layout文件夹下代码
f1.xml(被加载到fragment上)
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"android:layout_width="match_parent"android:layout_height="match_parent"android:orientation="vertical" ><TextViewandroid:id="@+id/textView1"android:layout_width="wrap_content"android:layout_height="wrap_content"android:text="文件管理"android:layout_marginTop="100dp"android:layout_marginLeft="20dp"android:textSize="25sp" /></LinearLayout>
f2.xml(被加载到fragment上)
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"android:layout_width="match_parent"android:layout_height="match_parent"android:orientation="vertical" ><TextViewandroid:id="@+id/textView1"android:layout_width="wrap_content"android:layout_height="wrap_content"android:text="用户管理"android:layout_marginTop="100dp"android:layout_marginLeft="20dp"android:textSize="25sp" /></LinearLayout>
f3.xml(被加载到fragment上)
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"android:layout_width="match_parent"android:layout_height="match_parent"android:orientation="vertical" ><TextViewandroid:id="@+id/textView1"android:layout_width="wrap_content"android:layout_height="wrap_content"android:text="产品管理"android:layout_marginTop="100dp"android:layout_marginLeft="20dp"android:textSize="25sp" /></LinearLayout>
f4.xml(被加载到fragment上)
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"android:layout_width="match_parent"android:layout_height="match_parent"android:orientation="vertical" ><TextViewandroid:id="@+id/textView1"android:layout_width="wrap_content"android:layout_height="wrap_content"android:text="资源管理"android:layout_marginTop="100dp"android:layout_marginLeft="20dp"android:textSize="25sp" /></LinearLayout>
Fragment1 extends fragment 其余三个和他相同
Fragment1.java 代码
package com.example.android_fragment_backstack;import android.app.Fragment;
import android.os.Bundle;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;public class Fragment1 extends Fragment {@Overridepublic void onCreate(Bundle savedInstanceState) {// TODO Auto-generated method stubsuper.onCreate(savedInstanceState);}@Overridepublic View onCreateView(LayoutInflater inflater, ViewGroup container,Bundle savedInstanceState) {// TODO Auto-generated method stubView view=inflater.inflate(R.layout.f1, null);return view;}@Overridepublic void onPause() {// TODO Auto-generated method stubsuper.onPause();}
}
activity_main.xml 代码文件（主要是两个布局）
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"xmlns:tools="http://schemas.android.com/tools"android:layout_width="match_parent"android:layout_height="match_parent"android:orientation="horizontal"tools:context=".MainActivity" ><LinearLayoutandroid:id="@+id/left"android:layout_weight="1"android:layout_width="0dp"android:layout_height="match_parent"android:orientation="vertical"android:background="#cccccc"><Buttonandroid:id="@+id/button1"android:layout_width="wrap_content"android:layout_height="wrap_content"android:text="文件管理" /><Buttonandroid:id="@+id/button2"android:layout_width="wrap_content"android:layout_height="wrap_content"android:text="用户管理" /><Buttonandroid:id="@+id/button3"android:layout_width="wrap_content"android:layout_height="wrap_content"android:text="产品管理" /><Buttonandroid:id="@+id/button4"android:layout_width="wrap_content"android:layout_height="wrap_content"android:text="资源管理" /></LinearLayout><LinearLayoutandroid:layout_weight="3"android:id="@+id/center"android:background="#0fffff"android:layout_width="0dp"android:layout_height="match_parent"android:orientation="vertical" ></LinearLayout></LinearLayout>
MainActivity.java代码
package com.example.android_fragment_backstack;import android.os.Bundle;
import android.app.Activity;
import android.app.FragmentManager;
import android.app.FragmentTransaction;
import android.view.Menu;
import android.view.View;
import android.view.View.OnClickListener;
import android.widget.Button;public class MainActivity extends Activity implements OnClickListener {private FragmentManager manager;private FragmentTransaction transaction;private Button button1,button2,button3,button4;@Overrideprotected void onCreate(Bundle savedInstanceState) {super.onCreate(savedInstanceState);setContentView(R.layout.activity_main);button1=(Button)findViewById(R.id.button1);button2=(Button)findViewById(R.id.button2);button3=(Button)findViewById(R.id.button3);button4=(Button)findViewById(R.id.button4);button1.setOnClickListener(this);button2.setOnClickListener(this);button3.setOnClickListener(this);button4.setOnClickListener(this);manager = this.getFragmentManager();}@Overridepublic boolean onCreateOptionsMenu(Menu menu) {// Inflate the menu; this adds items to the action bar if it is present.getMenuInflater().inflate(R.menu.main, menu);return true;}@Overridepublic void onClick(View v) {// TODO Auto-generated method stubtransaction = manager.beginTransaction();switch (v.getId()) {case R.id.button1:Fragment1 f1=new Fragment1();transaction.replace(R.id.center, f1,"fragment1");transaction.addToBackStack("fragment1");//添加到Activity管理的回退栈中break;case R.id.button2:Fragment2 f2=new Fragment2();transaction.replace(R.id.center, f2,"fragment2");transaction.addToBackStack("fragment2");//添加到Activity管理的回退栈中break;case R.id.button3:Fragment3 f3=new Fragment3();transaction.replace(R.id.center, f3,"fragment3");transaction.addToBackStack("fragment3");//添加到Activity管理的回退栈中break;case R.id.button4:Fragment4 f4=new Fragment4();transaction.replace(R.id.center, f4,"fragment4");transaction.addToBackStack("fragment4");//添加到Activity管理的回退栈中break;default:break;}transaction.commit();}}
