【Android基础入门〖7〗】SurfaceView坦克大战之世界地图

本文主要是介绍【Android基础入门〖7〗】SurfaceView坦克大战之世界地图，希望对大家解决编程问题提供一定的参考价值，需要的开发者们随着小编来一起学习吧！

目录(?)[+]

1 自定义 SurfaceView

WarView.java (世界战场)

  package com.mytank;
 import java.util.Vector;
 import android.content.Context;
 import android.graphics.Canvas;
 import android.graphics.Color;
 import android.graphics.Paint;
 import android.graphics.Paint.Style;
 import android.util.AttributeSet;
 import android.view.MotionEvent;
 import android.view.SurfaceHolder;
 import android.view.SurfaceView;
 public class WarView extends SurfaceView implements SurfaceHolder.Callback {
     SurfaceHolder mholder;
     boolean run_flag;
     Canvas canvas;
     DrawThread thread;

     Vector<Wall>walllist=new Vector<Wall>();

     int row;//行
     int col;//列
     int warmap[][];

     float x=10,y=10;

     public WarView(Context context, AttributeSet attrs) {
         super(context, attrs);
         mholder=this.getHolder();

         if(mholder!=null)
             mholder.addCallback(this);
     }

     //初始化地图
     public void initmap()
     {
         //0 空， 1 墙
         for(int i=0;i<col;i++)
         {
             warmap[0][i]=1;
             warmap[1][i]=1;
             Wall wall=new Wall(0,i);
             walllist.add(wall);
             wall=new Wall(1,i);
             walllist.add(wall);
         }
         for(int i=0;i<10;i++)
         {
             warmap[i][10]=1;
             warmap[i][11]=1;
             Wall wall=new Wall(i,10);
             walllist.add(wall);
             wall=new Wall(i,11);
             walllist.add(wall);
         }
     }
     @Override
     public void surfaceCreated(SurfaceHolder holder) {
         run_flag=true;
         row=this.getHeight()/Common.CELL_LENGTH;
         col=this.getWidth()/Common.CELL_LENGTH;
         warmap=new int[row][col];
         thread=new DrawThread();
         initmap();
         thread.start();
     }

     @Override
     public boolean onTouchEvent(MotionEvent event) {
         // TODO 自动生成的方法存根
         x=event.getX();
         y=event.getY();


         /*  备注:  一定要将return super.onTouchEvent(event)修改为return true
          *  原因：
          *        1: 父类的onTouchEvent(event)方法没有做任何处理，并且返回了false。;
          *        2: 一旦返回false，将不再收到 MotionEvent.ACTION_MOVE 及 MotionEvent.ACTION_UP 事件;
          */
         return true;
     }

     //自定义 界面绘制 线程
     class DrawThread extends Thread
     {
         @Override
         public void run() {

             //画刷
             Paint paint=new Paint();
             paint.setStyle(Style.FILL);
             paint.setColor(Color.rgb(255, 0, 0));    //红绿蓝

             Paint bkpaint=new Paint();
             bkpaint.setStyle(Style.FILL);            //设置填充方式
             bkpaint.setColor(Color.rgb(2,17,17));    //红绿蓝

             while(run_flag)
             {
                 //锁定画布
                 canvas=mholder.lockCanvas();
                 if (canvas == null)
                     continue;

                 //绘制背景
                 canvas.drawRect(0, 0, Common.CELL_LENGTH*col, Common.CELL_LENGTH*row, bkpaint);

                 //绘制手势跟踪
                 canvas.drawCircle(x, y, 15, paint);

                 //绘制墙壁
                 for(int i=0;i<walllist.size();i++)
                     walllist.get(i).Draw(canvas);

                 //取消锁定
                 mholder.unlockCanvasAndPost(canvas);
             }
         }
     }

     @Override
     public void surfaceChanged(SurfaceHolder holder, int format, int width, int height) {
     }
     @Override
     public void surfaceDestroyed(SurfaceHolder holder) {
         run_flag=false;        //关闭界面绘制线程
     }
 }


2 在布局中使用自定义的 WarView

main_layout.xml

  <FrameLayout xmlns:android="http://schemas.android.com/apk/res/android"
     android:layout_width="match_parent"
     android:layout_height="match_parent">
     <com.mytank.WarView
         android:layout_width="match_parent"
         android:layout_height="match_parent"/>
 </FrameLayout>


3 封装的墙块类

Wall.java

  package com.mytank;
 import android.graphics.Canvas;
 import android.graphics.Color;
 import android.graphics.Paint;
 import android.graphics.Rect;
 import android.graphics.Paint.Style;
 /**
  * @author michael.mao
  * @description 封装的 墙块类，包含自绘制方法
  */
 public class Wall {

     public int mrow;    //该墙壁所在行
     public int mcol;
     Paint inPaint;        //墙壁内边框画刷
     Paint outPaint;
     Rect inRect;
     Rect outRect;

     public Wall(int row, int col)
     {
         this.mrow=row;
         this.mcol=col;

         inPaint=new Paint();
         inPaint=new Paint();
         inPaint.setStyle(Style.FILL);
         inPaint .setColor(Color.rgb(86, 53, 35));//红绿蓝

         outPaint=new Paint();
         outPaint=new Paint();
         outPaint.setStyle(Style.STROKE);
         outPaint.setColor(Color.rgb(98, 98, 98));

         inRect=new Rect( mcol*Common.CELL_LENGTH+1,mrow*Common.CELL_LENGTH+1,
                        ( mcol+1)*Common.CELL_LENGTH-1,(mrow+1)*Common.CELL_LENGTH-1);
         outRect=new Rect( mcol*Common.CELL_LENGTH,mrow*Common.CELL_LENGTH,
                         ( mcol+1)*Common.CELL_LENGTH,(mrow+1)*Common.CELL_LENGTH);
     }

     public void Draw(Canvas canvas)
     {
         canvas.drawRect(inRect,inPaint);
         canvas.drawRect(outRect,outPaint);
     }
 }


4 常量值

Common.java

  package com.mytank;
 public class Common {
     public static int CELL_LENGTH=10;    //块宽    战场被分成 M行 N 列, CELL_LENGTH==行高==列宽
 }


5 主类

MainActivity.java

  package com.mytank;
 import android.os.Bundle;
 import android.app.Activity;
 public class MainActivity extends Activity {
     @Override
     protected void onCreate(Bundle savedInstanceState) {
         super.onCreate(savedInstanceState);
         setContentView(R.layout.main_layout);
     }
 }
