手势密码（四）

2024-08-31 23:38
文章标签 密码 手势

本文主要是介绍手势密码（四），希望对大家解决编程问题提供一定的参考价值，需要的开发者们随着小编来一起学习吧！

之前写过3篇手势密码的demo,不过没有集成到真实的企业项目中，这几天正好领到一个手势密码项目，昨天刚好弄完，今天抽空整理下，目前还没有完善，有一些地方需要更改，不过基本的流程都可以跑通了

源码下载地址。。。。。



先看主界面的入口把、里面有2个button(一个是设置手势密码、一个是校验手势密码)

activity_main.xml

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"xmlns:tools="http://schemas.android.com/tools"android:layout_width="match_parent"android:layout_height="match_parent"tools:context="com.example.gesturelock.MainActivity" ><Buttonandroid:id="@+id/setting"android:layout_width="wrap_content"android:layout_height="wrap_content"android:layout_alignParentLeft="true"android:layout_alignParentTop="true"android:text="设置" /><Buttonandroid:id="@+id/verify"android:layout_width="wrap_content"android:layout_height="wrap_content"android:layout_alignParentTop="true"android:layout_toRightOf="@+id/setting"android:text="校验" /></RelativeLayout>
在看主界面的代码把

MainActivity

package com.example.gesturelock;import android.app.Activity;
import android.content.Intent;
import android.os.Bundle;
import android.view.Menu;
import android.view.MenuItem;
import android.view.View;
import android.view.View.OnClickListener;
import android.widget.Button;public class MainActivity extends Activity implements OnClickListener {private Button setting, verify;@Overrideprotected void onCreate(Bundle savedInstanceState) {super.onCreate(savedInstanceState);setContentView(R.layout.activity_main);setting = (Button) findViewById(R.id.setting);verify = (Button) findViewById(R.id.verify);setting.setOnClickListener(this);verify.setOnClickListener(this);}@Overridepublic void onClick(View v) {switch (v.getId()) {case R.id.setting:startActivity(new Intent(this, GestureEditActivity.class));break;case R.id.verify:startActivity(new Intent(this, GestureVerifyActivity.class));break;default:break;}}}

想了想还是先贴数据库把---就是存放手势密码、以及还可以输入的手势密码次数

publicSQLiteOpenHelper

package com.example.gesturelock;import android.content.ContentValues;
import android.content.Context;
import android.database.Cursor;
import android.database.SQLException;
import android.database.sqlite.SQLiteDatabase;
import android.database.sqlite.SQLiteOpenHelper;public class publicSQLiteOpenHelper extends SQLiteOpenHelper{private static String name = "publicsqlite";private static String GESTURE_PASSWORD = "gesture_password";private static final int version = 1;public SQLiteDatabase db;public publicSQLiteOpenHelper(Context context) {super(context, name, null, version);}@Overridepublic void onCreate(SQLiteDatabase db) {String sqlpass = "create table " + "gesture_password"+ "("+ GesturePassword.WXID + " text not null,"+ GesturePassword.PASSWORD + " text not null,"+ GesturePassword.REMAINOPPORTUNITY + " text not null)";db.execSQL(sqlpass);}@Overridepublic void onUpgrade(SQLiteDatabase db, int oldVersion, int newVersion) {db.execSQL("DROP TABLE IF EXISTS password");onCreate(db); }public class GesturePassword  {public static final String WXID = "wxid";public static final String PASSWORD = "password";public static final String REMAINOPPORTUNITY = "remainopportunity";}/*** 插入手势密码表*/public void insertGestureInfo(SQLiteDatabase database ,String password,String times){ContentValues values = null;try {values = new ContentValues();values.put(GesturePassword.WXID, "001");values.put(GesturePassword.PASSWORD, password);values.put(GesturePassword.REMAINOPPORTUNITY, ""+times);database.insert(publicSQLiteOpenHelper.GESTURE_PASSWORD, null,values);} catch (Exception e) {e.printStackTrace();throw new SQLException(e.getMessage());}finally{if (values != null) {values.clear();values = null;}}}/*** 修改手势密码表---初始化次数为8次* * */public void updateGestureInfo(SQLiteDatabase database,String password,String times) {ContentValues values = null;try {if (password == null) {values = new ContentValues();values.put(GesturePassword.WXID, "001");values.put(GesturePassword.REMAINOPPORTUNITY, ""+times);database.update(publicSQLiteOpenHelper.GESTURE_PASSWORD,values, "WXID=?",new String[] { "001" });}else {values = new ContentValues();values.put(GesturePassword.WXID, "001");values.put(GesturePassword.PASSWORD, password);values.put(GesturePassword.REMAINOPPORTUNITY, ""+times);database.update(publicSQLiteOpenHelper.GESTURE_PASSWORD,values, "WXID=?",new String[] { "001" });}} catch (SQLException e) {} finally {if (values != null) {values.clear();values = null;}}}/*** 查询手势密码表有无记录* @return*/public boolean queryGestureTableCount(SQLiteDatabase database){Cursor cursor = null;try {cursor = database.query(publicSQLiteOpenHelper.GESTURE_PASSWORD, null, null, null, null, null, null);if (cursor != null && cursor.getCount()>0) {return true;}else {return false;}} catch (Exception e) {}finally{if (cursor != null) {cursor.close();cursor = null;}}return false;}/*** 查询手势密码表--查看剩余次数* */public String queryGestureTime(SQLiteDatabase database) {Cursor cursor = null;try {cursor = database.query(publicSQLiteOpenHelper.GESTURE_PASSWORD, null, null, null, null, null, null);if ((cursor != null) && (cursor.getCount() > 0)) {if (cursor.moveToFirst()) {int columnIndex = cursor.getColumnIndex(GesturePassword.REMAINOPPORTUNITY);return cursor.getString(columnIndex);}}} catch (Exception e) {} finally {if (cursor != null) {cursor.close();cursor = null;}}return "";}/*** 查询手势密码表--查看密码* */public String queryGesturePassword(SQLiteDatabase database) {Cursor cursor = null;try {cursor = database.query(publicSQLiteOpenHelper.GESTURE_PASSWORD, null, null, null, null, null, null);if ((cursor != null) && (cursor.getCount() > 0)) {if (cursor.moveToFirst()) {int columnIndex = cursor.getColumnIndex(GesturePassword.PASSWORD);return cursor.getString(columnIndex);}}} catch (Exception e) {} finally {if (cursor != null) {cursor.close();cursor = null;}}return "";}
}

接下里再看工具类把--就是输入的手势密码简单MD5加密、以及屏幕尺寸工具类

/*** */
package com.example.gesturelock;import android.content.Context;
import android.view.WindowManager;public class AppUtil {/*** 获取屏幕分辨�?* @param context* @return*/public static int[] getScreenDispaly(Context context) {WindowManager windowManager = (WindowManager) context.getSystemService(Context.WINDOW_SERVICE);@SuppressWarnings("deprecation")int width = windowManager.getDefaultDisplay().getWidth();@SuppressWarnings("deprecation")int height = windowManager.getDefaultDisplay().getHeight();int result[] = { width, height };return result;}}



package com.example.gesturelock;import java.security.MessageDigest;
import java.security.NoSuchAlgorithmException;import android.util.Log;public class MD5EncodeUtil {public static String MD5Ecode(String gesture){Log.i("GYL","gesture---"+gesture.toString());byte[] toencode=gesture.toString().getBytes();Log.i("GYL","byte[]----"+toencode.toString());try{MessageDigest md5=MessageDigest.getInstance("MD5");		md5.reset();md5.update(toencode);return HexEncode(md5.digest());}catch(NoSuchAlgorithmException e){e.printStackTrace();}return "";}public static String HexEncode(byte[] toencode){StringBuilder sb=new StringBuilder(toencode.length*2);for(byte b:toencode){sb.append(Integer.toHexString((b&0xf0)>>>4));sb.append(Integer.toHexString(b&0x0f));			}return sb.toString().toUpperCase();}
}

一步步来，接下来看bean类，就是每个圆点的属性

Constants

package com.example.gesturelock;public class Constants {public static final int POINT_STATE_NORMAL = 0; // 正常状态public static final int POINT_STATE_SELECTED = 1; // 按下状态public static final int POINT_STATE_WRONG = 2; // 错误状态}

GesturePoint

package com.example.gesturelock;import android.widget.ImageView;public class GesturePoint {/*** 左边x的值*/private int leftX;/*** 右边x的值*/private int rightX;/*** 上边y的值*/private int topY;/*** 下边y的值*/private int bottomY;/*** 这个点对应的ImageView控件*/private ImageView image;/*** 中心x值*/private int centerX;/*** 中心y值*/private int centerY;/*** 状态值*/private int pointState;/*** 代表这个Point对象代表的数字，从1开始(直接感觉从1开始)*/private int num;public GesturePoint(int leftX, int rightX, int topY, int bottomY,ImageView image, int num) {super();this.leftX = leftX;this.rightX = rightX;this.topY = topY;this.bottomY = bottomY;this.image = image;this.centerX = (leftX + rightX) / 2;this.centerY = (topY + bottomY) / 2;this.num = num;}public int getLeftX() {return leftX;}public void setLeftX(int leftX) {this.leftX = leftX;}public int getRightX() {return rightX;}public void setRightX(int rightX) {this.rightX = rightX;}public int getTopY() {return topY;}public void setTopY(int topY) {this.topY = topY;}public int getBottomY() {return bottomY;}public void setBottomY(int bottomY) {this.bottomY = bottomY;}public ImageView getImage() {return image;}public void setImage(ImageView image) {this.image = image;}public int getCenterX() {return centerX;}public void setCenterX(int centerX) {this.centerX = centerX;}public int getCenterY() {return centerY;}public void setCenterY(int centerY) {this.centerY = centerY;}public int getPointState() {return pointState;}public void setPointState(int state, int x, int y) {pointState = state;switch (state) {case Constants.POINT_STATE_NORMAL:this.image.setBackgroundResource(R.drawable.gesturewhite);break;case Constants.POINT_STATE_SELECTED:// 以原点为圆心，右下为正，左上为负if (y == 0 && x > 0) {this.image.setBackgroundResource(R.drawable.blueright);} else if (y == 0 && x < 0) {this.image.setBackgroundResource(R.drawable.blueleft);} else if (x == 0 && y > 0) {this.image.setBackgroundResource(R.drawable.bluedown);} else if (x == 0 && y < 0) {this.image.setBackgroundResource(R.drawable.blueup);} else if (x > 0 && y > 0) {this.image.setBackgroundResource(R.drawable.bluerightdown);} else if (x < 0 && y < 0) {this.image.setBackgroundResource(R.drawable.blueleftup);} else if (x < 0 && y > 0) {this.image.setBackgroundResource(R.drawable.blueleftdown);} else if (x > 0 && y < 0) {this.image.setBackgroundResource(R.drawable.bluerightup);} else if (x == 0 && y == 0) {this.image.setBackgroundResource(R.drawable.bluedot);}break;case Constants.POINT_STATE_WRONG:if (y == 0 && x > 0) {this.image.setBackgroundResource(R.drawable.redright);} else if (y == 0 && x < 0) {this.image.setBackgroundResource(R.drawable.redleft);} else if (x == 0 && y > 0) {this.image.setBackgroundResource(R.drawable.reddown);} else if (x == 0 && y < 0) {this.image.setBackgroundResource(R.drawable.redup);} else if (x > 0 && y > 0) {this.image.setBackgroundResource(R.drawable.redrightdown);} else if (x < 0 && y < 0) {this.image.setBackgroundResource(R.drawable.redleftup);} else if (x < 0 && y > 0) {this.image.setBackgroundResource(R.drawable.redleftdown);} else if (x > 0 && y < 0) {this.image.setBackgroundResource(R.drawable.redrightup);} else if (x == 0 && y == 0) {this.image.setBackgroundResource(R.drawable.reddot);}break;default:break;}}public int getNum() {return num;}public void setNum(int num) {this.num = num;}@Overridepublic int hashCode() {final int prime = 31;int result = 1;result = prime * result + bottomY;result = prime * result + ((image == null) ? 0 : image.hashCode());result = prime * result + leftX;result = prime * result + rightX;result = prime * result + topY;return result;}@Overridepublic boolean equals(Object obj) {if (this == obj)return true;if (obj == null)return false;if (getClass() != obj.getClass())return false;GesturePoint other = (GesturePoint) obj;if (bottomY != other.bottomY)return false;if (image == null) {if (other.image != null)return false;} else if (!image.equals(other.image))return false;if (leftX != other.leftX)return false;if (rightX != other.rightX)return false;if (topY != other.topY)return false;return true;}@Overridepublic String toString() {return "Point [leftX=" + leftX + ", rightX=" + rightX + ", topY="+ topY + ", bottomY=" + bottomY + "]";}
}

接下来就看那9个点的绘制界面

GestureContentView

package com.example.gesturelock;import java.util.ArrayList;
import java.util.List;import com.example.gesturelock.GestureDrawline.GestureCallBack;import android.content.Context;
import android.view.View;
import android.view.ViewGroup;
import android.widget.ImageView;/*** 手势密码容器类**/
public class GestureContentView extends ViewGroup {/*** 每个点区域的宽度*/private int blockWidth;private int spacing ;/*** 声明一个集合用来封装坐标集合*/private List<GesturePoint> list;private Context context;private GestureDrawline gestureDrawline;/*** 包含9个ImageView的容器，初始化* @param context* @param isVerify 是否为校验手势密码* @param passWord 用户传入密码* @param callBack 手势绘制完毕的回调*/public GestureContentView(Context context, boolean isVerify,String passWord, GestureCallBack callBack) {super(context);this.blockWidth = dip2px(context,66f); //圆圈的直径dp值this.spacing = dip2px(context, 30f); //圆圈之间的距离dp值this.list = new ArrayList<GesturePoint>();this.context = context;// 添加9个图标addChild();// 初始化一个可以画线的viewgestureDrawline = new GestureDrawline(context, list, isVerify,passWord, callBack);}public static int dip2px(Context context, float dpValue) {// TODO Auto-generated method stubfinal float scale = context.getResources().getDisplayMetrics().density;return (int) (dpValue * scale + 0.5f);}private void addChild(){for (int i = 0; i < 9; i++) {ImageView image = new ImageView(context);image.setBackgroundResource(R.drawable.gesturewhite);			this.addView(image,new LayoutParams(blockWidth, blockWidth));invalidate();// 第几行int row = i / 3;// 第几列int col = i % 3;// 定义点的每个属性int leftX = col * blockWidth + col * spacing;int topY = row * blockWidth + row * spacing;int rightX = leftX + blockWidth;int bottomY = topY + blockWidth;//圆圈之间线的位置GesturePoint p = new GesturePoint(leftX, rightX, topY, bottomY, image,i+1);this.list.add(p);}}public void setParentView(ViewGroup parent){// 得到屏幕的宽度LayoutParams layoutParams = new LayoutParams(blockWidth * 3 + spacing * 2, blockWidth * 3 + spacing * 2);parent.addView(gestureDrawline,layoutParams);parent.addView(this,layoutParams);}@Overrideprotected void onLayout(boolean changed, int l, int t, int r, int b) {for (int i = 0; i < getChildCount(); i++) {//第几行int row = i/3;//第几列int col = i%3;View v = getChildAt(i);//用于绘制圆圈的位置，d表示X轴方向的偏移量，如果要上下移动整块手绘区域，则将top和bottom参数增加或减小一个合适的偏移量int leftX = col * blockWidth + col * spacing;int topY = row * blockWidth + row * spacing;int rightX = leftX + blockWidth;int bottomY = topY + blockWidth;v.layout(leftX, topY, rightX, bottomY)  ;}}@Overrideprotected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {super.onMeasure(widthMeasureSpec, heightMeasureSpec);}/*** 保留路径delayTime时间长* @param delayTime*/public void clearDrawlineState(long delayTime) {gestureDrawline.clearDrawlineState(delayTime);}}

然后继续看当手指连接时候，的那个绘制中间连线的代码

GestureDrawline

package com.example.gesturelock;import java.util.ArrayList;
import java.util.HashMap;
import java.util.List;
import java.util.Map;import android.annotation.SuppressLint;
import android.content.Context;import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.graphics.Canvas;
import android.graphics.Color;
import android.graphics.Paint;
import android.graphics.Paint.Style;
import android.graphics.PorterDuff;
import android.os.Handler;import android.util.Log;
import android.util.Pair;
import android.view.MotionEvent;
import android.view.View;/*** 手势密码路径绘制* */
public class GestureDrawline extends View {private int mov_x;// 声明起点坐标private int mov_y;private Paint paint;// 声明画笔private Canvas canvas;// 画布private Bitmap bitmap;// 位图private List<GesturePoint> list;// private List<Pair<GesturePoint, GesturePoint>> lineList;// 记录画过的线private Map<String, GesturePoint> autoCheckPointMap;// 自动选中的情况点private boolean isDrawEnable = true; // 是否允许绘制/*** 屏幕的宽度和高度*/private int[] screenDispaly;private GesturePoint currentPoint;private GestureCallBack callBack;private StringBuilder passWordSb;private boolean isVerify;private String passWord;public GestureDrawline(Context context, List<GesturePoint> list,boolean isVerify, String passWord, GestureCallBack callBack) {super(context);//屏幕参数screenDispaly = AppUtil.getScreenDispaly(context);//画笔paint = new Paint(Paint.DITHER_FLAG);////初始化画布--宽高bitmap = Bitmap.createBitmap(screenDispaly[0], screenDispaly[0],Bitmap.Config.ARGB_8888); // canvas = new Canvas();canvas.setBitmap(bitmap);//设置画笔参数paint.setStyle(Style.STROKE);paint.setStrokeWidth(15);// paint.setColor(getResources().getColor(R.color.gestureline_green));// 设置默认连线颜色paint.setAntiAlias(true);//9个点的集合this.list = list;//画过的线集合this.lineList = new ArrayList<Pair<GesturePoint, GesturePoint>>();initAutoCheckPointMap();this.callBack = callBack;this.isVerify = isVerify;this.passWord = passWord;//密码集this.passWordSb = new StringBuilder();}private void initAutoCheckPointMap() {autoCheckPointMap = new HashMap<String, GesturePoint>();autoCheckPointMap.put("1,3", getGesturePointByNum(2));autoCheckPointMap.put("1,7", getGesturePointByNum(4));autoCheckPointMap.put("1,9", getGesturePointByNum(5));autoCheckPointMap.put("2,8", getGesturePointByNum(5));autoCheckPointMap.put("3,7", getGesturePointByNum(5));autoCheckPointMap.put("3,9", getGesturePointByNum(6));autoCheckPointMap.put("4,6", getGesturePointByNum(5));autoCheckPointMap.put("7,9", getGesturePointByNum(8));}/**得到对应的点位*/private GesturePoint getGesturePointByNum(int num) {for (GesturePoint point : list) {if (point.getNum() == num) {return point;}}return null;}/**将位图绘制到画布上*/@Overrideprotected void onDraw(Canvas canvas) {canvas.drawBitmap(bitmap, 0, 0, null);}// 触摸事件@SuppressLint("ClickableViewAccessibility")@Overridepublic boolean onTouchEvent(MotionEvent event) {if (isDrawEnable == false) {return true;}// 设置默认连线颜色paint.setColor(getResources().getColor(R.color.gestureline_green));switch (event.getAction()) {case MotionEvent.ACTION_DOWN:mov_x = (int) event.getX();mov_y = (int) event.getY();/**获取按下的点位*/currentPoint = getPointAt(mov_x, mov_y);if (currentPoint != null) {/**设置按下的点位的状态，保存密码*/currentPoint.setPointState(Constants.POINT_STATE_SELECTED, 0, 0);passWordSb.append(currentPoint.getNum());}invalidate();//回调方法callBack.onPointDown()  ;break;case MotionEvent.ACTION_MOVE://清楚痕迹clearScreenAndDrawList();//移动回调callBack.onGestureLineMove();//获取移动到的位置的点位GesturePoint pointAt = getPointAt((int) event.getX(),(int) event.getY());if (currentPoint == null && pointAt == null) {return true;} else {//由间隔处滑到原点处if (currentPoint == null && pointAt != null) {// 如果为空，那么把手指移动到的点赋值给currentPointcurrentPoint = pointAt;/**设置按下的点位的状态，保存密码*/currentPoint.setPointState(Constants.POINT_STATE_SELECTED,0, 0);passWordSb.append(currentPoint.getNum());}}/***/if (pointAt == null|| currentPoint.equals(pointAt)|| Constants.POINT_STATE_SELECTED == pointAt.getPointState()) {canvas.drawLine(currentPoint.getCenterX(),currentPoint.getCenterY(), event.getX(), event.getY(),paint);} else {int x = pointAt.getCenterX() - currentPoint.getCenterX();int y = pointAt.getCenterY() - currentPoint.getCenterY();currentPoint.setPointState(Constants.POINT_STATE_SELECTED, x, y);if (pointAt.equals(list.get(list.size() - 1))) {pointAt.setPointState(Constants.POINT_STATE_SELECTED, 0, 0);}GesturePoint betweenPoint = getBetweenCheckPoint(currentPoint,pointAt);if (betweenPoint != null&& Constants.POINT_STATE_SELECTED != betweenPoint.getPointState()) {// 存在中间点并且没有被选中Pair<GesturePoint, GesturePoint> pair1 = new Pair<GesturePoint, GesturePoint>(currentPoint, betweenPoint);lineList.add(pair1);passWordSb.append(betweenPoint.getNum());Pair<GesturePoint, GesturePoint> pair2 = new Pair<GesturePoint, GesturePoint>(betweenPoint, pointAt);lineList.add(pair2);passWordSb.append(pointAt.getNum());betweenPoint.setPointState(Constants.POINT_STATE_SELECTED,0, 0);currentPoint = pointAt;} else {Pair<GesturePoint, GesturePoint> pair = new Pair<GesturePoint, GesturePoint>(currentPoint, pointAt);lineList.add(pair);passWordSb.append(pointAt.getNum());currentPoint = pointAt;}}invalidate();break;case MotionEvent.ACTION_UP:isDrawEnable = false;if (isVerify) {// 手势密码校验String encodeString=MD5EncodeUtil.MD5Ecode(String.valueOf( passWordSb));String passwordMd5Ecode = MD5EncodeUtil.MD5Ecode(passWord);if (passwordMd5Ecode.equals(encodeString)) {callBack.checkedSuccess();} else {Log.e("TAG", "encode String fali");callBack.checkedFail();}} else {//重新绘制界面clearScreenAndDrawList();GesturePoint pointAtUp = getPointAt((int) event.getX(),(int) event.getY());if (pointAtUp != null&& currentPoint.equals(pointAtUp)&& Constants.POINT_STATE_SELECTED == pointAtUp.getPointState()&&passWordSb.length()==1) {currentPoint.setPointState(Constants.POINT_STATE_WRONG,0, 0);}invalidate();callBack.onGestureCodeInput(passWordSb.toString());}break;default:break;}return true;}/*** * @param delayTime*            延迟执行时间*/public void clearDrawlineState(long delayTime) {if (delayTime > 0) {// 绘制红色提示路线isDrawEnable = false;drawErrorPathTip();}new Handler().postDelayed(new clearStateRunnable(), delayTime);}/***/final class clearStateRunnable implements Runnable {public void run() {// 重置passWordSbpassWordSb = new StringBuilder();// 清空保存点的集合lineList.clear();// 重新绘制界面clearScreenAndDrawList();for (GesturePoint p : list) {p.setPointState(Constants.POINT_STATE_NORMAL, 0, 0);}invalidate();isDrawEnable = true;}}/*** * @param x* @param y*/private GesturePoint getPointAt(int x, int y) {for (GesturePoint point : list) {// 先判断xint leftX = point.getLeftX();int rightX = point.getRightX();if (!(x >= leftX && x < rightX)) {continue;}int topY = point.getTopY();int bottomY = point.getBottomY();if (!(y >= topY && y < bottomY)) {continue;}// 如果执行到这，那么说明当前点击的点的位置在遍历到点的位置这个地方return point;}return null;}private GesturePoint getBetweenCheckPoint(GesturePoint pointStart,GesturePoint pointEnd) {int startNum = pointStart.getNum();int endNum = pointEnd.getNum();String key = null;if (startNum < endNum) {key = startNum + "," + endNum;} else {key = endNum + "," + startNum;}return autoCheckPointMap.get(key);}/*** 清掉屏幕上所有的线，然后画出集合里面的线*/private void clearScreenAndDrawList() {canvas.drawColor(Color.TRANSPARENT, PorterDuff.Mode.CLEAR);for (int i = 0; i < lineList.size(); i++){int r = 0,x,y;if ((lineList.get(i).first.getTopY() - lineList.get(i).first.getBottomY()) / 2 < 0)r = -(lineList.get(i).first.getTopY() - lineList.get(i).first.getBottomY()) / 2;else {r = (lineList.get(i).first.getTopY() - lineList.get(i).first.getBottomY()) / 2;}float d = (float) 0.707 * r;x = lineList.get(i).second.getCenterX() -lineList.get(i).first.getCenterX();y = lineList.get(i).second.getCenterY() -lineList.get(i).first.getCenterY();if (i == lineList.size() - 1) {lineList.get(i).second.setPointState(Constants.POINT_STATE_SELECTED, 0, 0);lineList.get(i).first.setPointState(Constants.POINT_STATE_SELECTED, x, y);}else {lineList.get(i).first.setPointState(Constants.POINT_STATE_SELECTED, x, y);lineList.get(i).second.setPointState(Constants.POINT_STATE_SELECTED, x, y);}if (y == 0 && x > 0) {canvas.drawLine(lineList.get(i).first.getCenterX() + r,lineList.get(i).first.getCenterY(), lineList.get(i).second.getCenterX() - r,lineList.get(i).second.getCenterY(), paint);// 画线}else if (y == 0 && x < 0 ) {canvas.drawLine(lineList.get(i).first.getCenterX() - r,lineList.get(i).first.getCenterY(), lineList.get(i).second.getCenterX() + r,lineList.get(i).second.getCenterY(), paint);// 画线}else if (x == 0 && y > 0){canvas.drawLine(lineList.get(i).first.getCenterX(),lineList.get(i).first.getCenterY() + r, lineList.get(i).second.getCenterX(),lineList.get(i).second.getCenterY() - r, paint);// 画线}else if (x == 0 && y < 0 ) {				canvas.drawLine(lineList.get(i).first.getCenterX(),lineList.get(i).first.getCenterY() - r, lineList.get(i).second.getCenterX() ,lineList.get(i).second.getCenterY() + r, paint);// 画线}else if( x > 0 && y > 0 ){canvas.drawLine(lineList.get(i).first.getCenterX() + d,lineList.get(i).first.getCenterY() + d, lineList.get(i).second.getCenterX() - d ,lineList.get(i).second.getCenterY() - d, paint);// 画线}else if(x > 0 && y < 0 ){canvas.drawLine(lineList.get(i).first.getCenterX() + d,lineList.get(i).first.getCenterY() - d, lineList.get(i).second.getCenterX()-d ,lineList.get(i).second.getCenterY() + d, paint);// 画线				}else if (x < 0 && y > 0){canvas.drawLine(lineList.get(i).first.getCenterX() - d,lineList.get(i).first.getCenterY() + d, lineList.get(i).second.getCenterX()+d ,lineList.get(i).second.getCenterY() - d, paint);// 画线	}else if(x < 0 && y < 0 ){canvas.drawLine(lineList.get(i).first.getCenterX() - d,lineList.get(i).first.getCenterY() - d, lineList.get(i).second.getCenterX()+d ,lineList.get(i).second.getCenterY() + d, paint);// 画线	}}}private void drawErrorPathTip() {canvas.drawColor(Color.TRANSPARENT, PorterDuff.Mode.CLEAR);paint.setColor(getResources().getColor(R.color.gestureline_red));// 设置默认线路颜色if(lineList.size() == 0  && currentPoint!= null){currentPoint.setPointState(Constants.POINT_STATE_WRONG, 0, 0);}for (int i = 0; i < lineList.size(); i++) {			int r = 0,x,y;if ((lineList.get(i).first.getTopY() - lineList.get(i).first.getBottomY()) / 2 < 0)r = -(lineList.get(i).first.getTopY() - lineList.get(i).first.getBottomY()) / 2;else {r = (lineList.get(i).first.getTopY() - lineList.get(i).first.getBottomY()) / 2;}float d = (float) 0.707 * r;x = lineList.get(i).second.getCenterX() -lineList.get(i).first.getCenterX();y = lineList.get(i).second.getCenterY() -lineList.get(i).first.getCenterY();if (i == lineList.size() - 1) {lineList.get(i).second.setPointState(Constants.POINT_STATE_WRONG, 0, 0);lineList.get(i).first.setPointState(Constants.POINT_STATE_WRONG, x, y);}else {lineList.get(i).first.setPointState(Constants.POINT_STATE_WRONG, x, y);lineList.get(i).second.setPointState(Constants.POINT_STATE_WRONG, x, y);}if (y == 0 && x > 0) {canvas.drawLine(lineList.get(i).first.getCenterX() + r,lineList.get(i).first.getCenterY(), lineList.get(i).second.getCenterX() - r,lineList.get(i).second.getCenterY(), paint);// 画线}else if (y == 0 && x < 0 ) {canvas.drawLine(lineList.get(i).first.getCenterX() - r,lineList.get(i).first.getCenterY(), lineList.get(i).second.getCenterX() + r,lineList.get(i).second.getCenterY(), paint);// 画线}else if (x == 0 && y > 0){canvas.drawLine(lineList.get(i).first.getCenterX(),lineList.get(i).first.getCenterY() + r, lineList.get(i).second.getCenterX(),lineList.get(i).second.getCenterY() - r, paint);// 画线}else if (x == 0 && y < 0 ) {				canvas.drawLine(lineList.get(i).first.getCenterX(),lineList.get(i).first.getCenterY() - r, lineList.get(i).second.getCenterX() ,lineList.get(i).second.getCenterY() + r, paint);// 画线}else if( x > 0 && y > 0 ){canvas.drawLine(lineList.get(i).first.getCenterX() + d,lineList.get(i).first.getCenterY() + d, lineList.get(i).second.getCenterX() - d ,lineList.get(i).second.getCenterY() - d, paint);// 画线}else if(x > 0 && y < 0 ){canvas.drawLine(lineList.get(i).first.getCenterX() + d,lineList.get(i).first.getCenterY() - d, lineList.get(i).second.getCenterX()-d ,lineList.get(i).second.getCenterY() + d, paint);// 画线				}else if (x < 0 && y > 0){canvas.drawLine(lineList.get(i).first.getCenterX() - d,lineList.get(i).first.getCenterY() + d, lineList.get(i).second.getCenterX()+d ,lineList.get(i).second.getCenterY() - d, paint);// 画线	}else if(x < 0 && y < 0 ){canvas.drawLine(lineList.get(i).first.getCenterX() - d,lineList.get(i).first.getCenterY() - d, lineList.get(i).second.getCenterX()+d ,lineList.get(i).second.getCenterY() + d, paint);// 画线	}}invalidate();}public interface GestureCallBack {public abstract void onGestureCodeInput(String inputCode);public abstract void checkedSuccess();public abstract void checkedFail();public abstract void onGestureLineMove();public abstract void onPointDown() ;}}



ok 注备工作进行完毕，接下来看设置手势密码界面

gesture_edit.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"android:layout_width="match_parent"android:layout_height="match_parent"android:orientation="vertical"android:background="#f2f2f2" ><LinearLayoutandroid:id="@+id/ll_head"android:layout_width="fill_parent"android:layout_height="48dp"android:background="@drawable/bg_head"android:gravity="center_vertical"android:orientation="horizontal" ><LinearLayoutandroid:id="@+id/ll_head_left"android:layout_width="wrap_content"android:layout_height="fill_parent"android:layout_marginTop="1dp"android:gravity="center_vertical"android:background="@drawable/selector_head_back"android:orientation="horizontal" ><ImageViewandroid:id="@+id/im_back"android:layout_width="7dp"android:layout_height="14dp"android:layout_marginLeft="5dp"android:background="@drawable/back" /><TextViewandroid:layout_width="wrap_content"android:layout_height="wrap_content"android:layout_marginLeft="5dp"android:text="@string/set_gesture_code"android:textColor="#fff"android:textSize="17.33dp" /></LinearLayout><Viewandroid:layout_width="0dp"android:layout_height="fill_parent"android:layout_weight="1" /></LinearLayout><LinearLayoutandroid:id="@+id/gesture_tip_layout"android:layout_width="fill_parent"android:layout_height="wrap_content"android:layout_marginTop="75.67dp"android:orientation="vertical" ><TextViewandroid:id="@+id/tv_edit_texttip"android:layout_width="fill_parent"android:layout_height="wrap_content"android:gravity="center_horizontal"android:text="@string/set_gesture_pattern"android:textColor="@color/color_black"android:textSize="@dimen/textsize_s3" /></LinearLayout><RelativeLayoutandroid:id="@+id/fl_edit_gesture_container"android:layout_width="match_parent"android:layout_height="wrap_content"android:layout_marginTop="48dp"android:gravity="center_horizontal" ></RelativeLayout></LinearLayout>


GestureEditActivity

package com.example.gesturelock;import android.app.Activity;
import android.database.sqlite.SQLiteDatabase;
import android.os.Bundle;
import android.os.Handler;
import android.text.TextUtils;
import android.view.View;
import android.view.View.OnClickListener;
import android.widget.LinearLayout;
import android.widget.RelativeLayout;
import android.widget.TextView;import com.example.gesturelock.GestureDrawline.GestureCallBack;public class GestureEditActivity extends Activity implements OnClickListener {private LinearLayout im_back;private TextView tv_texttip;private RelativeLayout mGestureContainer;private GestureContentView mGestureContentView;// 第一次输入的密码private String mFirstPassword = null;// 是不是第一次输入private boolean mIsFirstInput = true;static final String TABLES_NAME_GESTURE = "gesture_password";public final static int GESTURE_TIME = 8;private publicSQLiteOpenHelper sqliteInstance;private SQLiteDatabase database;public void onCreate(Bundle savedInstanceState) {super.onCreate(savedInstanceState);setContentView(R.layout.gesture_edit);// 错误提示tv_texttip = (TextView) findViewById(R.id.tv_edit_texttip);// 9点区域mGestureContainer = (RelativeLayout) findViewById(R.id.fl_edit_gesture_container);// 返回im_back = (LinearLayout) findViewById(R.id.ll_head_left);// 初始化继续不可点击im_back.setOnClickListener(this);mGestureContentView = new GestureContentView(this, false, "",new GestureCallBack() {@Overridepublic void onGestureCodeInput(String inputCode) {if (mIsFirstInput) { // 第一次输入手势密码if (!isInputPassValidate(inputCode)) {// 至少连接4个点tv_texttip.setText(getResources().getString(R.string.drawguesturewarning));// 2秒后清除界面mGestureContentView.clearDrawlineState(2000L);// 2秒后还原提示mHandler.postDelayed(connect4Dot, 2000);return;}else {mFirstPassword = inputCode;tv_texttip.setText(getResources().getString(R.string.drawguestureagain));mHandler.postDelayed(clearGreenLine, 1000);mIsFirstInput = false;}} else {if (inputCode.equals(mFirstPassword)) { // 第二次输入手势密码与第一次一致tv_texttip.setText(getResources().getString(R.string.your_gesture_code));sqliteInstance = new publicSQLiteOpenHelper(GestureEditActivity.this);database = sqliteInstance.getWritableDatabase();boolean count = sqliteInstance.queryGestureTableCount(database);if (count) {//如果有记录sqliteInstance.updateGestureInfo(database,mFirstPassword, "8");}else {//如果没有记录sqliteInstance.insertGestureInfo(database,mFirstPassword, "8");}mHandler.postDelayed(setGestureOkFinish, 1000);} else {if (!isInputPassValidate(inputCode)) {// 至少连接4个点tv_texttip.setText(getResources().getString(R.string.drawguesturewarning));// 2秒后清除界面mGestureContentView.clearDrawlineState(2000L);// 2秒后还原提示mHandler.postDelayed(connect4Dot, 2000);} else { // 第二次输入手势密码与第一次不一致tv_texttip.setText(getResources().getString(R.string.drawagain));// 左右移动动画
//									 Animation shakeAnimation =
//									 AnimationUtils.loadAnimation(GestureEditActivity.this,R.anim.shake);
//									 tv_texttip.startAnimation(shakeAnimation);// 保持绘制的线，1.5秒后清除mGestureContentView.clearDrawlineState(2000L);mHandler.postDelayed(changeText2again, 2000);}}}}@Overridepublic void checkedFail() {}@Overridepublic void onGestureLineMove() {tv_texttip.setText(getResources().getString(R.string.release_hande_when_finish));}@Overridepublic void onPointDown() {}@Overridepublic void checkedSuccess() {}});// 设置手势解锁显示到哪个布局里面mGestureContentView.setParentView(mGestureContainer);}@Overrideprotected void onResume() {super.onResume();}Handler mHandler = new Handler();Runnable clearGreenLine = new Runnable() {public void run() {mGestureContentView.clearDrawlineState(0L);}};Runnable connect4Dot = new Runnable() {public void run() {tv_texttip.setText(getResources().getString(R.string.set_gesture_pattern));}};Runnable setGestureOkFinish = new Runnable() {public void run() {finish();}};Runnable changeText2again = new Runnable() {public void run() {tv_texttip.setText(getResources().getString(R.string.drawguestureagain));}};private boolean isInputPassValidate(String inputPassword) {if (TextUtils.isEmpty(inputPassword) || inputPassword.length() < 4) {return false;}return true;}protected void onDestroy() {super.onDestroy();}@Overridepublic void onClick(View v) {switch (v.getId()) {case R.id.ll_head_left:finish();break;}}
}

最后看校验界面

gesture_verify.xml

<?xml version="1.0" encoding="utf-8"?><LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"android:layout_width="match_parent"android:orientation="vertical"android:layout_height="match_parent"android:background="@color/color_main" ><LinearLayoutandroid:id="@+id/ll_head"android:layout_width="fill_parent"android:layout_height="48dp"android:background="@drawable/bg_head"android:gravity="center_vertical"android:orientation="horizontal" ><LinearLayoutandroid:id="@+id/ll_head_left"android:layout_width="wrap_content"android:layout_height="fill_parent"android:layout_marginTop="1dp"android:gravity="center_vertical"android:background="@drawable/selector_head_back"android:orientation="horizontal" ><ImageViewandroid:id="@+id/im_back"android:layout_width="7dp"android:layout_height="14dp"android:layout_marginLeft="5dp"android:background="@drawable/back" /><TextViewandroid:layout_width="wrap_content"android:layout_height="wrap_content"android:layout_marginLeft="5dp"android:text="@string/verify_gesture_code"android:textColor="#fff"android:textSize="17.33dp" /></LinearLayout><Viewandroid:layout_width="0dp"android:layout_height="fill_parent"android:layout_weight="1" /></LinearLayout><LinearLayoutandroid:id="@+id/gesture_tip_layout"android:layout_width="fill_parent"android:layout_height="wrap_content"android:layout_marginTop="75.67dp"android:orientation="vertical" ><TextViewandroid:id="@+id/tv_edit_texttip"android:layout_width="fill_parent"android:layout_height="wrap_content"android:gravity="center_horizontal"android:text="@string/set_gesture_pattern"android:textColor="@color/color_black"android:textSize="@dimen/textsize_s3" /></LinearLayout><RelativeLayoutandroid:id="@+id/fl_verify_gesture_container"android:layout_width="match_parent"android:layout_height="wrap_content"android:layout_marginTop="48dp"android:gravity="center_horizontal" ></RelativeLayout></LinearLayout>

最后校验代码

package com.example.gesturelock;import java.util.Timer;
import java.util.TimerTask;import android.annotation.SuppressLint;
import android.app.Activity;
import android.content.Intent;
import android.database.sqlite.SQLiteDatabase;
import android.os.Bundle;
import android.os.Handler;
import android.os.Message;
import android.text.TextUtils;
import android.util.Log;
import android.view.View;
import android.widget.LinearLayout;
import android.widget.RelativeLayout;
import android.widget.TextView;import com.example.gesturelock.GestureDrawline.GestureCallBack;public class GestureVerifyActivity extends Activity {private static String TAG = "GestureVerifyActivity";private TextView tv_texttip;private RelativeLayout mGestureContainer;private LinearLayout ib_back;private GestureContentView mGestureContentView;private Timer timer = new Timer() ;private TimerTask closeActivityTask = null;static final String TABLES_NAME_GESTURE = "gesture_password";private int remainopportunity ;private publicSQLiteOpenHelper sqliteInstance;private SQLiteDatabase database;private void resetCloseEvent(){clearCloseEvent() ;closeActivityTask = new TimerTask() {public void run() {Message message = new Message();message.what = 1;handler.sendMessage(message);}};timer.schedule(closeActivityTask, 30000); }private void clearCloseEvent(){if(closeActivityTask != null){closeActivityTask.cancel() ;closeActivityTask = null ;Log.i(TAG, "----------closeActivityTask----------"+closeActivityTask);}}public void onCreate(Bundle savedInstanceState) {super.onCreate(savedInstanceState);setContentView(R.layout.gesture_verify);resetCloseEvent(); tv_texttip = (TextView) findViewById(R.id.tv_edit_texttip);ib_back = (LinearLayout) findViewById(R.id.ll_head_left);mGestureContainer = (RelativeLayout) findViewById(R.id.fl_verify_gesture_container);sqliteInstance = new publicSQLiteOpenHelper(GestureVerifyActivity.this);database = sqliteInstance.getWritableDatabase();//从数据库中获取手势密码、剩余次数firstPassward = sqliteInstance.queryGesturePassword(database);remainopportunityStr = sqliteInstance.queryGestureTime(database);if (TextUtils.isEmpty(remainopportunityStr)) {remainopportunity = 8;//初始化8次sqliteInstance.updateGestureInfo(database,null, "8");} else {remainopportunity = Integer.parseInt(remainopportunityStr);}if(remainopportunity == 0){tv_texttip.setTextColor(getResources().getColor(R.color.gestureline_red));tv_texttip.setText(getResources().getString(R.string.no_chance));}ib_back.setOnClickListener(new View.OnClickListener() {@Overridepublic void onClick(View v) {finish();}});mGestureContentView = new GestureContentView(this, true, firstPassward,new GestureCallBack() {@Overridepublic void onGestureCodeInput(String inputCode) {}@SuppressLint("ShowToast")@Overridepublic void checkedSuccess() {sqliteInstance.updateGestureInfo(database,null, "8");mGestureContentView.clearDrawlineState(0L);resetCloseEvent();finish();//发送广播sendBroadcast(new Intent("com.godinsec.seland.intent.CASIntent.INTENT_LOAD_SD"));}@Overridepublic void checkedFail() {mGestureContentView.clearDrawlineState(2000L);tv_texttip.setTextColor(getResources().getColor(R.color.gestureline_red));if(remainopportunity > 0){remainopportunity-- ;}sqliteInstance.updateGestureInfo(database,null, ""+remainopportunity);resetCloseEvent();changeText();}@Overridepublic void onGestureLineMove() {if(remainopportunity > 0){tv_texttip.setTextColor(getResources().getColor(R.color.textcolor_black_bb));tv_texttip.setText(getResources().getString(R.string.release_hande_when_finish));}}@Overridepublic void onPointDown() {clearCloseEvent() ;}});mGestureContentView.setParentView(mGestureContainer);}protected void changeText() {Log.e("TAGG", "changeText");if (remainopportunity == 7) {tv_texttip.setText(getResources().getString(R.string.wrong_answer_seven));} else if (remainopportunity == 6) {tv_texttip.setText(getResources().getString(R.string.wrong_answer_six));} else if (remainopportunity == 5) {tv_texttip.setText(getResources().getString(R.string.wrong_answer_five));} else if (remainopportunity == 4) {tv_texttip.setText(getResources().getString(R.string.wrong_answer_four));} else if (remainopportunity == 3) {tv_texttip.setText(getResources().getString(R.string.wrong_answer_three));} else if (remainopportunity == 2) {tv_texttip.setText(getResources().getString(R.string.wrong_answer_two));} else if (remainopportunity == 1) {tv_texttip.setText(getResources().getString(R.string.wrong_answer_one));} else {tv_texttip.setText(getResources().getString(R.string.wrong_answer_zero));handler.postDelayed(errorFinish, 2000);}}@Overrideprotected void onResume() {super.onResume();}Runnable errorFinish = new Runnable() {public void run() {finish();}};@SuppressLint("HandlerLeak")Handler handler = new Handler() {@Overridepublic void handleMessage(Message msg) {super.handleMessage(msg);switch (msg.what) {case 1:finish();break;}}};private String remainopportunityStr;private String firstPassward;protected void onDestroy() {super.onDestroy();}protected void onStop() {super.onStop();}
}



这篇关于手势密码（四）的文章就介绍到这儿，希望我们推荐的文章对编程师们有所帮助！


http://www.chinasem.cn/article/1125322。
