓是一部"跟风学习"的编年史。从最初的搜索引擎营销（SEM），
阅读更多...
数据库遇上知识图谱、区块链、深度学习

数据库遇上知识图谱、区块链、深度学习

参考资料： https://zhuanlan.zhihu.com/p/33381916 https://www.zuozuovera.com/archives/1062/ 东南大学D&Intel Lab相关ppt 数据库的核心概念——表示、存取、查询 有了数据库是干什么，大概实现的逻辑，特点，才能引申出对当今这些新技术的对比、适应和发展。 目的：研究数据表示、存取数据模型：表示数据的模型，通
阅读更多...
AIGC大模型智能抠图（清除背景）：Sanster/IOPaint，python（2）

AIGC大模型智能抠图（清除背景）：Sanster/IOPaint，python（2）

AIGC大模型智能抠图（清除背景）：Sanster/IOPaint，python（2）   在文章（1）的基础上，尝试用大模型扣除图中的某些主要景物。 1、首先，安装插件： pip install rembg   2、第1步安装成功，启动webui，注意，这里要启用清除背景/抠图的插件 --enable-remove-bg ： iopaint start --model=lama
阅读更多...
【中国国际航空-注册/登录安全分析报告】

【中国国际航空-注册/登录安全分析报告】

前言 由于网站注册入口容易被黑客攻击，存在如下安全问题： 1. 暴力破解密码，造成用户信息泄露 2. 短信盗刷的安全问题，影响业务及导致用户投诉 3. 带来经济损失，尤其是后付费客户，风险巨大，造成亏损无底洞 所以大部分网站及App 都采取图形验证码或滑动验证码等交互解决方案， 但在机器学习能力提高的当下，连百度这样的大厂都遭受攻击导致点名批评， 图形验证及交互验证方式的安全性到底如
阅读更多...
隐私计算实训营：SplitRec：当拆分学习遇上推荐系统

隐私计算实训营：SplitRec：当拆分学习遇上推荐系统

拆分学习的概念 拆分学习的核心思想是拆分网络结构。每一个参与方拥有模型结构的一部分，所有参与方的模型合在一起形成一个完整的模型。训练过程中，不同参与方只对本地模型进行正向或者反向传播计算，并将计算结果传递给下一个参与方。多个参与方通过联合模型进行训练直至最终收敛。 一个典型的拆分学习例子： Alice持有数据和基础模型。Bob只有数据、基础模型和fuse模型。 Alice使用自己的数据
阅读更多...
中国书法——孙溟㠭浅析碑帖《越州石氏帖》

中国书法——孙溟㠭浅析碑帖《越州石氏帖》

孙溟㠭浅析碑帖《越州石氏帖》 《越州石氏帖》  是一部汇集多本摹刻的帖，南宋时期的会稽石邦哲（字熙明）把家藏的一些法书碑帖集中一起摹刻成的，宋理宗时临安书商陈思《宝刻丛编》有记載这部帖的目录。现在还存有宋代时拓的残缺本，大多是相传的晋朝唐朝的小楷，后人多有临摹学习，并以此版本重新摹刻。 （图片来源于网络） 图文/氿波整理
阅读更多...
将中国标准时间转换为年月日时分秒格式

将中国标准时间转换为年月日时分秒格式

1.将中国标准时间转换为年月日时分秒格式 代码如下（示例）： // 时间格式化timestampToTime(timestamp) {var chinaStandard=Mon Jul 19 2021 11:11:55 GMT+0800 (中国标准时间);var date = new Date(chinaStandard);var y = date.getFullYear();var m =
阅读更多...

Copyright China编程 23002807@qq.com

沪ICP备2023033072号-2
