USB Drivers 相关数据结构记录
struct usb_device_id
路径：include/linux/mod_devicetable.h
/*** struct usb_device_id - identifies USB devices for probing and hotplugging* @match_flags: Bit mask controlling of the other fields are used to match* against new devices. Any field except for driver_info may be used,* although some only make sense in conjunction with other fields.* This is usually set by a USB_DEVICE_*() macro, which sets all* other fields in this structure except for driver_info.* @idVendor: USB vendor ID for a device; numbers are assigned* by the USB forum to its members.* @idProduct: Vendor-assigned product ID.* @bcdDevice_lo: Low end of range of vendor-assigned product version numbers.* This is also used to identify individual product versions, for* a range consisting of a single device.* @bcdDevice_hi: High end of version number range. The range of product* versions is inclusive.* @bDeviceClass: Class of device; numbers are assigned* by the USB forum. Products may choose to implement classes,* or be vendor-specific. Device classes specify behavior of all* the interfaces on a devices.* @bDeviceSubClass: Subclass of device; associated with bDeviceClass.* @bDeviceProtocol: Protocol of device; associated with bDeviceClass.* @bInterfaceClass: Class of interface; numbers are assigned* by the USB forum. Products may choose to implement classes,* or be vendor-specific. Interface classes specify behavior only* of a given interface; other interfaces may support other classes.* @bInterfaceSubClass: Subclass of interface; associated with bInterfaceClass.* @bInterfaceProtocol: Protocol of interface; associated with bInterfaceClass.* @bInterfaceNumber: Number of interface; composite devices may use* fixed interface numbers to differentiate between vendor-specific* interfaces.* @driver_info: Holds information used by the driver. Usually it holds* a pointer to a descriptor understood by the driver, or perhaps* device flags.** In most cases, drivers will create a table of device IDs by using* USB_DEVICE(), or similar macros designed for that purpose.* They will then export it to userspace using MODULE_DEVICE_TABLE(),* and provide it to the USB core through their usb_driver structure.** See the usb_match_id() function for information about how matches are* performed. Briefly, you will normally use one of several macros to help* construct these entries. Each entry you provide will either identify* one or more specific products, or will identify a class of products* which have agreed to behave the same. You should put the more specific* matches towards the beginning of your table, so that driver_info can* record quirks of specific products.*/
struct usb_device_id {/* which fields to match against? */__u16 match_flags;/* Used for product specific matches; range is inclusive */__u16 idVendor;__u16 idProduct;__u16 bcdDevice_lo;__u16 bcdDevice_hi;/* Used for device class matches */__u8 bDeviceClass;__u8 bDeviceSubClass;__u8 bDeviceProtocol;/* Used for interface class matches */__u8 bInterfaceClass;__u8 bInterfaceSubClass;__u8 bInterfaceProtocol;/* Used for vendor-specific interface matches */__u8 bInterfaceNumber;/* not matched against */kernel_ulong_t driver_info__attribute__((aligned(sizeof(kernel_ulong_t))));
};
Macro: USB_DEVICE
include/linux/usb.h
/*** USB_DEVICE - macro used to describe a specific usb device* @vend: the 16 bit USB Vendor ID* @prod: the 16 bit USB Product ID** This macro is used to create a struct usb_device_id that matches a* specific device.*/
#define USB_DEVICE(vend, prod) \.match_flags = USB_DEVICE_ID_MATCH_DEVICE, \.idVendor = (vend), \.idProduct = (prod)
Macro: MODULE_DEVICE_TABLE
路径：include/linux/module.h
#define MODULE_DEVICE_TABLE(type,name) \MODULE_GENERIC_TABLE(type##_device,name)
#define MODULE_GENERIC_TABLE(gtype,name) \
extern const struct gtype##_id __mod_##gtype##_table \__attribute__ ((unused, alias(__stringify(name))))
struct kref
路径： include/linux/kref.h
struct kref {atomic_t refcount;
};
struct urb
path: include/linux/usb.h
/*** struct urb - USB Request Block* @urb_list: For use by current owner of the URB.* @anchor_list: membership in the list of an anchor* @anchor: to anchor URBs to a common mooring* @ep: Points to the endpoint's data structure. Will eventually* replace @pipe.* @pipe: Holds endpoint number, direction, type, and more.* Create these values with the eight macros available;* usb_{snd,rcv}TYPEpipe(dev,endpoint), where the TYPE is "ctrl"* (control), "bulk", "int" (interrupt), or "iso" (isochronous).* For example usb_sndbulkpipe() or usb_rcvintpipe(). Endpoint* numbers range from zero to fifteen. Note that "in" endpoint two* is a different endpoint (and pipe) from "out" endpoint two.* The current configuration controls the existence, type, and* maximum packet size of any given endpoint.* @stream_id: the endpoint's stream ID for bulk streams* @dev: Identifies the USB device to perform the request.* @status: This is read in non-iso completion functions to get the* status of the particular request. ISO requests only use it* to tell whether the URB was unlinked; detailed status for* each frame is in the fields of the iso_frame-desc.* @transfer_flags: A variety of flags may be used to affect how URB* submission, unlinking, or operation are handled. Different* kinds of URB can use different flags.* @transfer_buffer: This identifies the buffer to (or from) which the I/O* request will be performed unless URB_NO_TRANSFER_DMA_MAP is set* (however, do not leave garbage in transfer_buffer even then).* This buffer must be suitable for DMA; allocate it with* kmalloc() or equivalent. For transfers to "in" endpoints, contents* of this buffer will be modified. This buffer is used for the data* stage of control transfers.* @transfer_dma: When transfer_flags includes URB_NO_TRANSFER_DMA_MAP,* the device driver is saying that it provided this DMA address,* which the host controller driver should use in preference to the* transfer_buffer.* @sg: scatter gather buffer list, the buffer size of each element in* the list (except the last) must be divisible by the endpoint's* max packet size if no_sg_constraint isn't set in 'struct usb_bus'* (FIXME: scatter-gather under xHCI is broken for periodic transfers.* Do not use urb->sg for interrupt endpoints for now, only bulk.)* @num_mapped_sgs: (internal) number of mapped sg entries* @num_sgs: number of entries in the sg list* @transfer_buffer_length: How big is transfer_buffer. The transfer may* be broken up into chunks according to the current maximum packet* size for the endpoint, which is a function of the configuration* and is encoded in the pipe. When the length is zero, neither* transfer_buffer nor transfer_dma is used.* @actual_length: This is read in non-iso completion functions, and* it tells how many bytes (out of transfer_buffer_length) were* transferred. It will normally be the same as requested, unless* either an error was reported or a short read was performed.* The URB_SHORT_NOT_OK transfer flag may be used to make such* short reads be reported as errors.* @setup_packet: Only used for control transfers, this points to eight bytes* of setup data. Control transfers always start by sending this data* to the device. Then transfer_buffer is read or written, if needed.* @setup_dma: DMA pointer for the setup packet. The caller must not use* this field; setup_packet must point to a valid buffer.* @start_frame: Returns the initial frame for isochronous transfers.* @number_of_packets: Lists the number of ISO transfer buffers.* @interval: Specifies the polling interval for interrupt or isochronous* transfers. The units are frames (milliseconds) for full and low* speed devices, and microframes (1/8 millisecond) for highspeed* and SuperSpeed devices.* @error_count: Returns the number of ISO transfers that reported errors.* @context: For use in completion functions. This normally points to* request-specific driver context.* @complete: Completion handler. This URB is passed as the parameter to the* completion function. The completion function may then do what* it likes with the URB, including resubmitting or freeing it.* @iso_frame_desc: Used to provide arrays of ISO transfer buffers and to* collect the transfer status for each buffer.** This structure identifies USB transfer requests. URBs must be allocated by* calling usb_alloc_urb() and freed with a call to usb_free_urb().* Initialization may be done using various usb_fill_*_urb() functions. URBs* are submitted using usb_submit_urb(), and pending requests may be canceled* using usb_unlink_urb() or usb_kill_urb().** Data Transfer Buffers:** Normally drivers provide I/O buffers allocated with kmalloc() or otherwise* taken from the general page pool. That is provided by transfer_buffer* (control requests also use setup_packet), and host controller drivers* perform a dma mapping (and unmapping) for each buffer transferred. Those* mapping operations can be expensive on some platforms (perhaps using a dma* bounce buffer or talking to an IOMMU),* although they're cheap on commodity x86 and ppc hardware.** Alternatively, drivers may pass the URB_NO_TRANSFER_DMA_MAP transfer flag,* which tells the host controller driver that no such mapping is needed for* the transfer_buffer since* the device driver is DMA-aware. For example, a device driver might* allocate a DMA buffer with usb_alloc_coherent() or call usb_buffer_map().* When this transfer flag is provided, host controller drivers will* attempt to use the dma address found in the transfer_dma* field rather than determining a dma address themselves.** Note that transfer_buffer must still be set if the controller* does not support DMA (as indicated by bus.uses_dma) and when talking* to root hub. If you have to trasfer between highmem zone and the device* on such controller, create a bounce buffer or bail out with an error.* If transfer_buffer cannot be set (is in highmem) and the controller is DMA* capable, assign NULL to it, so that usbmon knows not to use the value.* The setup_packet must always be set, so it cannot be located in highmem.** Initialization:** All URBs submitted must initialize the dev, pipe, transfer_flags (may be* zero), and complete fields. All URBs must also initialize* transfer_buffer and transfer_buffer_length. They may provide the* URB_SHORT_NOT_OK transfer flag, indicating that short reads are* to be treated as errors; that flag is invalid for write requests.** Bulk URBs may* use the URB_ZERO_PACKET transfer flag, indicating that bulk OUT transfers* should always terminate with a short packet, even if it means adding an* extra zero length packet.** Control URBs must provide a valid pointer in the setup_packet field.* Unlike the transfer_buffer, the setup_packet may not be mapped for DMA* beforehand.** Interrupt URBs must provide an interval, saying how often (in milliseconds* or, for highspeed devices, 125 microsecond units)* to poll for transfers. After the URB has been submitted, the interval* field reflects how the transfer was actually scheduled.* The polling interval may be more frequent than requested.* For example, some controllers have a maximum interval of 32 milliseconds,* while others support intervals of up to 1024 milliseconds.* Isochronous URBs also have transfer intervals. (Note that for isochronous* endpoints, as well as high speed interrupt endpoints, the encoding of* the transfer interval in the endpoint descriptor is logarithmic.* Device drivers must convert that value to linear units themselves.)** If an isochronous endpoint queue isn't already running, the host* controller will schedule a new URB to start as soon as bandwidth* utilization allows. If the queue is running then a new URB will be* scheduled to start in the first transfer slot following the end of the* preceding URB, if that slot has not already expired. If the slot has* expired (which can happen when IRQ delivery is delayed for a long time),* the scheduling behavior depends on the URB_ISO_ASAP flag. If the flag* is clear then the URB will be scheduled to start in the expired slot,* implying that some of its packets will not be transferred; if the flag* is set then the URB will be scheduled in the first unexpired slot,* breaking the queue's synchronization. Upon URB completion, the* start_frame field will be set to the (micro)frame number in which the* transfer was scheduled. Ranges for frame counter values are HC-specific* and can go from as low as 256 to as high as 65536 frames.** Isochronous URBs have a different data transfer model, in part because* the quality of service is only "best effort". Callers provide specially* allocated URBs, with number_of_packets worth of iso_frame_desc structures* at the end. Each such packet is an individual ISO transfer. Isochronous* URBs are normally queued, submitted by drivers to arrange that* transfers are at least double buffered, and then explicitly resubmitted* in completion handlers, so* that data (such as audio or video) streams at as constant a rate as the* host controller scheduler can support.** Completion Callbacks:** The completion callback is made in_interrupt(), and one of the first* things that a completion handler should do is check the status field.* The status field is provided for all URBs. It is used to report* unlinked URBs, and status for all non-ISO transfers. It should not* be examined before the URB is returned to the completion handler.** The context field is normally used to link URBs back to the relevant* driver or request state.** When the completion callback is invoked for non-isochronous URBs, the* actual_length field tells how many bytes were transferred. This field* is updated even when the URB terminated with an error or was unlinked.** ISO transfer status is reported in the status and actual_length fields* of the iso_frame_desc array, and the number of errors is reported in* error_count. Completion callbacks for ISO transfers will normally* (re)submit URBs to ensure a constant transfer rate.** Note that even fields marked "public" should not be touched by the driver* when the urb is owned by the hcd, that is, since the call to* usb_submit_urb() till the entry into the completion routine.*/
struct urb {/* private: usb core and host controller only fields in the urb */struct kref kref; /* reference count of the URB */void *hcpriv; /* private data for host controller */atomic_t use_count; /* concurrent submissions counter */atomic_t reject; /* submissions will fail */int unlinked; /* unlink error code *//* public: documented fields in the urb that can be used by drivers */struct list_head urb_list; /* list head for use by the urb's* current owner */struct list_head anchor_list; /* the URB may be anchored */struct usb_anchor *anchor;struct usb_device *dev; /* (in) pointer to associated device */struct usb_host_endpoint *ep; /* (internal) pointer to endpoint */unsigned int pipe; /* (in) pipe information */unsigned int stream_id; /* (in) stream ID */int status; /* (return) non-ISO status */unsigned int transfer_flags; /* (in) URB_SHORT_NOT_OK | ...*/void *transfer_buffer; /* (in) associated data buffer */dma_addr_t transfer_dma; /* (in) dma addr for transfer_buffer */struct scatterlist *sg; /* (in) scatter gather buffer list */int num_mapped_sgs; /* (internal) mapped sg entries */int num_sgs; /* (in) number of entries in the sg list */u32 transfer_buffer_length; /* (in) data buffer length */u32 actual_length; /* (return) actual transfer length */unsigned char *setup_packet; /* (in) setup packet (control only) */dma_addr_t setup_dma; /* (in) dma addr for setup_packet */int start_frame; /* (modify) start frame (ISO) */int number_of_packets; /* (in) number of ISO packets */int interval; /* (modify) transfer interval* (INT/ISO) */int error_count; /* (return) number of ISO errors */void *context; /* (in) context for completion */usb_complete_t complete; /* (in) completion routine */struct usb_iso_packet_descriptor iso_frame_desc[0];/* (in) ISO ONLY */
};
struct usb_interface
path: include/linux/usb.h
/*** struct usb_interface - what usb device drivers talk to* @altsetting: array of interface structures, one for each alternate* setting that may be selected. Each one includes a set of* endpoint configurations. They will be in no particular order.* @cur_altsetting: the current altsetting.* @num_altsetting: number of altsettings defined.* @intf_assoc: interface association descriptor* @minor: the minor number assigned to this interface, if this* interface is bound to a driver that uses the USB major number.* If this interface does not use the USB major, this field should* be unused. The driver should set this value in the probe()* function of the driver, after it has been assigned a minor* number from the USB core by calling usb_register_dev().* @condition: binding state of the interface: not bound, binding* (in probe()), bound to a driver, or unbinding (in disconnect())* @sysfs_files_created: sysfs attributes exist* @ep_devs_created: endpoint child pseudo-devices exist* @unregistering: flag set when the interface is being unregistered* @needs_remote_wakeup: flag set when the driver requires remote-wakeup* capability during autosuspend.* @needs_altsetting0: flag set when a set-interface request for altsetting 0* has been deferred.* @needs_binding: flag set when the driver should be re-probed or unbound* following a reset or suspend operation it doesn't support.* @dev: driver model's view of this device* @usb_dev: if an interface is bound to the USB major, this will point* to the sysfs representation for that device.* @pm_usage_cnt: PM usage counter for this interface* @reset_ws: Used for scheduling resets from atomic context.* @reset_running: set to 1 if the interface is currently running a* queued reset so that usb_cancel_queued_reset() doesn't try to* remove from the workqueue when running inside the worker* thread. See __usb_queue_reset_device().* @resetting_device: USB core reset the device, so use alt setting 0 as* current; needs bandwidth alloc after reset.** USB device drivers attach to interfaces on a physical device. Each* interface encapsulates a single high level function, such as feeding* an audio stream to a speaker or reporting a change in a volume control.* Many USB devices only have one interface. The protocol used to talk to* an interface's endpoints can be defined in a usb "class" specification,* or by a product's vendor. The (default) control endpoint is part of* every interface, but is never listed among the interface's descriptors.** The driver that is bound to the interface can use standard driver model* calls such as dev_get_drvdata() on the dev member of this structure.** Each interface may have alternate settings. The initial configuration* of a device sets altsetting 0, but the device driver can change* that setting using usb_set_interface(). Alternate settings are often* used to control the use of periodic endpoints, such as by having* different endpoints use different amounts of reserved USB bandwidth.* All standards-conformant USB devices that use isochronous endpoints* will use them in non-default settings.** The USB specification says that alternate setting numbers must run from* 0 to one less than the total number of alternate settings. But some* devices manage to mess this up, and the structures aren't necessarily* stored in numerical order anyhow. Use usb_altnum_to_altsetting() to* look up an alternate setting in the altsetting array based on its number.*/
struct usb_interface {/* array of alternate settings for this interface,* stored in no particular order */struct usb_host_interface *altsetting;struct usb_host_interface *cur_altsetting; /* the currently* active alternate setting */unsigned num_altsetting; /* number of alternate settings *//* If there is an interface association descriptor then it will list* the associated interfaces */struct usb_interface_assoc_descriptor *intf_assoc;int minor; /* minor number this interface is* bound to */enum usb_interface_condition condition; /* state of binding */unsigned sysfs_files_created:1; /* the sysfs attributes exist */unsigned ep_devs_created:1; /* endpoint "devices" exist */unsigned unregistering:1; /* unregistration is in progress */unsigned needs_remote_wakeup:1; /* driver requires remote wakeup */unsigned needs_altsetting0:1; /* switch to altsetting 0 is pending */unsigned needs_binding:1; /* needs delayed unbind/rebind */unsigned reset_running:1;unsigned resetting_device:1; /* true: bandwidth alloc after reset */struct device dev; /* interface specific device info */struct device *usb_dev;atomic_t pm_usage_cnt; /* usage counter for autosuspend */struct work_struct reset_ws; /* for resets in atomic context */
};
struct usb_device
path: include/linux/usb.h
/*** struct usb_device - kernel's representation of a USB device* @devnum: device number; address on a USB bus* @devpath: device ID string for use in messages (e.g., /port/...)* @route: tree topology hex string for use with xHCI* @state: device state: configured, not attached, etc.* @speed: device speed: high/full/low (or error)* @tt: Transaction Translator info; used with low/full speed dev, highspeed hub* @ttport: device port on that tt hub* @toggle: one bit for each endpoint, with ([0] = IN, [1] = OUT) endpoints* @parent: our hub, unless we're the root* @bus: bus we're part of* @ep0: endpoint 0 data (default control pipe)* @dev: generic device interface* @descriptor: USB device descriptor* @bos: USB device BOS descriptor set* @config: all of the device's configs* @actconfig: the active configuration* @ep_in: array of IN endpoints* @ep_out: array of OUT endpoints* @rawdescriptors: raw descriptors for each config* @bus_mA: Current available from the bus* @portnum: parent port number (origin 1)* @level: number of USB hub ancestors* @can_submit: URBs may be submitted* @persist_enabled: USB_PERSIST enabled for this device* @have_langid: whether string_langid is valid* @authorized: policy has said we can use it;* (user space) policy determines if we authorize this device to be* used or not. By default, wired USB devices are authorized.* WUSB devices are not, until we authorize them from user space.* FIXME -- complete doc* @authenticated: Crypto authentication passed* @wusb: device is Wireless USB* @lpm_capable: device supports LPM* @usb2_hw_lpm_capable: device can perform USB2 hardware LPM* @usb2_hw_lpm_besl_capable: device can perform USB2 hardware BESL LPM* @usb2_hw_lpm_enabled: USB2 hardware LPM is enabled* @usb2_hw_lpm_allowed: Userspace allows USB 2.0 LPM to be enabled* @usb3_lpm_enabled: USB3 hardware LPM enabled* @string_langid: language ID for strings* @product: iProduct string, if present (static)* @manufacturer: iManufacturer string, if present (static)* @serial: iSerialNumber string, if present (static)* @filelist: usbfs files that are open to this device* @maxchild: number of ports if hub* @quirks: quirks of the whole device* @urbnum: number of URBs submitted for the whole device* @active_duration: total time device is not suspended* @connect_time: time device was first connected* @do_remote_wakeup: remote wakeup should be enabled* @reset_resume: needs reset instead of resume* @port_is_suspended: the upstream port is suspended (L2 or U3)* @wusb_dev: if this is a Wireless USB device, link to the WUSB* specific data for the device.* @slot_id: Slot ID assigned by xHCI* @removable: Device can be physically removed from this port* @l1_params: best effor service latency for USB2 L1 LPM state, and L1 timeout.* @u1_params: exit latencies for USB3 U1 LPM state, and hub-initiated timeout.* @u2_params: exit latencies for USB3 U2 LPM state, and hub-initiated timeout.* @lpm_disable_count: Ref count used by usb_disable_lpm() and usb_enable_lpm()* to keep track of the number of functions that require USB 3.0 Link Power* Management to be disabled for this usb_device. This count should only* be manipulated by those functions, with the bandwidth_mutex is held.** Notes:* Usbcore drivers should not set usbdev->state directly. Instead use* usb_set_device_state().*/
struct usb_device {int devnum;char devpath[16];u32 route;enum usb_device_state state;enum usb_device_speed speed;struct usb_tt *tt;int ttport;unsigned int toggle[2];struct usb_device *parent;struct usb_bus *bus;struct usb_host_endpoint ep0;struct device dev;struct usb_device_descriptor descriptor;struct usb_host_bos *bos;struct usb_host_config *config;struct usb_host_config *actconfig;struct usb_host_endpoint *ep_in[16];struct usb_host_endpoint *ep_out[16];char **rawdescriptors;unsigned short bus_mA;u8 portnum;u8 level;unsigned can_submit:1;unsigned persist_enabled:1;unsigned have_langid:1;unsigned authorized:1;unsigned authenticated:1;unsigned wusb:1;unsigned lpm_capable:1;unsigned usb2_hw_lpm_capable:1;unsigned usb2_hw_lpm_besl_capable:1;unsigned usb2_hw_lpm_enabled:1;unsigned usb2_hw_lpm_allowed:1;unsigned usb3_lpm_enabled:1;int string_langid;/* static strings from the device */char *product;char *manufacturer;char *serial;struct list_head filelist;int maxchild;u32 quirks;atomic_t urbnum;unsigned long active_duration;#ifdef CONFIG_PMunsigned long connect_time;unsigned do_remote_wakeup:1;unsigned reset_resume:1;unsigned port_is_suspended:1;
#endifstruct wusb_dev *wusb_dev;int slot_id;enum usb_device_removable removable;struct usb2_lpm_parameters l1_params;struct usb3_lpm_parameters u1_params;struct usb3_lpm_parameters u2_params;unsigned lpm_disable_count;
};
struct usb_host_config
path: include/linux/usb.h
/*** struct usb_host_config - representation of a device's configuration* @desc: the device's configuration descriptor.* @string: pointer to the cached version of the iConfiguration string, if* present for this configuration.* @intf_assoc: list of any interface association descriptors in this config* @interface: array of pointers to usb_interface structures, one for each* interface in the configuration. The number of interfaces is stored* in desc.bNumInterfaces. These pointers are valid only while the* the configuration is active.* @intf_cache: array of pointers to usb_interface_cache structures, one* for each interface in the configuration. These structures exist* for the entire life of the device.* @extra: pointer to buffer containing all extra descriptors associated* with this configuration (those preceding the first interface* descriptor).* @extralen: length of the extra descriptors buffer.** USB devices may have multiple configurations, but only one can be active* at any time. Each encapsulates a different operational environment;* for example, a dual-speed device would have separate configurations for* full-speed and high-speed operation. The number of configurations* available is stored in the device descriptor as bNumConfigurations.** A configuration can contain multiple interfaces. Each corresponds to* a different function of the USB device, and all are available whenever* the configuration is active. The USB standard says that interfaces* are supposed to be numbered from 0 to desc.bNumInterfaces-1, but a lot* of devices get this wrong. In addition, the interface array is not* guaranteed to be sorted in numerical order. Use usb_ifnum_to_if() to* look up an interface entry based on its number.** Device drivers should not attempt to activate configurations. The choice* of which configuration to install is a policy decision based on such* considerations as available power, functionality provided, and the user's* desires (expressed through userspace tools). However, drivers can call* usb_reset_configuration() to reinitialize the current configuration and* all its interfaces.*/
struct usb_host_config {struct usb_config_descriptor desc;char *string; /* iConfiguration string, if present *//* List of any Interface Association Descriptors in this* configuration. */struct usb_interface_assoc_descriptor *intf_assoc[USB_MAXIADS];/* the interfaces associated with this configuration,* stored in no particular order */struct usb_interface *interface[USB_MAXINTERFACES];/* Interface information available even when this is not the* active configuration */struct usb_interface_cache *intf_cache[USB_MAXINTERFACES];unsigned char *extra; /* Extra descriptors */int extralen;
};
函数iminor imajor
path :include/linux/fs.h
static inline unsigned iminor(const struct inode *inode)
{return MINOR(inode->i_rdev);
}static inline unsigned imajor(const struct inode *inode)
{return MAJOR(inode->i_rdev);
}
struct usb_class_driver
usb.h
/*** struct usb_class_driver - identifies a USB driver that wants to use the USB major number* @name: the usb class device name for this driver. Will show up in sysfs.* @devnode: Callback to provide a naming hint for a possible* device node to create.* @fops: pointer to the struct file_operations of this driver.* @minor_base: the start of the minor range for this driver.** This structure is used for the usb_register_dev() and* usb_unregister_dev() functions, to consolidate a number of the* parameters used for them.*/
struct usb_class_driver {char *name;char *(*devnode)(struct device *dev, umode_t *mode);const struct file_operations *fops;int minor_base;
};
struct usb_host_endpoint
/*** struct usb_host_endpoint - host-side endpoint descriptor and queue* @desc: descriptor for this endpoint, wMaxPacketSize in native byteorder* @ss_ep_comp: SuperSpeed companion descriptor for this endpoint* @urb_list: urbs queued to this endpoint; maintained by usbcore* @hcpriv: for use by HCD; typically holds hardware dma queue head (QH)* with one or more transfer descriptors (TDs) per urb* @ep_dev: ep_device for sysfs info* @extra: descriptors following this endpoint in the configuration* @extralen: how many bytes of "extra" are valid* @enabled: URBs may be submitted to this endpoint** USB requests are always queued to a given endpoint, identified by a* descriptor within an active interface in a given USB configuration.*/
struct usb_host_endpoint {struct usb_endpoint_descriptor desc;struct usb_ss_ep_comp_descriptor ss_ep_comp;struct list_head urb_list;void *hcpriv;struct ep_device *ep_dev; /* For sysfs info */unsigned char *extra; /* Extra descriptors */int extralen;int enabled;
};
struct usb_host_interface
/* host-side wrapper for one interface setting's parsed descriptors */
struct usb_host_interface {struct usb_interface_descriptor desc;int extralen;unsigned char *extra; /* Extra descriptors *//* array of desc.bNumEndpoint endpoints associated with this* interface setting. these will be in no particular order.*/struct usb_host_endpoint *endpoint;char *string; /* iInterface string, if present */
};
struct usb_device_descriptor
/* USB_DT_DEVICE: Device descriptor */
struct usb_device_descriptor {__u8 bLength;__u8 bDescriptorType;__le16 bcdUSB;__u8 bDeviceClass;__u8 bDeviceSubClass;__u8 bDeviceProtocol;__u8 bMaxPacketSize0;__le16 idVendor;__le16 idProduct;__le16 bcdDevice;__u8 iManufacturer;__u8 iProduct;__u8 iSerialNumber;__u8 bNumConfigurations;
} __attribute__ ((packed));
USB设备类型宏定义
/** Device and/or Interface Class codes* as found in bDeviceClass or bInterfaceClass* and defined by www.usb.org documents*/
#define USB_CLASS_PER_INTERFACE 0 /* for DeviceClass */
#define USB_CLASS_AUDIO 1
#define USB_CLASS_COMM 2
#define USB_CLASS_HID 3
#define USB_CLASS_PHYSICAL 5
#define USB_CLASS_STILL_IMAGE 6
#define USB_CLASS_PRINTER 7
#define USB_CLASS_MASS_STORAGE 8
#define USB_CLASS_HUB 9
#define USB_CLASS_CDC_DATA 0x0a
#define USB_CLASS_CSCID 0x0b /* chip+ smart card */
#define USB_CLASS_CONTENT_SEC 0x0d /* content security */
#define USB_CLASS_VIDEO 0x0e
#define USB_CLASS_WIRELESS_CONTROLLER 0xe0
#define USB_CLASS_MISC 0xef
#define USB_CLASS_APP_SPEC 0xfe
#define USB_CLASS_VENDOR_SPEC 0xff#define USB_SUBCLASS_VENDOR_SPEC 0xff
struct usb_config_descriptor
/* USB_DT_CONFIG: Configuration descriptor information.** USB_DT_OTHER_SPEED_CONFIG is the same descriptor, except that the* descriptor type is different. Highspeed-capable devices can look* different depending on what speed they're currently running. Only* devices with a USB_DT_DEVICE_QUALIFIER have any OTHER_SPEED_CONFIG* descriptors.*/
struct usb_config_descriptor {__u8 bLength;__u8 bDescriptorType;__le16 wTotalLength;__u8 bNumInterfaces;__u8 bConfigurationValue;__u8 iConfiguration;__u8 bmAttributes;__u8 bMaxPower;
} __attribute__ ((packed));
struct usb_interface_descriptor
/* USB_DT_INTERFACE: Interface descriptor */
struct usb_interface_descriptor {__u8 bLength;__u8 bDescriptorType;__u8 bInterfaceNumber;__u8 bAlternateSetting;__u8 bNumEndpoints;__u8 bInterfaceClass;__u8 bInterfaceSubClass;__u8 bInterfaceProtocol;__u8 iInterface;
} __attribute__ ((packed));
struct usb_ss_ep_comp_descriptor
/* USB_DT_SS_ENDPOINT_COMP: SuperSpeed Endpoint Companion descriptor */
struct usb_ss_ep_comp_descriptor {__u8 bLength;__u8 bDescriptorType;__u8 bMaxBurst;__u8 bmAttributes;__le16 wBytesPerInterval;
} __attribute__ ((packed));
函数： usb_get_dev
path : drivers/usb/core/usb.c
/*** usb_get_dev - increments the reference count of the usb device structure* @dev: the device being referenced** Each live reference to a device should be refcounted.** Drivers for USB interfaces should normally record such references in* their probe() methods, when they bind to an interface, and release* them by calling usb_put_dev(), in their disconnect() methods.** Return: A pointer to the device with the incremented reference counter.*/
struct usb_device *usb_get_dev(struct usb_device *dev)
{if (dev)get_device(&dev->dev);return dev;
}
EXPORT_SYMBOL_GPL(usb_get_dev);
函数： usb_put_dev
path : drivers/usb/core/usb.c
/*** usb_put_dev - release a use of the usb device structure* @dev: device that's been disconnected** Must be called when a user of a device is finished with it. When the last* user of the device calls this function, the memory of the device is freed.*/
void usb_put_dev(struct usb_device *dev)
{if (dev)put_device(&dev->dev);
}
EXPORT_SYMBOL_GPL(usb_put_dev);dev_get_drvdata
path :drivers/base/dd.c
/** These exports can't be _GPL due to .h files using this within them, and it* might break something that was previously working...*/
void *dev_get_drvdata(const struct device *dev)
{if (dev && dev->p)return dev->p->driver_data;return NULL;
}
EXPORT_SYMBOL(dev_get_drvdata);
dev_set_drvdata
path :drivers/base/dd.c
int dev_set_drvdata(struct device *dev, void *data)
{int error;if (!dev->p) {error = device_private_init(dev);if (error)return error;}dev->p->driver_data = data;return 0;
}
EXPORT_SYMBOL(dev_set_drvdata);
