ActivityManagerService(简称AMS)ActivityManagerNative(简称AMN)
WindowManagerService(简称WMS)
*******************************************************************************************************************************************
system_server.java::ServerThread
context = ActivityManagerService.main(factoryTest) //1调用main函数，得到一个Context对象
ActivityManagerService.setSystemProcess(); //2setSystemProcess：这样system_server进程可加到AMS中，并被它管理
ActivityManagerService.installSystemProviders(); //3installSystemProviders：将SettingsProvider放到system_server进程中来运行
ActivityManagerService.self().setWindowManager(wm); //4在内部保存WindowManagerService(以后简称WMS)
ActivityManagerNative.getDefault().showBootMessage( //5和WMS交互，弹出“启动进度”对话框
context.getResources().getText(
com.android.internal.R.string.android_upgrading_starting_apps),
false);
ActivityManagerService.self().systemReady(new Runnable() {......} //6AMS是系统的核心，只有它准备好了才能调用其他服务的systemReady
1、调用main函数，得到一个Context对象（ActivityManagerService.java）
public static final Context main(int factoryTest){
AThread thr = new AThread(); //1创建一个AThread线程对象
thr.start();
...... //等待thr创建成功
ActivityManagerService m = thr.mService;
mSelf = m;
//2调用ActivityThread的systemMain函数
ActivityThread at = ActivityThread.systemMain();
mSystemThread = at;
//3得到一个Context对象，注意是用的是getSystemContext
Context context = at.getSystemContext();
context.setTheme(android.R.style.Theme_Holo);
m.mContext = context;
m.mFactoryTest = factoryTest;
//ActivityStack是AMS中用来管理Activity的启动和调度的核心类，以后再分析它
m.mMainStack = new ActivityStack(m, context, true);
//调用BSS的publish（第五章中讲过了）
m.mBatteryStatsService.publish(context);
//另一个Service
m.mUsageStatsService.publish(context);
synchronized (thr) {
thr.mReady = true;
thr.notifyAll(); //通知thr线程，本线程工作完成
}
//4调用AMS的startRunning函数
m.startRunning(null, null, null, null);
return context;
}
说明：
AMS自己的工作在AThread线程中做，
main函数首先需要等待AThread所在线程启动并完成一部分工作；
AThread完成那一部分工作后，等待main函数完成后续工作。
1.1 AThread分析
1.1_1 AThread分析
ActivityManagerService.java::AThread
static class AThread extends Thread {
......
public void run() {
......
ActivityManagerService m = new ActivityManagerService();
......
}
}
AThread的主要工作就是创建AMS对象，然后通知AMS的main函数。
1.1_2 AMS的构造函数分析
ActivityManagerService.java::ActivityManagerService
private ActivityManagerService() {
Slog.i(TAG, "Memory class: " + ActivityManager.staticGetMemoryClass());
mFgBroadcastQueue = new BroadcastQueue(this, "foreground", BROADCAST_FG_TIMEOUT);
mBgBroadcastQueue = new BroadcastQueue(this, "background", BROADCAST_BG_TIMEOUT);
mBroadcastQueues[0] = mFgBroadcastQueue;
mBroadcastQueues[1] = mBgBroadcastQueue;
mServices = new ActiveServices(this);
mProviderMap = new ProviderMap(this);
File dataDir = Environment.getDataDirectory();
File systemDir = new File(dataDir, "system");
systemDir.mkdirs();
mBatteryStatsService = new BatteryStatsService(new File(
systemDir, "batterystats.bin").toString());
mBatteryStatsService.getActiveStatistics().readLocked();
mBatteryStatsService.getActiveStatistics().writeAsyncLocked();
mOnBattery = DEBUG_POWER ? true
: mBatteryStatsService.getActiveStatistics().getIsOnBattery();
mBatteryStatsService.getActiveStatistics().setCallback(this);
mUsageStatsService = new UsageStatsService(new File(
systemDir, "usagestats").toString());
mHeadless = "1".equals(SystemProperties.get("ro.config.headless", "0"));
// User 0 is the first and only user that runs at boot.
mStartedUsers.put(0, new UserStartedState(new UserHandle(0), true));
mUserLru.add(Integer.valueOf(0));
updateStartedUserArrayLocked();
GL_ES_VERSION = SystemProperties.getInt("ro.opengles.version",
ConfigurationInfo.GL_ES_VERSION_UNDEFINED);
mConfiguration.setToDefaults();
mConfiguration.setLocale(Locale.getDefault());
mConfigurationSeq = mConfiguration.seq = 1;
mProcessStats.init();
mCompatModePackages = new CompatModePackages(this, systemDir);
// Add ourself to the Watchdog monitors.
Watchdog.getInstance().addMonitor(this);
mProcessStatsThread = new Thread("ProcessStats") {
public void run() {
while (true) {
try {
try {
synchronized(this) {
final long now = SystemClock.uptimeMillis();
long nextCpuDelay = (mLastCpuTime.get()+MONITOR_CPU_MAX_TIME)-now;
long nextWriteDelay = (mLastWriteTime+BATTERY_STATS_TIME)-now;
//Slog.i(TAG, "Cpu delay=" + nextCpuDelay
// + ", write delay=" + nextWriteDelay);
if (nextWriteDelay < nextCpuDelay) {
nextCpuDelay = nextWriteDelay;
}
if (nextCpuDelay > 0) {
mProcessStatsMutexFree.set(true);
this.wait(nextCpuDelay);
}
}
} catch (InterruptedException e) {
}
updateCpuStatsNow();
} catch (Exception e) {
Slog.e(TAG, "Unexpected exception collecting process stats", e);
}
}
}
};
mProcessStatsThread.start();
}
一些初始化创建等：
a、创建BSS、USS、mProcessStats、mProcessStatsThread线程，这些都是与系统运行状况统计相关。
b、创建/data/system目录，为mCompatModePackages和mConfiguration等成员赋值。
1.2 ActivityThread.systemMain函数分析
ActivityThread是Framework中一个非常重要的类，它代表一个应用进程的主线程，其职责就是调度及执行在该线程中运行的四大组件。
public static ActivityThread systemMain() {
HardwareRenderer.disable(true); //禁止硬件加速
ActivityThread thread = new ActivityThread(); //空构造函数
thread.attach(true);
return thread;
}
这里主要做了 禁止硬件加速和创建自己并调用了attach函数。
private void attach(boolean system) {
sThreadLocal.set(this);
mSystemThread = system;
if (!system) {
//应用进程处理流程
} else {
android.ddm.DdmHandleAppName.setAppName("system_process", //systemserver的进程名
UserHandle.myUserId());
try {
mInstrumentation = new Instrumentation(); //Instrumentation 工具类
ContextImpl context = new ContextImpl(); //
context.init(getSystemContext().mPackageInfo, null, this); //为什么getSystemContext
Application app = Instrumentation.newApplication(Application.class, context); //利用Instrumentation创建Application
mAllApplications.add(app);
mInitialApplication = app;
app.onCreate(); //调用app的oncreate函数
} catch (Exception e) {
throw new RuntimeException(
"Unable to instantiate Application():" + e.toString(), e);
}
}
// add dropbox logging to libcore
DropBox.setReporter(new DropBoxReporter()); //==========后续=======
ViewRootImpl.addConfigCallback(new ComponentCallbacks2() {
public void onConfigurationChanged(Configuration newConfig) {
//当系统配置发生变化时调用（如语言切换）
}
public void onLowMemory() {}
public void onTrimMemory(int level) {}
});
}
attach函数中几个重要成员的作用：
a、Instrumentation：当app被启用时先创建Instrumentation，然后通过它来创建其他组件，系统和组件之间的交互也通过Instrumentation来传递。Instrumentation 能监控这些交互情况。
b、Application：Application保存了一个全局的Application状态。
c、Context：Context是一个接口，通过它可以获取并操作Application的资源、类及Application的四大组件。
public ContextImpl getSystemContext() {
synchronized (this) {
if (mSystemContext == null) {
ContextImpl context =
ContextImpl.createSystemContext(this);
LoadedApk info = new LoadedApk(this, "android", context, null,
CompatibilityInfo.DEFAULT_COMPATIBILITY_INFO); //LoadedApk代表一个加载到系统的apk
context.init(info, null, this); //初始化ContextImpl对象
context.getResources().updateConfiguration( //初始化资源信息
getConfiguration(), getDisplayMetricsLocked(
Display.DEFAULT_DISPLAY,
CompatibilityInfo.DEFAULT_COMPATIBILITY_INFO));
mSystemContext = context; //保存
//Slog.i(TAG, "Created system resources " + context.getResources()
// + ": " + context.getResources().getConfiguration());
}
}
return mSystemContext;
}
以上代码先创建一个ContextImpl，然后初始化，使用getSystemContext命名因为其要加载的是framework-res.apk，此apk的package名为“android”，仅供system_server使用。
systemMain总结：
a、得到一个ActivityThread对象，代表应用进程主线程
b、得到Context对象，指向其运行环境。使得system_server<==>AMS
1.3 AMS的startrunning函数：
ActivityManagerService.java::startrunning
public final void startRunning(String pkg, String cls, String action,
String data) {
synchronized(this) {
if (mStartRunning) {
return;
}
mStartRunning = true;
mTopComponent = pkg != null && cls != null
? new ComponentName(pkg, cls) : null;
mTopAction = action != null ? action : Intent.ACTION_MAIN;
mTopData = data;
if (!mSystemReady) {
return;
}
}
systemReady(null); //重要 后续说明
}
ActivityManagerService的main总结：
a、创建AMS
b、为system_server配置android运行环境
2、AMS的setSystemProcess
ActivityManagerService.java::setSystemProcess
public static void setSystemProcess() {
try {
ActivityManagerService m = mSelf;
//向ServiceManager注册几个服务
ServiceManager.addService("activity", m, true);
ServiceManager.addService("meminfo", new MemBinder(m));
ServiceManager.addService("gfxinfo", new GraphicsBinder(m));
ServiceManager.addService("dbinfo", new DbBinder(m));
if (MONITOR_CPU_USAGE) {
ServiceManager.addService("cpuinfo", new CpuBinder(m));
}
ServiceManager.addService("permission", new PermissionController(m)); //向SM注册权限管理服务
ApplicationInfo info = //使用AMS的mContext对象
mSelf.mContext.getPackageManager().getApplicationInfo(
"android", STOCK_PM_FLAGS);
mSystemThread.installSystemApplicationInfo(info); //调用ystemThread的installSystemApplicationInfo函数
synchronized (mSelf) {
ProcessRecord app = mSelf.newProcessRecordLocked( //AMS对进程的管理
mSystemThread.getApplicationThread(), info,
info.processName, false);
app.persistent = true;
app.pid = MY_PID;
app.maxAdj = ProcessList.SYSTEM_ADJ;
mSelf.mProcessNames.put(app.processName, app.uid, app);
synchronized (mSelf.mPidsSelfLocked) {
mSelf.mPidsSelfLocked.put(app.pid, app);
}
mSelf.updateLruProcessLocked(app, true);
}
} catch (PackageManager.NameNotFoundException e) {
throw new RuntimeException(
"Unable to find android system package", e);
}
}
2.1 installSystemApplicationInfo
ActivityThread.java::installSystemApplicationInfo
public void installSystemApplicationInfo(ApplicationInfo info) {
synchronized (this) {
ContextImpl context = getSystemContext();
context.init(new LoadedApk(this, "android", context, info, //此次真正给context设置info
CompatibilityInfo.DEFAULT_COMPATIBILITY_INFO), null, this);
// give ourselves a default profiler //用于性能统计
mProfiler = new Profiler();
}
}
插入说明5
IApplicationThread仅仅是AMS和另一个进程交互的接口，AMS还需要该进程的信息，用ProcessRecord数据结构来保存进程信息。
ActivityManagerService.java::newProcessRecordLocked
final ProcessRecord newProcessRecordLocked(IApplicationThread thread,
ApplicationInfo info, String customProcess, boolean isolated) {
String proc = customProcess != null ? customProcess : info.processName;
BatteryStatsImpl.Uid.Proc ps = null;
BatteryStatsImpl stats = mBatteryStatsService.getActiveStatistics();
int uid = info.uid;
if (isolated) {
int userId = UserHandle.getUserId(uid);
int stepsLeft = Process.LAST_ISOLATED_UID - Process.FIRST_ISOLATED_UID + 1;
uid = 0;
while (true) {
if (mNextIsolatedProcessUid < Process.FIRST_ISOLATED_UID
|| mNextIsolatedProcessUid > Process.LAST_ISOLATED_UID) {
mNextIsolatedProcessUid = Process.FIRST_ISOLATED_UID;
}
uid = UserHandle.getUid(userId, mNextIsolatedProcessUid);
mNextIsolatedProcessUid++;
if (mIsolatedProcesses.indexOfKey(uid) < 0) {
// No process for this uid, use it.
break;
}
stepsLeft--;
if (stepsLeft <= 0) {
return null;
}
}
}
synchronized (stats) {
ps = stats.getProcessStatsLocked(info.uid, proc);
}
return new ProcessRecord(ps, thread, info, proc, uid);
}
看看构造函数：
ProcessRecord.java::ProcessRecord
ProcessRecord(BatteryStatsImpl.Uid.Proc _batteryStats, IApplicationThread _thread,
ApplicationInfo _info, String _processName, int _uid) {
batteryStats = _batteryStats;
info = _info; //保存最开始启动的ApplicationInfo
isolated = _info.uid != _uid;
uid = _uid;
userId = UserHandle.getUserId(_uid);
processName = _processName; //system_process
pkgList.add(_info.packageName); //
thread = _thread;
maxAdj = ProcessList.HIDDEN_APP_MAX_ADJ;
hiddenAdj = clientHiddenAdj = emptyAdj = ProcessList.HIDDEN_APP_MIN_ADJ;
curRawAdj = setRawAdj = -100;
curAdj = setAdj = -100;
persistent = false;
removed = false;
}
在上述ActivityManagerService.java::setSystemProcess 中还设置了：
app.persistent = true;
app.pid = MY_PID;
app.maxAdj = ProcessList.SYSTEM_ADJ;
至此system_srver的ProcessRecord创建完成。AMS中有两个成员变量来保存ProcessRecord，mProcessNames和mPidsSelfLocked(各自用途情况？？？)
AMS的setSystemProcess总结：
a、注册AMS，meminfo,gfxinfo等服务到SM
b、根据PKMS返回的ApplicationInfo初始化system_server的android运行环境。
3. AMS的installSystemProviders分析
installSystemProviders加载的是SettingsProvider.apk,并把它放在system_server进程中来运行。
ActivityManagerService.java::installSystemProviders
public static final void installSystemProviders() {
List<ProviderInfo> providers;
synchronized (mSelf) {
ProcessRecord app = mSelf.mProcessNames.get("system", Process.SYSTEM_UID);
providers = mSelf.generateApplicationProvidersLocked(app);
if (providers != null) {
for (int i=providers.size()-1; i>=0; i--) {
ProviderInfo pi = (ProviderInfo)providers.get(i);
if ((pi.applicationInfo.flags&ApplicationInfo.FLAG_SYSTEM) == 0) {
Slog.w(TAG, "Not installing system proc provider " + pi.name
+ ": not system .apk");
providers.remove(i);
}
}
}
}
if (providers != null) {
mSystemThread.installSystemProviders(providers);
}
mSelf.mCoreSettingsObserver = new CoreSettingsObserver(mSelf); //监视long_press_timeout配置的变化
mSelf.mUsageStatsService.monitorPackages();
}
上述代码中有两个关键调用：
a、调用 generateApplicationProvidersLocked 返回ProviderInfo List
b、调用 installSystemProviders ，为system_server进程安装contextProvider。
2.1 generateApplicationProvidersLocked
ActivityManagerService.java::generateApplicationProvidersLocked
private final List<ProviderInfo> generateApplicationProvidersLocked(ProcessRecord app) {
List<ProviderInfo> providers = null;
try {
providers = AppGlobals.getPackageManager(). //想PKMS查询满足条件的ProviderInfo
queryContentProviders(app.processName, app.uid,
STOCK_PM_FLAGS | PackageManager.GET_URI_PERMISSION_PATTERNS);
} catch (RemoteException ex) {
}
if (DEBUG_MU)
Slog.v(TAG_MU, "generateApplicationProvidersLocked, app.info.uid = " + app.uid);
int userId = app.userId;
if (providers != null) {
int N = providers.size();
for (int i=0; i<N; i++) { //AMS对ContextProvider的管理
ProviderInfo cpi =
(ProviderInfo)providers.get(i);
boolean singleton = isSingleton(cpi.processName, cpi.applicationInfo,
cpi.name, cpi.flags);
if (singleton && UserHandle.getUserId(app.uid) != 0) {
// This is a singleton provider, but a user besides the
// default user is asking to initialize a process it runs
// in... well, no, it doesn't actually run in this process,
// it runs in the process of the default user. Get rid of it.
providers.remove(i);
N--;
continue;
}
ComponentName comp = new ComponentName(cpi.packageName, cpi.name);
ContentProviderRecord cpr = mProviderMap.getProviderByClass(comp, userId);
if (cpr == null) {
cpr = new ContentProviderRecord(this, cpi, app.info, comp, singleton);
mProviderMap.putProviderByClass(comp, cpr);
}
if (DEBUG_MU)
Slog.v(TAG_MU, "generateApplicationProvidersLocked, cpi.uid = " + cpr.uid);
app.pubProviders.put(cpi.name, cpr);
app.addPackage(cpi.applicationInfo.packageName);
ensurePackageDexOpt(cpi.applicationInfo.packageName);
}
}
return providers;
}
generateApplicationProvidersLocked 先从PKMS中查到满足条件的ProviderInfo信息，然后分别保存到ProcessRecord（ app）和AMS(mProviderMap)中。
2.1_1 queryContentProviders 查询
public List<ProviderInfo> queryContentProviders(String processName,
int uid, int flags) {
ArrayList<ProviderInfo> finalList = null;
// reader
synchronized (mPackages) {
final Iterator<PackageParser.Provider> i = mProvidersByComponent.values().iterator();
final int userId = processName != null ?
UserHandle.getUserId(uid) : UserHandle.getCallingUserId();
while (i.hasNext()) {
final PackageParser.Provider p = i.next();
PackageSetting ps = mSettings.mPackages.get(p.owner.packageName);
if (ps != null && p.info.authority != null
&& (processName == null
|| (p.info.processName.equals(processName)
&& UserHandle.isSameApp(p.info.applicationInfo.uid, uid)))
&& mSettings.isEnabledLPr(p.info, flags, userId)
&& (!mSafeMode
|| (p.info.applicationInfo.flags & ApplicationInfo.FLAG_SYSTEM) != 0)) {
if (finalList == null) {
finalList = new ArrayList<ProviderInfo>(3);
}
ProviderInfo info = PackageParser.generateProviderInfo(p, flags,
ps.readUserState(userId), userId);
if (info != null) {
finalList.add(info);
}
}
}
}
if (finalList != null) {
Collections.sort(finalList, mProviderInitOrderSorter);
}
return finalList;
}
queryContentProviders为什么能找到SettingsProvider呢？
因为：SettingsProvider的Manifest.xml中设置了uid为system_server，process名为system。
2.1_2 ContentProvider
前面queryContentProviders查找到的ProviderInfo信息只是保存起来了，还需要将其与AMS和ProcessRecord联系起来
a、AMS保存的原因就是为了管理
b、ProcessRecord保存是ProviderInfo要与一个进程联系起来，以便方便AMS管理。
图：《ContentProvideRecord团队》
2.2 ActivityThread的installSystemProviders函数
ActivityThread.java::installSystemProviders -------> installContentProviders
private void installContentProviders(
Context context, List<ProviderInfo> providers) {
final ArrayList<IActivityManager.ContentProviderHolder> results =
new ArrayList<IActivityManager.ContentProviderHolder>();
for (ProviderInfo cpi : providers) {
if (DEBUG_PROVIDER) {
StringBuilder buf = new StringBuilder(128);
buf.append("Pub ");
buf.append(cpi.authority);
buf.append(": ");
buf.append(cpi.name);
Log.i(TAG, buf.toString());
}
IActivityManager.ContentProviderHolder cph = installProvider(context, null, cpi,
false /*noisy*/, true /*noReleaseNeeded*/, true /*stable*/);
if (cph != null) {
cph.noReleaseNeeded = true;
results.add(cph);
}
}
try {
ActivityManagerNative.getDefault().publishContentProviders(
getApplicationThread(), results);
} catch (RemoteException ex) {
}
}
installContentProviders实际上是标准的ContentProvider安装时调用的程序
其包括两个方面的工作：
a、先在ActivityThread通过installProvider得到一个ContentProvider实例
b、向AMS发布这个ContentProvider实例（类似于向AMS注册这个实例）。
2.2_1 ActivityThread的installProvider函数
ActivityThread.java::installProvider
private IActivityManager.ContentProviderHolder installProvider(Context context,
IActivityManager.ContentProviderHolder holder, ProviderInfo info,
boolean noisy, boolean noReleaseNeeded, boolean stable) {
ContentProvider localProvider = null;
IContentProvider provider;
if (holder == null || holder.provider == null) {
if (DEBUG_PROVIDER || noisy) {
Slog.d(TAG, "Loading provider " + info.authority + ": "
+ info.name);
}
Context c = null;
ApplicationInfo ai = info.applicationInfo;
if (context.getPackageName().equals(ai.packageName)) {
c = context;
} else if (mInitialApplication != null &&
mInitialApplication.getPackageName().equals(ai.packageName)) {
c = mInitialApplication;
} else {
try {
c = context.createPackageContext(ai.packageName,
Context.CONTEXT_INCLUDE_CODE);
} catch (PackageManager.NameNotFoundException e) {
// Ignore
}
}
if (c == null) {
Slog.w(TAG, "Unable to get context for package " +
ai.packageName +
" while loading content provider " +
info.name);
return null;
}
try {
final java.lang.ClassLoader cl = c.getClassLoader();
localProvider = (ContentProvider)cl.
loadClass(info.name).newInstance();
provider = localProvider.getIContentProvider();
if (provider == null) {
Slog.e(TAG, "Failed to instantiate class " +
info.name + " from sourceDir " +
info.applicationInfo.sourceDir);
return null;
}
if (DEBUG_PROVIDER) Slog.v(
TAG, "Instantiating local provider " + info.name);
// XXX Need to create the correct context for this provider.
localProvider.attachInfo(c, info);
} catch (java.lang.Exception e) {
if (!mInstrumentation.onException(null, e)) {
throw new RuntimeException(
"Unable to get provider " + info.name
+ ": " + e.toString(), e);
}
return null;
}
} else {
provider = holder.provider;
if (DEBUG_PROVIDER) Slog.v(TAG, "Installing external provider " + info.authority + ": "
+ info.name);
}
IActivityManager.ContentProviderHolder retHolder;
synchronized (mProviderMap) {
if (DEBUG_PROVIDER) Slog.v(TAG, "Checking to add " + provider
+ " / " + info.name);
IBinder jBinder = provider.asBinder();
if (localProvider != null) {
ComponentName cname = new ComponentName(info.packageName, info.name);
ProviderClientRecord pr = mLocalProvidersByName.get(cname);
if (pr != null) {
if (DEBUG_PROVIDER) {
Slog.v(TAG, "installProvider: lost the race, "
+ "using existing local provider");
}
provider = pr.mProvider;
} else {
holder = new IActivityManager.ContentProviderHolder(info);
holder.provider = provider;
holder.noReleaseNeeded = true;
pr = installProviderAuthoritiesLocked(provider, localProvider, holder);
mLocalProviders.put(jBinder, pr);
mLocalProvidersByName.put(cname, pr);
}
retHolder = pr.mHolder;
} else {
ProviderRefCount prc = mProviderRefCountMap.get(jBinder);
if (prc != null) {
if (DEBUG_PROVIDER) {
Slog.v(TAG, "installProvider: lost the race, updating ref count");
}
// We need to transfer our new reference to the existing
// ref count, releasing the old one... but only if
// release is needed (that is, it is not running in the
// system process).
if (!noReleaseNeeded) {
incProviderRefLocked(prc, stable);
try {
ActivityManagerNative.getDefault().removeContentProvider(
holder.connection, stable);
} catch (RemoteException e) {
//do nothing content provider object is dead any way
}
}
} else {
ProviderClientRecord client = installProviderAuthoritiesLocked(
provider, localProvider, holder);
if (noReleaseNeeded) {
prc = new ProviderRefCount(holder, client, 1000, 1000);
} else {
prc = stable
? new ProviderRefCount(holder, client, 1, 0)
: new ProviderRefCount(holder, client, 0, 1);
}
mProviderRefCountMap.put(jBinder, prc);
}
retHolder = prc.holder;
}
}
return retHolder;
}
以上代码是创建 SettingsProvider
存储情况具体如图：
a、ContentProvider是个容器，ContentProvider通过getIContentProvider获取mTransport，mTransport实现对跨进程调用的支持
b、ApplicationThreadNative从binder派生，实现了IContentProvider接口
c、ProviderClientRecord是用来保存ContentProvider信息的结构体，mLocalProviders保存ContentProvider对象，mProvider保存IContentProvider对象。
创建完成后将发布（把数据和运行环境联系起来）
2.2_2 AMS的publishContentProviders函数（发布前面创建的provider）
ActivityManagerService.java::publishContentProviders
public final void publishContentProviders(IApplicationThread caller,
List<ContentProviderHolder> providers) {
if (providers == null) {
return;
}
enforceNotIsolatedCaller("publishContentProviders");
synchronized (this) {
final ProcessRecord r = getRecordForAppLocked(caller);
if (DEBUG_MU)
Slog.v(TAG_MU, "ProcessRecord uid = " + r.uid);
if (r == null) {
throw new SecurityException(
"Unable to find app for caller " + caller
+ " (pid=" + Binder.getCallingPid()
+ ") when publishing content providers");
}
final long origId = Binder.clearCallingIdentity();
final int N = providers.size();
for (int i=0; i<N; i++) {
ContentProviderHolder src = providers.get(i);
if (src == null || src.info == null || src.provider == null) {
continue;
}
ContentProviderRecord dst = r.pubProviders.get(src.info.name);
if (DEBUG_MU)
Slog.v(TAG_MU, "ContentProviderRecord uid = " + dst.uid);
if (dst != null) {
ComponentName comp = new ComponentName(dst.info.packageName, dst.info.name);
mProviderMap.putProviderByClass(comp, dst);
String names[] = dst.info.authority.split(";");
for (int j = 0; j < names.length; j++) {
mProviderMap.putProviderByName(names[j], dst);
}
int NL = mLaunchingProviders.size();
int j;
for (j=0; j<NL; j++) {
if (mLaunchingProviders.get(j) == dst) {
mLaunchingProviders.remove(j);
j--;
NL--;
}
}
synchronized (dst) {
dst.provider = src.provider;
dst.proc = r;
dst.notifyAll();
}
updateOomAdjLocked(r); //发布一个Provider
}
}
Binder.restoreCallingIdentity(origId);
}
}
大概梳理一下：publishContentProviders：
a、 先根据调用者的PID找到对应的ProcessRecord对象。
b、 这个ProcessRecord的pubProviders中保存了ContentProviderRecord信息。在generateApplicationProvidersLocked函数生成。
c、 判断ContentProvider是否由那个package声明，返回成功，则将对应的authority加到mProviderMap中。
d、mLaunchingProviders和dst.notifyAl用于通知那些等待ContentProvider所在进程启动的客户端进程。
至此SettingsProvider正式加入到了AMS，之后和Settings数据库相关的操作均由它来管理。
4. AMS的systemReady分析 (ActivityManagerService.self().systemReady)
***********************
第一阶段
*****************************************************************************************************************************************
public void systemReady(final Runnable goingCallback) {
synchronized(this) {
if (mSystemReady) {
if (goingCallback != null) goingCallback.run();
return;
}
// Check to see if there are any update receivers to run.
if (!mDidUpdate) {
if (mWaitingUpdate) {
return;
}
Intent intent = new Intent(Intent.ACTION_PRE_BOOT_COMPLETED);
List<ResolveInfo> ris = null;
try {
ris = AppGlobals.getPackageManager().queryIntentReceivers(
intent, null, 0, 0);
} catch (RemoteException e) {
}
if (ris != null) {
for (int i=ris.size()-1; i>=0; i--) {
if ((ris.get(i).activityInfo.applicationInfo.flags
&ApplicationInfo.FLAG_SYSTEM) == 0) {
ris.remove(i);
}
}
intent.addFlags(Intent.FLAG_RECEIVER_BOOT_UPGRADE);
ArrayList<ComponentName> lastDoneReceivers = readLastDonePreBootReceivers();
final ArrayList<ComponentName> doneReceivers = new ArrayList<ComponentName>();
for (int i=0; i<ris.size(); i++) {
ActivityInfo ai = ris.get(i).activityInfo;
ComponentName comp = new ComponentName(ai.packageName, ai.name);
if (lastDoneReceivers.contains(comp)) {
ris.remove(i);
i--;
}
}
final int[] users = getUsersLocked();
for (int i=0; i<ris.size(); i++) {
ActivityInfo ai = ris.get(i).activityInfo;
ComponentName comp = new ComponentName(ai.packageName, ai.name);
doneReceivers.add(comp);
intent.setComponent(comp);
for (int j=0; j<users.length; j++) {
IIntentReceiver finisher = null;
if (i == ris.size()-1 && j == users.length-1) {
finisher = new IIntentReceiver.Stub() {
public void performReceive(Intent intent, int resultCode,
String data, Bundle extras, boolean ordered,
boolean sticky, int sendingUser) {
// The raw IIntentReceiver interface is called
// with the AM lock held, so redispatch to
// execute our code without the lock.
mHandler.post(new Runnable() {
public void run() {
synchronized (ActivityManagerService.this) {
mDidUpdate = true;
}
writeLastDonePreBootReceivers(doneReceivers);
showBootMessage(mContext.getText(
R.string.android_upgrading_complete),
false);
systemReady(goingCallback);
}
});
}
};
}
Slog.i(TAG, "Sending system update to " + intent.getComponent()
+ " for user " + users[j]);
broadcastIntentLocked(null, null, intent, null, finisher,
0, null, null, null, true, false, MY_PID, Process.SYSTEM_UID,
users[j]);
if (finisher != null) {
mWaitingUpdate = true;
}
}
}
}
if (mWaitingUpdate) {
return;
}
mDidUpdate = true;
}
mSystemReady = true;
if (!mStartRunning) {
return;
}
}
*****************************************************************************************************************************************
由以上代码可知，systemReady第一个阶段的工作主要是发送并处理与PRE_BOOT_COMPLETED广播相关的事情。
***********************
第二阶段
*****************************************************************************************************************************************
ArrayList<ProcessRecord> procsToKill = null;
synchronized(mPidsSelfLocked) {
for (int i=mPidsSelfLocked.size()-1; i>=0; i--) {
ProcessRecord proc = mPidsSelfLocked.valueAt(i);
if (!isAllowedWhileBooting(proc.info)){
if (procsToKill == null) {
procsToKill = new ArrayList<ProcessRecord>();
}
procsToKill.add(proc);
}
}
}
synchronized(this) {
if (procsToKill != null) {
for (int i=procsToKill.size()-1; i>=0; i--) {
ProcessRecord proc = procsToKill.get(i);
Slog.i(TAG, "Removing system update proc: " + proc);
removeProcessLocked(proc, true, false, "system update done");
}
}
// Now that we have cleaned up any update processes, we
// are ready to start launching real processes and know that
// we won't trample on them any more.
mProcessesReady = true;
}
Slog.i(TAG, "System now ready");
EventLog.writeEvent(EventLogTags.BOOT_PROGRESS_AMS_READY,
SystemClock.uptimeMillis());
synchronized(this) {
// Make sure we have no pre-ready processes sitting around.
if (mFactoryTest == SystemServer.FACTORY_TEST_LOW_LEVEL) {
ResolveInfo ri = mContext.getPackageManager()
.resolveActivity(new Intent(Intent.ACTION_FACTORY_TEST),
STOCK_PM_FLAGS);
CharSequence errorMsg = null;
if (ri != null) {
ActivityInfo ai = ri.activityInfo;
ApplicationInfo app = ai.applicationInfo;
if ((app.flags&ApplicationInfo.FLAG_SYSTEM) != 0) {
mTopAction = Intent.ACTION_FACTORY_TEST;
mTopData = null;
mTopComponent = new ComponentName(app.packageName,
ai.name);
} else {
errorMsg = mContext.getResources().getText(
com.android.internal.R.string.factorytest_not_system);
}
} else {
errorMsg = mContext.getResources().getText(
com.android.internal.R.string.factorytest_no_action);
}
if (errorMsg != null) {
mTopAction = null;
mTopData = null;
mTopComponent = null;
Message msg = Message.obtain();
msg.what = SHOW_FACTORY_ERROR_MSG;
msg.getData().putCharSequence("msg", errorMsg);
mHandler.sendMessage(msg);
}
}
}
retrieveSettings();
*****************************************************************************************************************************************
systemReady第二阶段：
a、杀死在AMS未启动完毕就先启动的应用进程（java进程）。
b、从Settings数据库中获取配置信息，配置：debug_app，wait_for_debugger，always_finish_activityes，font_scale（字体放大倍数）。
***********************
第三阶段
*****************************************************************************************************************************************
if (goingCallback != null) goingCallback.run();
synchronized (this) {
if (mFactoryTest != SystemServer.FACTORY_TEST_LOW_LEVEL) {
try {
List apps = AppGlobals.getPackageManager().
getPersistentApplications(STOCK_PM_FLAGS);
if (apps != null) {
int N = apps.size();
int i;
for (i=0; i<N; i++) {
ApplicationInfo info
= (ApplicationInfo)apps.get(i);
if (info != null &&
!info.packageName.equals("android")) { //android<===>framework-res.apk
addAppLocked(info, false); //启动该application所在进程。
}
}
}
} catch (RemoteException ex) {
// pm is in same process, this will never happen.
}
}
// Start up initial activity.
mBooting = true;
try {
if (AppGlobals.getPackageManager().hasSystemUidErrors()) {
Message msg = Message.obtain();
msg.what = SHOW_UID_ERROR_MSG;
mHandler.sendMessage(msg);
}
} catch (RemoteException e) {
}
long ident = Binder.clearCallingIdentity();
try {
Intent intent = new Intent(Intent.ACTION_USER_STARTED);
intent.addFlags(Intent.FLAG_RECEIVER_REGISTERED_ONLY
| Intent.FLAG_RECEIVER_FOREGROUND);
intent.putExtra(Intent.EXTRA_USER_HANDLE, mCurrentUserId);
broadcastIntentLocked(null, null, intent,
null, null, 0, null, null, null,
false, false, MY_PID, Process.SYSTEM_UID, mCurrentUserId);
intent = new Intent(Intent.ACTION_USER_STARTING);
intent.addFlags(Intent.FLAG_RECEIVER_REGISTERED_ONLY);
intent.putExtra(Intent.EXTRA_USER_HANDLE, mCurrentUserId);
broadcastIntentLocked(null, null, intent,
null, new IIntentReceiver.Stub() {
@Override
public void performReceive(Intent intent, int resultCode, String data,
Bundle extras, boolean ordered, boolean sticky, int sendingUser)
throws RemoteException {
}
}, 0, null, null,
android.Manifest.permission.INTERACT_ACROSS_USERS,
true, false, MY_PID, Process.SYSTEM_UID, UserHandle.USER_ALL);
} finally {
Binder.restoreCallingIdentity(ident);
}
mMainStack.resumeTopActivityLocked(null);
sendUserSwitchBroadcastsLocked(-1, mCurrentUserId);
}
}
*****************************************************************************************************************************************
systemReady第三阶段：
a、调用systemReady设置的回调对象goingCallback的run函数
b、启动那些声明了persistent的APK
c、启动桌面
4.1 回调：(回调是在SystemServer.java 中定义的)
ActivityManagerService.self().systemReady(new Runnable() {
public void run() {
Slog.i(TAG, "Making services ready");
if (!headless) startSystemUi(contextF);
try {
if (mountServiceF != null) mountServiceF.systemReady();
} catch (Throwable e) {
reportWtf("making Mount Service ready", e);
}
try {
if (batteryF != null) batteryF.systemReady();
} catch (Throwable e) {
reportWtf("making Battery Service ready", e);
}
try {
if (networkManagementF != null) networkManagementF.systemReady();
} catch (Throwable e) {
reportWtf("making Network Managment Service ready", e);
}
try {
if (networkStatsF != null) networkStatsF.systemReady();
} catch (Throwable e) {
reportWtf("making Network Stats Service ready", e);
}
try {
if (networkPolicyF != null) networkPolicyF.systemReady();
} catch (Throwable e) {
reportWtf("making Network Policy Service ready", e);
}
try {
if (connectivityF != null) connectivityF.systemReady();
} catch (Throwable e) {
reportWtf("making Connectivity Service ready", e);
}
try {
if (dockF != null) dockF.systemReady();
} catch (Throwable e) {
reportWtf("making Dock Service ready", e);
}
try {
if (usbF != null) usbF.systemReady();
} catch (Throwable e) {
reportWtf("making USB Service ready", e);
}
try {
if (twilightF != null) twilightF.systemReady();
} catch (Throwable e) {
reportWtf("makin Twilight Service ready", e);
}
try {
if (uiModeF != null) uiModeF.systemReady();
} catch (Throwable e) {
reportWtf("making UI Mode Service ready", e);
}
try {
if (recognitionF != null) recognitionF.systemReady();
} catch (Throwable e) {
reportWtf("making Recognition Service ready", e);
}
Watchdog.getInstance().start();
// It is now okay to let the various system services start their
// third party code...
try {
if (appWidgetF != null) appWidgetF.systemReady(safeMode);
} catch (Throwable e) {
reportWtf("making App Widget Service ready", e);
}
try {
if (wallpaperF != null) wallpaperF.systemReady();
} catch (Throwable e) {
reportWtf("making Wallpaper Service ready", e);
}
try {
if (immF != null) immF.systemReady(statusBarF);
} catch (Throwable e) {
reportWtf("making Input Method Service ready", e);
}
try {
if (locationF != null) locationF.systemReady();
} catch (Throwable e) {
reportWtf("making Location Service ready", e);
}
try {
if (countryDetectorF != null) countryDetectorF.systemReady();
} catch (Throwable e) {
reportWtf("making Country Detector Service ready", e);
}
try {
if (throttleF != null) throttleF.systemReady();
} catch (Throwable e) {
reportWtf("making Throttle Service ready", e);
}
try {
if (networkTimeUpdaterF != null) networkTimeUpdaterF.systemReady();
} catch (Throwable e) {
reportWtf("making Network Time Service ready", e);
}
try {
if (commonTimeMgmtServiceF != null) commonTimeMgmtServiceF.systemReady();
} catch (Throwable e) {
reportWtf("making Common time management service ready", e);
}
try {
if (textServiceManagerServiceF != null) textServiceManagerServiceF.systemReady();
} catch (Throwable e) {
reportWtf("making Text Services Manager Service ready", e);
}
try {
if (dreamyF != null) dreamyF.systemReady();
} catch (Throwable e) {
reportWtf("making DreamManagerService ready", e);
}
try {
// TODO(BT) Pass parameter to input manager
if (inputManagerF != null) inputManagerF.systemReady();
} catch (Throwable e) {
reportWtf("making InputManagerService ready", e);
}
try {
if (telephonyRegistryF != null) telephonyRegistryF.systemReady();
} catch (Throwable e) {
reportWtf("making TelephonyRegistry ready", e);
}
}
});
// For debug builds, log event loop stalls to dropbox for analysis.
if (StrictMode.conditionallyEnableDebugLogging()) {
Slog.i(TAG, "Enabled StrictMode for system server main thread.");
}
Looper.loop();
Slog.d(TAG, "System ServerThread is exiting!");
}
static final void startSystemUi(Context context) {
Intent intent = new Intent();
intent.setComponent(new ComponentName("com.android.systemui",
"com.android.systemui.SystemUIService"));
//Slog.d(TAG, "Starting service: " + intent);
context.startServiceAsUser(intent, UserHandle.OWNER);
}
run函数：
a、 执行startSystemUi，对应SystemUI.apk 状态栏
b、 调用一些其他服务的systemReady
c、 启动Watchdog
4.2 启动桌面
mMainStack.resumeTopActivityLocked(null);
final boolean resumeTopActivityLocked(ActivityRecord prev) {
return resumeTopActivityLocked(prev, null);
}
final boolean resumeTopActivityLocked(ActivityRecord prev, Bundle options) {
// Find the first activity that is not finishing.
ActivityRecord next = topRunningActivityLocked(null);
// Remember how we'll process this pause/resume situation, and ensure
// that the state is reset however we wind up proceeding.
final boolean userLeaving = mUserLeaving;
mUserLeaving = false;
if (next == null) {
// There are no more activities! Let's just start up the
// Launcher...
if (mMainStack) {
ActivityOptions.abort(options);
return mService.startHomeActivityLocked(mCurrentUser);
}
}
......
if (mResumedActivity != null) {
if (DEBUG_SWITCH) Slog.v(TAG, "Skip resume: need to start pausing");
// At this point we want to put the upcoming activity's process
// at the top of the LRU list, since we know we will be needing it
// very soon and it would be a waste to let it get killed if it
// happens to be sitting towards the end.
if (next.app != null && next.app.thread != null) {
// No reason to do full oom adj update here; we'll let that
// happen whenever it needs to later.
mService.updateLruProcessLocked(next.app, false);
}
startPausingLocked(userLeaving, false);
return true;
}
......
这个函数很长，这里主要关注mService.startHomeActivityLocked(mCurrentUser)
ActivityManagerService mService;
boolean startHomeActivityLocked(int userId) {
if (mHeadless) {
// Added because none of the other calls to ensureBootCompleted seem to fire
// when running headless.
ensureBootCompleted();
return false;
}
if (mFactoryTest == SystemServer.FACTORY_TEST_LOW_LEVEL
&& mTopAction == null) {
// We are running in factory test mode, but unable to find
// the factory test app, so just sit around displaying the
// error message and don't try to start anything.
return false;
}
Intent intent = new Intent(
mTopAction,
mTopData != null ? Uri.parse(mTopData) : null);
intent.setComponent(mTopComponent);
if (mFactoryTest != SystemServer.FACTORY_TEST_LOW_LEVEL) {
intent.addCategory(Intent.CATEGORY_HOME);
}
ActivityInfo aInfo =
resolveActivityInfo(intent, STOCK_PM_FLAGS, userId);
if (aInfo != null) {
intent.setComponent(new ComponentName(
aInfo.applicationInfo.packageName, aInfo.name));
// Don't do this if the home app is currently being
// instrumented.
aInfo = new ActivityInfo(aInfo);
aInfo.applicationInfo = getAppInfoForUser(aInfo.applicationInfo, userId);
ProcessRecord app = getProcessRecordLocked(aInfo.processName,
aInfo.applicationInfo.uid);
if (app == null || app.instrumentationClass == null) {
intent.setFlags(intent.getFlags() | Intent.FLAG_ACTIVITY_NEW_TASK);
mMainStack.startActivityLocked(null, intent, null, aInfo,
null, null, 0, 0, 0, 0, null, false, null);
}
}
return true;
}
这个函数的位置就是添加开机记忆功能的位置（在这里读取系统属性，根据属性来决定启动网格UI还是启动TV）
private final void startActivityLocked(ActivityRecord r, boolean newTask,
boolean doResume, boolean keepCurTransition, Bundle options) {......}
这个函数就是根据参数具体启动应用。
4.3 发送广播
resumeTopActivityLocked 函数中 startHomeActivityLocked 完了之后会调用 startPausingLocked 函数
private final void startPausingLocked(boolean userLeaving, boolean uiSleeping) {
if (mPausingActivity != null) {
RuntimeException e = new RuntimeException();
Slog.e(TAG, "Trying to pause when pause is already pending for "
+ mPausingActivity, e);
}
ActivityRecord prev = mResumedActivity;
if (prev == null) {
RuntimeException e = new RuntimeException();
Slog.e(TAG, "Trying to pause when nothing is resumed", e);
resumeTopActivityLocked(null);
return;
}
mResumedActivity = null;
mPausingActivity = prev;
mLastPausedActivity = prev;
prev.state = ActivityState.PAUSING;
prev.task.touchActiveTime();
prev.updateThumbnail(screenshotActivities(prev), null);
mService.updateCpuStats();
if (prev.app != null && prev.app.thread != null) {
if (DEBUG_PAUSE) Slog.v(TAG, "Enqueueing pending pause: " + prev);
try {
EventLog.writeEvent(EventLogTags.AM_PAUSE_ACTIVITY,
prev.userId, System.identityHashCode(prev),
prev.shortComponentName);
prev.app.thread.schedulePauseActivity(prev.appToken, prev.finishing,
userLeaving, prev.configChangeFlags);
if (mMainStack) {
mService.updateUsageStats(prev, false);
}
} catch (Exception e) {
// Ignore exception, if process died other code will cleanup.
Slog.w(TAG, "Exception thrown during pause", e);
mPausingActivity = null;
mLastPausedActivity = null;
}
} else {
mPausingActivity = null;
mLastPausedActivity = null;
}
// If we are not going to sleep, we want to ensure the device is
// awake until the next activity is started.
if (!mService.mSleeping && !mService.mShuttingDown) {
mLaunchingActivity.acquire();
if (!mHandler.hasMessages(LAUNCH_TIMEOUT_MSG)) {
// To be safe, don't allow the wake lock to be held for too long.
Message msg = mHandler.obtainMessage(LAUNCH_TIMEOUT_MSG);
mHandler.sendMessageDelayed(msg, LAUNCH_TIMEOUT);
}
}
if (mPausingActivity != null) {
// Have the window manager pause its key dispatching until the new
// activity has started. If we're pausing the activity just because
// the screen is being turned off and the UI is sleeping, don't interrupt
// key dispatch; the same activity will pick it up again on wakeup.
if (!uiSleeping) {
prev.pauseKeyDispatchingLocked();
} else {
if (DEBUG_PAUSE) Slog.v(TAG, "Key dispatch not paused for screen off");
}
// Schedule a pause timeout in case the app doesn't respond.
// We don't give it much time because this directly impacts the
// responsiveness seen by the user.
Message msg = mHandler.obtainMessage(PAUSE_TIMEOUT_MSG);
msg.obj = prev;
prev.pauseTime = SystemClock.uptimeMillis();
mHandler.sendMessageDelayed(msg, PAUSE_TIMEOUT);
if (DEBUG_PAUSE) Slog.v(TAG, "Waiting for pause to complete...");
} else {
// This activity failed to schedule the
// pause, so just treat it as being paused now.
if (DEBUG_PAUSE) Slog.v(TAG, "Activity not running, resuming next.");
resumeTopActivityLocked(null);
}
}
调用了schedulePauseActivity
public final void schedulePauseActivity(IBinder token, boolean finished,
boolean userLeaving, int configChanges) {
queueOrSendMessage(
finished ? H.PAUSE_ACTIVITY_FINISHING : H.PAUSE_ACTIVITY,
token,
(userLeaving ? 1 : 0),
configChanges);
}
此函数发送了PAUSE_ACTIVITY_FINISHING广播，这个广播在handleMessage中处理：
public void handleMessage(Message msg) {
if (DEBUG_MESSAGES) Slog.v(TAG, ">>> handling: " + codeToString(msg.what));
switch (msg.what) {
case PAUSE_ACTIVITY_FINISHING:
Trace.traceBegin(Trace.TRACE_TAG_ACTIVITY_MANAGER, "activityPause");
handlePauseActivity((IBinder)msg.obj, true, msg.arg1 != 0, msg.arg2);
Trace.traceEnd(Trace.TRACE_TAG_ACTIVITY_MANAGER);
break;
handlePauseActivity来响应：
private void handlePauseActivity(IBinder token, boolean finished,
boolean userLeaving, int configChanges) {
ActivityClientRecord r = mActivities.get(token);
if (r != null) {
//Slog.v(TAG, "userLeaving=" + userLeaving + " handling pause of " + r);
if (userLeaving) {
performUserLeavingActivity(r);
}
r.activity.mConfigChangeFlags |= configChanges;
performPauseActivity(token, finished, r.isPreHoneycomb());
// Make sure any pending writes are now committed.
if (r.isPreHoneycomb()) {
QueuedWork.waitToFinish();
}
// Tell the activity manager we have paused.
try {
ActivityManagerNative.getDefault().activityPaused(token);
} catch (RemoteException ex) {
}
}
}
中间调用了： performPauseActivity
final Bundle performPauseActivity(ActivityClientRecord r, boolean finished,
boolean saveState) {
if (r.paused) {
if (r.activity.mFinished) {
// If we are finishing, we won't call onResume() in certain cases.
// So here we likewise don't want to call onPause() if the activity
// isn't resumed.
return null;
}
RuntimeException e = new RuntimeException(
"Performing pause of activity that is not resumed: "
+ r.intent.getComponent().toShortString());
Slog.e(TAG, e.getMessage(), e);
}
Bundle state = null;
if (finished) {
r.activity.mFinished = true;
}
try {
// Next have the activity save its current state and managed dialogs...
if (!r.activity.mFinished && saveState) {
state = new Bundle();
state.setAllowFds(false);
mInstrumentation.callActivityOnSaveInstanceState(r.activity, state);
r.state = state;
}
// Now we are idle.
r.activity.mCalled = false;
mInstrumentation.callActivityOnPause(r.activity);
EventLog.writeEvent(LOG_ON_PAUSE_CALLED, UserHandle.myUserId(),
r.activity.getComponentName().getClassName());
if (!r.activity.mCalled) {
throw new SuperNotCalledException(
"Activity " + r.intent.getComponent().toShortString() +
" did not call through to super.onPause()");
}
} catch (SuperNotCalledException e) {
throw e;
} catch (Exception e) {
if (!mInstrumentation.onException(r.activity, e)) {
throw new RuntimeException(
"Unable to pause activity "
+ r.intent.getComponent().toShortString()
+ ": " + e.toString(), e);
}
}
r.paused = true;
// Notify any outstanding on paused listeners
ArrayList<OnActivityPausedListener> listeners;
synchronized (mOnPauseListeners) {
listeners = mOnPauseListeners.remove(r.activity);
}
int size = (listeners != null ? listeners.size() : 0);
for (int i = 0; i < size; i++) {
listeners.get(i).onPaused(r.activity);
}
return state;
}
然后调用了：ActivityManagerNative.getDefault().activityPaused
final void activityPaused(IBinder token, boolean timeout) {
if (DEBUG_PAUSE) Slog.v(
TAG, "Activity paused: token=" + token + ", timeout=" + timeout);
ActivityRecord r = null;
synchronized (mService) {
int index = indexOfTokenLocked(token);
if (index >= 0) {
r = mHistory.get(index);
mHandler.removeMessages(PAUSE_TIMEOUT_MSG, r);
if (mPausingActivity == r) {
if (DEBUG_STATES) Slog.v(TAG, "Moving to PAUSED: " + r
+ (timeout ? " (due to timeout)" : " (pause complete)"));
r.state = ActivityState.PAUSED;
completePauseLocked();
} else {
EventLog.writeEvent(EventLogTags.AM_FAILED_TO_PAUSE,
r.userId, System.identityHashCode(r), r.shortComponentName,
mPausingActivity != null
? mPausingActivity.shortComponentName : "(none)");
}
}
}
}
此函数中调用了：completePauseLocked
private final void completePauseLocked() {
ActivityRecord prev = mPausingActivity;
if (DEBUG_PAUSE) Slog.v(TAG, "Complete pause: " + prev);
if (prev != null) {
if (prev.finishing) {
if (DEBUG_PAUSE) Slog.v(TAG, "Executing finish of activity: " + prev);
prev = finishCurrentActivityLocked(prev, FINISH_AFTER_VISIBLE, false);
} else if (prev.app != null) {
if (DEBUG_PAUSE) Slog.v(TAG, "Enqueueing pending stop: " + prev);
if (prev.waitingVisible) {
prev.waitingVisible = false;
mWaitingVisibleActivities.remove(prev);
if (DEBUG_SWITCH || DEBUG_PAUSE) Slog.v(
TAG, "Complete pause, no longer waiting: " + prev);
}
if (prev.configDestroy) {
// The previous is being paused because the configuration
// is changing, which means it is actually stopping...
// To juggle the fact that we are also starting a new
// instance right now, we need to first completely stop
// the current instance before starting the new one.
if (DEBUG_PAUSE) Slog.v(TAG, "Destroying after pause: " + prev);
destroyActivityLocked(prev, true, false, "pause-config");
} else {
mStoppingActivities.add(prev);
if (mStoppingActivities.size() > 3) {
// If we already have a few activities waiting to stop,
// then give up on things going idle and start clearing
// them out.
if (DEBUG_PAUSE) Slog.v(TAG, "To many pending stops, forcing idle");
scheduleIdleLocked();
} else {
checkReadyForSleepLocked();
}
}
} else {
if (DEBUG_PAUSE) Slog.v(TAG, "App died during pause, not stopping: " + prev);
prev = null;
}
mPausingActivity = null;
}
if (!mService.isSleeping()) {
resumeTopActivityLocked(prev);
} else {
checkReadyForSleepLocked();
ActivityRecord top = topRunningActivityLocked(null);
if (top == null || (prev != null && top != prev)) {
// If there are no more activities available to run,
// do resume anyway to start something. Also if the top
// activity on the stack is not the just paused activity,
// we need to go ahead and resume it to ensure we complete
// an in-flight app switch.
resumeTopActivityLocked(null);
}
}
if (prev != null) {
prev.resumeKeyDispatchingLocked();
}
if (prev.app != null && prev.cpuTimeAtResume > 0
&& mService.mBatteryStatsService.isOnBattery()) {
long diff = 0;
synchronized (mService.mProcessStatsThread) {
diff = mService.mProcessStats.getCpuTimeForPid(prev.app.pid)
- prev.cpuTimeAtResume;
}
if (diff > 0) {
BatteryStatsImpl bsi = mService.mBatteryStatsService.getActiveStatistics();
synchronized (bsi) {
BatteryStatsImpl.Uid.Proc ps =
bsi.getProcessStatsLocked(prev.info.applicationInfo.uid,
prev.info.packageName);
if (ps != null) {
ps.addForegroundTimeLocked(diff);
}
}
}
}
prev.cpuTimeAtResume = 0; // reset it
}
此函数中调用了： scheduleIdleLocked
final void scheduleIdleLocked() {
Message msg = Message.obtain();
msg.what = IDLE_NOW_MSG;
mHandler.sendMessage(msg);
}
发送了一个IDLE_NOW_MSG广播：
public void handleMessage(Message msg) {
switch (msg.what) {
case IDLE_NOW_MSG: {
ActivityRecord r = (ActivityRecord)msg.obj;
activityIdleInternal(r != null ? r.appToken : null, false, null);
} break;
IDLE_NOW_MSG广播的处理调用了：activityIdleInternal
final ActivityRecord activityIdleInternal(IBinder token, boolean fromTimeout,
Configuration config) {
if (localLOGV) Slog.v(TAG, "Activity idle: " + token);
......
if (booting) {
mService.finishBooting();
} else if (startingUsers != null) {
for (i=0; i<startingUsers.size(); i++) {
mService.finishUserSwitch(startingUsers.get(i));
}
}
mService.trimApplications();
//dump();
//mWindowManager.dump();
if (enableScreen) {
mService.enableScreenAfterBoot();
}
if (activityRemoved) {
resumeTopActivityLocked(null);
}
return res;
}
其调用了mService.finishBooting();
final void finishBooting() {
IntentFilter pkgFilter = new IntentFilter();
pkgFilter.addAction(Intent.ACTION_QUERY_PACKAGE_RESTART);
pkgFilter.addDataScheme("package");
mContext.registerReceiver(new BroadcastReceiver() {
@Override
public void onReceive(Context context, Intent intent) {
String[] pkgs = intent.getStringArrayExtra(Intent.EXTRA_PACKAGES);
if (pkgs != null) {
for (String pkg : pkgs) {
synchronized (ActivityManagerService.this) {
if (forceStopPackageLocked(pkg, -1, false, false, false, false, 0)) {
setResultCode(Activity.RESULT_OK);
return;
}
}
}
}
}
}, pkgFilter);
synchronized (this) {
// Ensure that any processes we had put on hold are now started
// up.
final int NP = mProcessesOnHold.size();
if (NP > 0) {
ArrayList<ProcessRecord> procs =
new ArrayList<ProcessRecord>(mProcessesOnHold);
for (int ip=0; ip<NP; ip++) {
if (DEBUG_PROCESSES) Slog.v(TAG, "Starting process on hold: "
+ procs.get(ip));
startProcessLocked(procs.get(ip), "on-hold", null);
}
}
if (mFactoryTest != SystemServer.FACTORY_TEST_LOW_LEVEL) {
// Start looking for apps that are abusing wake locks.
Message nmsg = mHandler.obtainMessage(CHECK_EXCESSIVE_WAKE_LOCKS_MSG);
mHandler.sendMessageDelayed(nmsg, POWER_CHECK_DELAY);
// Tell anyone interested that we are done booting!
SystemProperties.set("sys.boot_completed", "1");
SystemProperties.set("dev.bootcomplete", "1");
for (int i=0; i<mStartedUsers.size(); i++) {
UserStartedState uss = mStartedUsers.valueAt(i);
if (uss.mState == UserStartedState.STATE_BOOTING) {
uss.mState = UserStartedState.STATE_RUNNING;
final int userId = mStartedUsers.keyAt(i);
Intent intent = new Intent(Intent.ACTION_BOOT_COMPLETED, null);
intent.putExtra(Intent.EXTRA_USER_HANDLE, userId);
broadcastIntentLocked(null, null, intent,
null, null, 0, null, null,
android.Manifest.permission.RECEIVE_BOOT_COMPLETED,
false, false, MY_PID, Process.SYSTEM_UID, userId);
}
}
}
}
}
最终 finishBooting 发送了 Intent.ACTION_BOOT_COMPLETED 广播。
几个问题说明：
1、应用进程与系统进程
应用进程是指那些运行apk的进程，它们由Zygote派生（fork）而来，上面运行了dalvik虚拟机。
系统进程：Zygote和system_server进程
2、应用apk与系统apk
/data/app/下的apk为应用apk
/system/app/下的apk为系统apk
3、ActivityThread代表应用进程的主线程，而system_server并非一个应用进程，为什么也需要ActivityThread？
a、因为framework-res.apk除了包含资源文件外，还包含了一些Activity（如关机对话框）,这些Activity运行在system_server进程中，所以system_server是一个特殊的应用进程。
b、通过ActivityThread可以把Android系统提供的组件之间的交互机制和交互接口(如Context提供的API)也拓展到system_server。
4、四大组件：
activity、service、content provider、broadcast receiver。
5、ProcessRecord和IApplicationThread
AMS与应用进程之间使用binder进行通信。android定义了IApplicationThread接口，此接口定义了AMS和应用进程之间的交互函数。此接口的家族图：
ActivityThread通过成员变量mAppThread指向它的内部类ApplicationThread。
IApplicationThread的客户端在AMS中，IApplicationThread的Binder服务端在应用进程中。（binder系统支持客户端监听服务端的死亡信息）
public final void scheduleStopActivity(IBinder token, boolean showWindow,
int configChanges) {
queueOrSendMessage(
showWindow ? H.STOP_ACTIVITY_SHOW : H.STOP_ACTIVITY_HIDE,
token, 0, configChanges);
}
即当AMS想要停止一个Activity时，就会通过IApplicationThread的Binder的客户端函数scheduleStopActivity想ActivityThread所在线程发送一个消息，ActivityThread运行在主线程，所以这个消息最终是由主线程处理的。
这篇关于activitymanagerservice启动的文章就介绍到这儿，希望我们推荐的文章对编程师们有所帮助！
