装饰者模式的uml
- 通过继承和组合的方式来设计类的修饰作用
- 在继承的基础上,通过引用让对象具有多重修饰(拥有其他子类的方法)的特性。
这个类图是《Head first 设计模式》上的例子
装饰者的魔力主要在于CondimentDecorator的身上,它是抽象的装饰者类。继承CondimentDecorator在构造方法上都引用了Baverage抽象类。
抽象的Beverage类
public abstract class Beverage {//星巴兹咖啡店新增了小杯、中杯、大杯的咖啡规格。public static final int small = 1;public static final int middle = 2;public static final int large = 3;String description;private double sizeCost = 0D;private String sizeDescription = "";public void setSize(int size){if (size == small){sizeCost = 0.1;sizeDescription = "小杯";}else if (size == middle){sizeCost = 0.2;sizeDescription = "中杯";}else if (size == large){sizeCost = 0.3;sizeDescription = "大杯";}}public Double getSize(){return sizeCost;}public String getDescription(){return sizeDescription + this.description;}//不同的价格,由子类来说明public abstract Double cost();
}
不具有装饰的子类(只列举一个)
public class DarkRoast extends Beverage{public DarkRoast(){description = "深焙咖啡";}public Double cost() {return super.getSize() + 0.89;}
}
装饰者的抽象类
可以根据自身业务,来定义要实现的抽象方法
public abstract class CondimentDecorator extends Beverage{//对被装饰的了饮料的描述public abstract String getDescription();
}
具有装饰效果的子类
public class Mocha extends CondimentDecorator {//引入父类,让装饰者对象都有其父类的特性private Beverage beverage;private Mocha(){}public Mocha(Beverage beverage){this.beverage = beverage;}public String getDescription() {return this.beverage.getDescription() + ", 摩卡";}public Double cost() {return this.beverage.cost() + 0.2;}}
装饰者的魔力体验
public class DecoratorMain {public static void main(String[] args) {//来大杯的双倍摩卡综合咖啡Beverage beverage = new HouseBlend();beverage.setSize(3);beverage = new Mocha(beverage);beverage = new Mocha(beverage);System.out.println("描述:" + beverage.getDescription() + "。 价格:"+beverage.cost());}
}
以上将一个子类对象经过多重修饰,获得一个想要达到的目标。
javaIO中的装饰者模式设计
java对io操作的API中有根据读取方向分为输入流(InputStream)和输出流(OutputStream),我们从InputStream来开始分析。
InputStream的uml图
从java的io包中找出*InputStream类来对其进行uml设计关系的分析。
* 具有装饰功能的类都继承自FilterInputStream类,他们的子类都持有InputStream类的引用
* 其余的子类对象例如FileInputStream类和ByteArrayInputStream类都是正常的子类实现,直接继承自InputStream。
分析BufferedInputStream类
从调用入口开始入手分析
//inputStream只能按照字节来读取,因此读取中文的时候会出现乱码public void useBufferedInputStream() throws IOException {String str = "fdsggdsk";byte[] bytes = str.getBytes("utf-8");BufferedInputStream bis = new BufferedInputStream(new ByteArrayInputStream(bytes));int c ;StringBuffer sb = new StringBuffer();while ((c = bis.read()) >= 0 ){sb.append((char) c);}System.out.println("sb.toString() = " + sb.toString());}
这里创建了两个InputStream子类的实例
1. new ByteArrayInputStream(bytes)
2. new BufferedInputStream(new ByteArrayInputStream(bytes))
3. 调用BufferedInputStream的read方法
ByteArrayInputStream的read方法是一个字节一个字节的读取内容,而BufferInputStream的read方法,是将所有的字节缓冲到buf[]数组中,然后再依次读取
通过源码可以了解
public synchronized int read() throws IOException {
//先判断数组指针和count是否相等,如果pos == count,当使用
//read()方法读取到缓冲区的末尾时,会使用fill()方法再次预先读入
//一部分字节if (pos >= count) {fill();if (pos >= count)return -1;}return getBufIfOpen()[pos++] & 0xff;}
byte[] buffer = getBufIfOpen();if (markpos < 0)pos = 0; /* no mark: throw away the buffer */else if (pos >= buffer.length) /* no room left in buffer */if (markpos > 0) { /* can throw away early part of the buffer */int sz = pos - markpos;System.arraycopy(buffer, markpos, buffer, 0, sz);pos = sz;markpos = 0;} else if (buffer.length >= marklimit) {markpos = -1; /* buffer got too big, invalidate mark */pos = 0; /* drop buffer contents */} else if (buffer.length >= MAX_BUFFER_SIZE) {throw new OutOfMemoryError("Required array size too large");} else { /* grow buffer */int nsz = (pos <= MAX_BUFFER_SIZE - pos) ?pos * 2 : MAX_BUFFER_SIZE;if (nsz > marklimit)nsz = marklimit;byte nbuf[] = new byte[nsz];System.arraycopy(buffer, 0, nbuf, 0, pos);if (!bufUpdater.compareAndSet(this, buffer, nbuf)) {// Can't replace buf if there was an async close.// Note: This would need to be changed if fill()// is ever made accessible to multiple threads.// But for now, the only way CAS can fail is via close.// assert buf == null;throw new IOException("Stream closed");}buffer = nbuf;}count = pos;//这里调用InputStream的read方法,哪个子类实现该方法,//就调用它的实现。例如ByteArrayInputStream.read()int n = getInIfOpen().read(buffer, pos, buffer.length - pos);if (n > 0)count = n + pos;
以上就是javaIO的装饰模式的实现例子。我们也可以通过集成字FilterInputStream来特定的IO读取方式。
实现一个将大写字母转换成小写的InputStream
LowerCaseInputStream类的实现
简单的实现,只实现了read()和read(byte[] b, int off, int len) 方法就可以了
public class LowerCaseInputStream extends FilterInputStream {/*** Creates a <code>FilterInputStream</code>* by assigning the argument <code>in</code>* to the field <code>this.in</code> so as* to remember it for later use.** @param in the underlying input stream, or <code>null</code> if* this instance is to be created without an underlying stream.*/protected LowerCaseInputStream(InputStream in) {super(in);}@Overridepublic int read() throws IOException {int read = super.read();return read == -1 ? -1 : Character.toLowerCase((char)read);}@Overridepublic int read(byte[] b, int off, int len) throws IOException {int read = super.read(b, off, len);for (int i = off; i < off + len; i++){b[i] = (byte) Character.toLowerCase((char) b[i]);}return read;}
}
参考博客
http://blog.csdn.net/songwei128/article/details/23355045
